  • Page 1 Network Video Recorder Installation Manual DR-3516P Powered by...
  • Page 2 Before reading this manual This manual contains basic instructions on installing and using DirectIP Network Video Recorder, an IDIS product. Users who are using this product for the first time, as well as users with experience using comparable products, must read this manual carefully before use and heed to the warnings and precautions contained herein while using the product.
  • Page 3 Before reading this manual Important Safeguards 1. Read Instructions All the safety and operating instructions should be damage and will often require extensive work by a qualified technician to read before the appliance is operated. restore the equipment to its normal operation. 2.
  • Page 4 Before reading this manual In-Text Symbol Type Description Caution Important information concerning a specific function. Note Useful information concerning a specific function. User’s Caution Statement Caution: Any changes or modifications to the equipment not expressly approved by the party responsible for compliance could void your authority to operate the equipment.
  • Page 5 Before reading this manual Copyright © 2022 IDIS Co., Ltd. IDIS Co., Ltd. reserves all rights concerning this manual. Use or duplication of this manual in part or whole without the prior consent of IDIS Co., Ltd. is strictly prohibited. Contents of this manual are subject to change without prior notice.

  • Page 6: Table Of Contents

    Table of Contents Part 1 – Introduction ......... 7 Product Features .

  • Page 7: Part 1 - Introduction

    Part 1 – Introduction Product Features This is a DirectIP-enabled video recorder that supports surveillance, recording, and playback of video from network cameras (or video encoders). This NVR (Network Video Recorder) unit offers the following features: ● Real-time 8/16-channel DirectIP network surveillance ●...
  • Page 8 Part 1 – Introduction Audio Out HDMI Monitor VGA Monitor DirectIP™ Gigabit PoE Switch Network Camera USB HDD Flash Memory HDMI Monitor VGA Monitor Audio Out Network Camera DirrectIP Giagabit PoE Switch Network Camera Alarm Out USB HDD Flash Memory Network Video Recorder Analog Alarm...

  • Page 9: Accessories

    Part 1 – Introduction Accessories Upon unpackaging the product, check the contents inside to ensure that all the following accessories are included. Network Video Recorder Power Cable Quick Guide SATA2 cables Optical USB Mouse IR Remote Control (Optional) Assembly Screws for Adding Hard Rack-mount Kit Disk Drives Rack Installation Precautions...

  • Page 10: Overview

    Part 1 – Introduction Overview Front Panel LEDs USB Ports • Remote control sensor is located on the bottom center of the front panel. Ensure that the sensor remains unobstructed at all times. If obstructed, the sensor might not be able to receive remote control signals. •...
  • Page 11 Part 1 – Introduction Connections on the Front Panel IR Remote Control Flash Memory Mouse USB HDD...

  • Page 12: Dimensions

    Part 1 – Introduction Dimensions Unit : mm...

  • Page 13: Rear Panel

    Part 1 – Introduction Rear Panel Video In / PoE Ports Video In / Ext. Port Network Port eSATA Ports USB Port Alarm Connection Ports RS-485 Port RS-232 Port HDMI Out Port VGA Out Port Audio Ports Power In Port Vent...

  • Page 14: Rear Panel Connections

    Part 1 – Introduction Rear Panel Connections Network Connection Video Connection This NVR is capable of connecting to networks via an ● Video In/PoE Port ethernet connector. Connect an RJ-45 cable (Cat5e, or Cat6) to the NVR's network port. It's possible to operate and upgrade the NVR remotely over a network.
  • Page 15 Part 1 – Introduction USB Port Alarm Connection Connect alarm connectors to these ports. Support SuperSpeed USB 3.0 (5Gbps), High-Speed USB 2.0 (480Mbps) and Full-Speed USB 1.0 (12Mbps) for transfer. Press down on the button and insert the cable into the opening.
  • Page 16 Part 1 – Introduction ● ARI (Alarm Reset In) • This NVR does not feature a built-in audio amplifier An external signal to the Alarm Reset In can be used to unit and therefore requires the user to purchase a speaker system with a built-in amplifier separately.
  • Page 17 Part 1 – Introduction Connections on the Rear Panel Video Encoder Analog Camera Network Camera USB 3.0 DirectIP Gigabit Network PoE Switch Camera Sensor eSATA Storage Network Microphone Device Speaker IDIS Center Keyboard VGA Monitor Remote Monitoring Alarm HDMI Monitor Power...

  • Page 18: Remote Control

    Part 1 – Introduction Remote Control (Optional) ID Button PANIC Button Camera Buttons STATUS Button LAYOUT Button PTZ Control Buttons REGISTER MODE Button THUMBNAIL Button CALENDAR Button KEYLOCK Button SETUP Button FREEZE Button LOG Button Enter Button Arrow Buttons ALARM Button SEQUENCE Button &...
  • Page 19 Part 1 – Introduction 1 ID Button 7 REGISTER MODE Button Used to assign remote control ID values. Used in Live mode to access Camera Registration mode. No additional remote control assignment is necessary if the system's ID is 0. If the system's ID is 8 THUMBNAIL Button a number between 1 and 99, however, you will need Used in Playback mode to access Thumbnail Search...
  • Page 20 Part 1 – Introduction $ Enter Button b MENU Button Pressing the MENU button while in Live mode Used to make menu option selections and register data entries. In addition, pressing this button while displays the Live menu. Alternatively, pressing the a camera screen is selected by pressing the Menu button while in Time-lapse Search mode displays the button in Live or Playback mode displays the Camera...

  • Page 21: Part 2 - Appendix

    Part 2 - Appendix System Log Types Boot Up Panic On System Shutdown Panic Off Restart Clear All Data Upgrade Success Clear Disk Upgrade Error Format Disk Power Failure Disk Full Time Changed Auto Deletion Time Zone Change Search Begin Time Sync.

  • Page 22: Error Code Types

    Part 2 - Appendix Error Code Types Upgrade Error Codes Type Type Unknown Error Remote Network Error Incorrect File Version No Remote Upgrade Permission Incorrect OS Version Remote Upgrade File Save Failure Incorrect Software Version Remote Upgrade Cancelled by User Incorrect Kernel Version USB Storage Device Mount Failure Storage Device Mount Failure...
  • Page 23 Part 2 - Appendix Clip Copy Error Codes Type Type Unknown Error Disk Error Device Error Clip Player Execution File Not Found Device Connection Failure Clip Player Execution File Access Failure CD Media Not Found Clip Player Execution File Save Failure Incorrect Media Image Generation Failure File Name Taken...
  • Page 24 Part 2 - Appendix Network Error Codes Type Type Cause of Failure Unknown Connection Cancelled by User Normal Logout No Response from Network Device Host All Channels in Use - Connection Denied High Network Noise Level Incorrect Product Version Info Transmission Queue Full Incorrect User Name or Password Incorrect OEM Info...

  • Page 25: Troubleshooting

    Part 2 - Appendix Troubleshooting Problem Solution ● Check the power cable connection status. The main unit won't turn on. ● Check the power outlet. ● Check the camera's video cable connection status. ● Check the monitor's video cable connection status. Unable to display Live video.

  • Page 26: Specifications

    Part 2 - Appendix Specifications These product specifications may change without prior notice. VIDEO Video Inputs 16 IP channels Video Outputs 1 HDMI, 1 VGA HDMI : 3840x2160, 1920 x 1200, 1920 x 1080, 1680 x 1050, 1600 x 1200 Display Resolution VGA : 1920 x 1200, 1920 x 1080, 1680 x 1050, 1600 x 1200 Display Speed...
  • Page 27 Part 2 - Appendix INTERFACE Local(NVR) : 1 RCA / 1RCA + 1HDMI Audio In / Out IP Camera : 16 / 16 (Depending on IP Camera) NVR Alarm Spec- In 4 TTL, NC/NO programmable, 2.4V (NC) or 0.3V (NO) threshold, 5V DC NVR Alarm Spec- Out 1 relay output, NC/NO, 2A@125V AC, 1A@30V DC NVR Alarm Spec - Reset IN...
  • Page 28 IDIS Co., Ltd. For more information, please visit at www.idisglobal.com...
