  • Page 1 Network Video Recorder Operation Manual DR-1504P DR-1508P Powered by...
  • Page 2 Before reading this manual This operation manual contains basic instructions on installing and using DirectIP Network Video Recorder, an IDIS product. Users who are using this product for the first time, as well as users with experience using comparable products, must read this operation manual carefully before use and heed to the warnings and precautions contained herein while using the product.
  • Page 3 Before reading this manual 1. Read Instructions D. If the equipment does not operate normally by following the operating instructions, adjust only those controls that are covered by the operating All the safety and operating instructions should be read before the appliance instructions as an improper adjustment of other controls may result in is operated.
  • Page 4 Before reading this manual Important Safeguards In-Text Symbol Type Description Caution Important information concerning a specific function. Note Useful information concerning a specific function. User’s Caution Statement Caution: Any changes or modifications to the equipment not expressly approved by the party responsible for compliance could void your authority to operate the equipment.
  • Page 5 Before reading this manual Copyright © 2022 IDIS Co., Ltd. IDIS Co., Ltd. reserves all rights concerning this operation manual. Use or duplication of this operation manual in part or whole without the prior consent of IDIS Co., Ltd. is strictly prohibited.

  • Page 6: Table Of Contents

    Table of Contents Part 1 - Getting Started ........9 Setting Password .
  • Page 7 User ..................33 Security .
  • Page 8 Push ..................72 HTTP .

  • Page 9: Part 1 - Getting Started

    Part 1 - Getting Started Setup Wizard This document covers the 4- and 8- channel network video recorders. The NVRs are identical except for the number of cameras that can be Setup Wizard lets you configure basic settings required connected and the number of cameras that can for operating the system.
  • Page 10 Part 1 - Getting Started Choose the desired Recording Method and click Quick Wizard Next. Select Quick Wizard. Choose the desired Recording Quality and click Next. Specify the current date and time and then click Next. • Higher recording quality uses up more disk space.
  • Page 11 Part 1 - Getting Started – Recording resolutions used under each recording method Network Wizard and record video quality setting are as follows: High Video Quality Standard Longer Recording After exiting from Quick Wizard, the network with Priority Profile Recording Time Priority Network Wizard will start automatically.
  • Page 12 Part 1 - Getting Started Enter in the Device Name field the NVR name to be Select Network Configuration and then click Next. Select either Auto Configuration or Manual registered on the FEN server and then click Check to Configuration and then click Test to test the system’s check its availability.

  • Page 13: Camera Registration

    Part 1 - Getting Started Camera Registration Click Finish to exit Network Wizard. Once Network Setup Wizard is complete, live mode screen appears. While in live mode, right-click on the mouse and select Camera Registration to run the Camera Registration mode. It allows you to scan for the cameras connected to the NVR.

  • Page 14: Camera Scan Button

    Part 1 - Getting Started Camera Scan Button ● Mode: Select the scan mode. – Auto Scan (LAN): Lists cameras in a LAN environment. If Auto Scan (LAN) fails to recognize You can scan and search and register cameras that were a camera, try using IP Address Scan instead.
  • Page 15 Part 1 - Getting Started Set Camera Password Search Scope For IDIS protocol cameras that support changing and Filters the cameras in the camera list depending on the finding the camera password, you must set the camera search scope such as specified IP address rang password at the time of initial camera registration.

  • Page 16: Camera View Buttons

    Part 1 - Getting Started Scan Refresh Interval Configures the refresh interval to scan the camera. If the interval is short, camera scan results are refreshed more frequently. However, if the interval is long, it is advantageous to scan cameras on a wide network. Camera View Buttons IDIS cameras can be detected automatically but ●...

  • Page 17: Camera List Area

    Part 1 - Getting Started Camera List Area Following options can be accessed by right-clicking on a camera list entry: ● Add/Remove Camera: Adds or removes the selected camera. The Add Camera option is inactive if the camera has already been added to the screen. ●...

  • Page 18: Video Display Area

    Part 1 - Getting Started Video Display Area • Information is not indicated on the bottom of the screen for cameras already registered to the NVR, and the Screen Position/Registration Info icon is Left-click on the video display area to toggle between shown with a black background.

  • Page 19: Apply/Cancel Buttons

    Part 1 - Getting Started Apply/Cancel Buttons Diagnosis Process While in Camera Registration mode, select Apply When the camera is registered to the NVR, Self- to register all changes. When selecting Apply, the diagnosis runs automatically for the new registered and changed cameras.

  • Page 20: Camera Registration Mode

    Part 1 - Getting Started Camera Registration Mode Login Configuring the NVR’s settings and accessing its While in Live mode, right-click and select Camera searching and other functions require an authorized Registration. user login. Bring up the Live menu and click on icon using the mouse to log in.
  • Page 21 Part 1 - Getting Started Enter an UPR(User Password Reset) verification and Find Password then click on UPR Verification button. If you do not know the password, select FIND PW . You can set a new password. Enter a user, registered email and then select Get Verification Code.

  • Page 22: Live Menu

    Part 1 - Getting Started Live Mode Live Menu Placing the mouse pointer near the top portion of the screen displays the Live menu. 5 6 7 8 9 0 Previous Group, Login/Logout Layout Display Next Group Freeze Panic Recording Sequence Status Select Camera...
  • Page 23 Part 1 - Getting Started 1 Login/Logout Cameo Sequence Log into and out from accounts. If in the logged in In Cameo Sequence mode, only the bottom right state, the account ID is shown. If in the logged out state, the login icon is shown. screen in a split screen setup changes sequence.

  • Page 24: Zoom

    Part 1 - Getting Started Zoom 8 Status Displays the status window for NVR's system and device. While in Live mode, right-click and select Zoom. When a zoom frame appears on the selected channel, right-click on the mouse to zoom in. Use the arrow 9 Select Camera buttons to position the frame.
  • Page 25 Part 1 - Getting Started Setting Up a PTZ Preset Advanced Settings In PTZ mode, selecting a camera and then right-clicking While in PTZ mode, select the icon to display the on the mouse loads the Advanced PTZ screen as shown Set Preset window and assign the current position as a below.

  • Page 26: Event Monitoring

    Part 1 - Getting Started Covert Camera • The exact PTZ protocol supported by the camera must be specified in order to use the NVR's PTZ controls. Use this feature to assign Covert Camera View • Drag and drop to reposition the PTZ Tools window. permissions.

  • Page 27: Edit Group

    Part 1 - Getting Started Video Recording Edit Group Video recording will only take place if all the connections Edit Group lets you customize split screen pages in both are made correctly as per information contained in Part Live and Search modes. 2 of this operation manual.

  • Page 28: Video Recording Playback

    Part 1 - Getting Started Video Recording Playback You can play back video recordings by using mouse. • Login with an account that has search permission is needed to playback video recordings. • The initial video playback point in Search mode is the recording's last playback point or the end of the recording data.

  • Page 29: Part 2 - Configuration

    Part 2 - Configuration Menu Use While in Live mode, select Live menu > Setup using the mouse. Information contained in this section (Menu Use) applies to all other instructions found throughout Part 3 - Configuration. Menu Icon Use the virtual keyboard to enter text. Type the text.

  • Page 30: Text Input Via Virtual Keyboard

    Part 2 - Configuration Text Input via Virtual Keyboard Batch Assignment Click on the key using the mouse. Certain table-format menus such as the shown in the Camera Setup on page 40 allow you to change the title value. In this case, changing the title value simultaneously changes all other entry values on the same row.

  • Page 31: System Setup

    Part 2 - Configuration System Setup ● Import: Decide whether to import network settings as well. If you do not wish to change the current network settings, do not select Include Network Refer to the Menu Use on page 29 for basic Setup.

  • Page 32: Date/Time

    Part 2 - Configuration Date/Time In order to display the system_log.txt file, you must use the correct character encoding settings and use a ● Date: Used to change the system’s date setting. fixed-width font. ● Time: Used to change the system’s time setting. ●...

  • Page 33: User

    Part 2 - Configuration ● Holiday: Designate holidays. On specified holidays, User recording takes place according to the holiday recording schedule specified under Record Schedule. Use this option to register users and assign permissions. Select the + button at the bottom of the window. Select a date.
  • Page 34 Part 2 - Configuration Select a group for the user and then enter a Group Permissions password. The password can be up to 16 characters in length and may include letters, symbols, and May shutdown the numbers. The e-mail address will be used as System Shutdown system from the information on password verification.
  • Page 35 Part 2 - Configuration Remote Connection Policy May configure camera Camera Setup settings. May change the Select camera channels to System Time Camera Is Hidden hide on the screen when system's date and time Change connecting remotely. settings. Select Schedule On and May clear data stored Data Clear then configure the days...

  • Page 36: Security

    Part 2 - Configuration Security If you click the + button at the bottom of the table, the following message will appear and you can register the 2FA device. Use this option to configure security settings. • 2FA device registration is supported only via IDIS Mobile app.

  • Page 37: Storage

    Part 2 - Configuration Storage Network Security (Host Certificates) This is the certificate management menu for network Use this option to configure storage settings. security access. It supports checking the product certificate information, creating the new certificate, exporting and importing certificates. ●...

  • Page 38: Self-Diagnosis

    Part 2 - Configuration Self-Diagnosis • The reports are stored in up to 24 files. If you have configured Auto Generating Interval as one-day period, only the the reports from the last 24 days Use this option to configure self-diagnostic settings. can be viewed.

  • Page 39: Custom Value

    Part 2 - Configuration Custom Value ● Name: Set the name of system properties to be included in a JSON file on HTTP notifications. ● Value: Set the value of system properties to be included in a JSON file on HTTP notifications. About ●...

  • Page 40: Camera Setup

    Part 2 - Configuration Camera Setup Device Scan Scan the device under Registration - Scan. Refer to the Menu Use on page 29 for basic information on using the Setup menus. Registration You can register cameras at remote locales. By selecting a number from the list, you can move the camera up or down the list using the mouse wheel to reorder its position.
  • Page 41 Part 2 - Configuration ● Filter: Enter a keyword in the MAC Address / Address Login / Model / Name / Status fields for the selected camera. This allows the user to scan this camera easily. If the password is set or you want to register third party cameras, registering a device requires an authorized •...

  • Page 42: General

    Part 2 - Configuration General Set Camera Password For IDIS protocol cameras that support changing and Enable/disable the covert view and rename cameras. finding the camera password, you must set the camera password at the time of initial camera registration. The email information is used to change and find the camera password.

  • Page 43: Advanced Setup

    Part 2 - Configuration Advanced Setup Configure security and other advanced camera settings. Numbers shown below Preset, Scan, Pattern, and Tour indicate the numbers of configured functions. ● Video: Adjust the camera image sensor settings such 1 Preset as white balance and exposure. Configuration options may differ depending on the camera model.
  • Page 44 Part 2 - Configuration Used to tilt and pan the camera. 2 Scan Used to set up a profile for moving the camera between – Zoom ( ): Zoom in and out. two points. At least two presets must be available in –...
  • Page 45 Part 2 - Configuration 5 PTZ Reset: Reboots the camera’s panning / tilting Privacy Masking Options and zoom settings. 6 Home Position: Specify the camera’s home position. ● Default: Uses the factory-default position as the camera’s home position. ● Custom: Uses the user-defined position as the home position.
  • Page 46 Part 2 - Configuration ● White LED Mode: Clicking on/off enables or disables Image Sensor Options White LED lighting when motion is detected by the PIR sensor. Also clicking auto allows the system to enable/disable White LED mode automatically. ● Pivot: Enable this option and choose the direction of the pivot.
  • Page 47 Part 2 - Configuration White Balance Options Exposure Options ● Preset: Use preconfigured white balance settings. ● AE Target Gain: Specify exposure compensation’s – Auto: Allow the system to adjust the white target gain. Exposure is compensated automatically balance automatically. The system will assess the based on the specified target gain.
  • Page 48 Part 2 - Configuration ● IRIS: Depending on the camera type, the user can Day & Night Options select DC-IRIS or P-IRIS. – DC IRIS – OFF : Select this if a manual IRIS lens is mounted on the camera. –...

  • Page 49: Stream I

    Part 2 - Configuration Stream I View Options Configure the camera’s live and recording resolution, ● Type: Selects the camera view. codec, picture quality, transfer speed, and ips speed settings. ● Mode: Selects the screen layout in live mode. ● Camera Channels: It’s possible to configure a unique video profile for each camera.

  • Page 50: Stream Ii

    Part 2 - Configuration ● Use Dual Track Recording: Set to record with the Stream II video profile value (main stream) set in the schedule and record with the profile 4 value (sub stream) at the same time. • It displays as below when recording on a network video recorder.

  • Page 51: Maintenance

    Part 2 - Configuration ● MAT Setup : Select the MAP Setup option to use the Maintenance MAT (Motion Adaptive Transmission) function during video transmission and recording. When the USB search window appears, select the • When the MAT (Motion Adaptive Transmission) corresponding upgrade package from the storage function is active, the associated VA device may device connected to the NVR’s USB port.

  • Page 52: Record Setup

    Part 2 - Configuration Record Setup ● Limit Time-Lapse Recording: You can store event recording data for longer. If you do not wish to use Limit Time-Lapse Recording, select Never. This Refer to the Menu Use on page 29 for basic function is activated when data has been stored for information on using the Setup menus.

  • Page 53: Schedule

    Part 2 - Configuration Schedule Simple Mode Options ● Mode: Select No Record, Time, Event, or Time & Event. Unless the Panic Record button is pressed, no recording will take place Record during the scheduled time frames on the scheduled days. icon appears on the upper left corner of the screen.
  • Page 54 Part 2 - Configuration If a camera supporting the Dual Track Recording Advanced Mode Options function (Main and Sub stream) is in use, the following Select to configure event types and video profiles. icon will be displayed. ● Type: Event-specific and time recording icons are as follows: Recording both mainstream and substream Time Lapse...

  • Page 55: Pre-Event

    Part 2 - Configuration Event Setup Pre-Event When an event occurs, enabling this option includes Refer to the Menu Use on page 29 for basic the specified duration prior to the event in the event- information on using the Setup menus. triggered recording.

  • Page 56: Camera System

    Part 2 - Configuration Monitoring Options Monitors disks that support Disk S.M.A.R.T. and notifies the user if a S.M.A.R.T. disk error is detected. Define monitoring times. If self- diagnosis is not performed on a System It will be highlighted when the NVR regular basis, the system will assume Disk Config reboots after the hard disk drive has...

  • Page 57: Camera System_Video Loss

    Part 2 - Configuration Camera System_Video Loss Camera System_Recording Fail ● Activation Time: Specify how long recording fail has ● Activation Time: Specify how long video loss has to last in order for it to be considered as an event. to last in order for it to be considered as an event.

  • Page 58: Camera System_Pir

    Part 2 - Configuration Camera System_PIR – Use Ignoring Time: Select Time Setup to specify the PIR detection ignore time of camera channels. PIR detection will be disabled during the specified This event occurs when the PIR sensor mounted on the time frame.

  • Page 59: Video-Analytics

    Part 2 - Configuration Video-Analytics From the zone selection screen, press the button on the remote control or right-click on the mouse to open up the Zone Setup menu. Event lists that occur through video analysis include Motion, Tampering, PIR, TripZone, Face Detection and Auto Tracking events..

  • Page 60: Video-Analytics_Trip Zone

    Part 2 - Configuration – Daytime Setup: Specify when daytime starts Video-Analytics_Trip Zone and ends. Adjust the time frame in 15-minute increments. Times outside the specified range will be assumed as nighttime by the system. ● Actions: Specify which actions to take when motion is detected.
  • Page 61 Part 2 - Configuration Trip Zone Ignoring Time does not affect Trip Zone recording. – Daytime Setup: Specify when daytime starts and ends. Adjust the time frame in 15-minute increments. Times outside the specified range will be assumed as nighttime by the system. ●...

  • Page 62: Video-Analytics_Tampering

    Part 2 - Configuration Video-Analytics_Tampering ● Actions: Specify which actions to take when Tampering is detected. – Record: Specify which cameras to begin linked recording on when an event occurs. If the schedule is set to Event or Time & Event mode, the selected cameras will begin linked recording when an event occurs.

  • Page 63: Video-Analytics_Auto Tracking

    Part 2 - Configuration ● Actions: Specify which actions to take when Alarm-In Video-Analytics_Auto Tracking is detected. – Record: Specify which cameras to begin linked When the PTZ camera detects a moving object, the recording on when an event occurs. If the schedule camera operates the PTZ to track the moving object.

  • Page 64: Network Setup

    Part 2 - Configuration Network Setup Designate the IP address type as IPv4_None, IPv4_ Refer to the Menu Use on page 29 for basic Manual, IPv4_DHCP, IPv6_None or IPv6_Link-local. information on using the Setup menus. IPv4_None General Select None and then save to disable IPv4 mode. ●...
  • Page 65 Part 2 - Configuration ● Ping Test: Select to test the current WAN settings you ● Trace Route Test: The NVR tries to trace a network made. path to its destination. Set the network address of the destination. Enter the IP address of the NVR. Set the maximum number of hops.
  • Page 66 Part 2 - Configuration IPv4_DHCP IPv6_Manual Select DHCP and then Save to retrieve IP address and other network settings automatically from the DHCP • Manual lets you configure related settings server. Once the network settings have been retrieved, manually. Configure IP Address, Prefix Length, the NVR’s current IP address is displayed in the IP Gateway, and DNS Server settings manually using Address field.

  • Page 67: Vin

    Part 2 - Configuration If the camera is networked but not scanned, use this setup. This setup allows you to change the network setting of the NVR’s VIDEO IN port which is camera’s network environment. Check the camera’s network setting first before you use this setup. •...

  • Page 68: Fen

    Part 2 - Configuration When registering nvr with the Idis mobile application, you can easily enter the IP address by using the QR code. If using a dynamic IP address, FEN service makes it easy to connect to the NVR from a remote program without having to configure dynamic IP or router settings.

  • Page 69: Firewall

    Part 2 - Configuration Notification Setup Firewall Setting up a customized firewall rule set, it allows or denies access such as specific MAC address, IP address and receiving network port of the NVR. Schedule Select the + icon at the lower left corner of the screen to add a notification schedule.

  • Page 70: Callback

    Part 2 - Configuration Callback ● Max. Queue Size : Determine the maximum number that can be processing events. You can limit from 300 to 1000 queues. For more information on Callback Configure Callback settings. Retry Policy, refer to the graph below. Enter the IP address of the receiving server and set Retry to between 1 and 10 in case of connection failure.

  • Page 71: Mail

    Part 2 - Configuration Mail SMTP Setup Select SMTP Setup at the bottom right corner of the Configure Mail settings. screen to configure an SMTP server. Select the SMTP server Type. Enter the SMTP Server’s IP address or domain name and then configure the Port and Sender settings.

  • Page 72: Push

    Part 2 - Configuration Push Attach Type Setup Configure Push settings. ● Encoding (File name): Set the encoding for the name of the attached files to BASE64 or PLAIN-TEXT. Select Push to use Push feature. ● Priority: Set the stream video for email and FTP The Push feature sends out event-related messages to attached files to Main Stream or Sub Stream.

  • Page 73: Display Setup

    Part 2 - Configuration Display Setup ● Address: Enter the address of HTTP notifications. ● Path: Enter the path of HTTP server address. Refer to the Menu Use on page 29 for basic ● User / Password: Enter the user and password to information on using the Setup menus.

  • Page 74: Main Monitor

    Part 2 - Configuration Status Setup ● Freeze & Sequence: Displays freeze and sequence icons. ● Screen Group: Displays the current screen's group. Refer to the Menu Use on page 29 for basic information on using the Setup menus. Main Monitor Camera Configure monitor-related settings.

  • Page 75: Device

    Part 2 - Configuration Device System This screen displays an overview of device events. This screen displays an overview of system events. When an event occurs, the corresponding channel When an event occurs, the corresponding channel flashes for 5 seconds. flashes for 5 seconds.

  • Page 76: Storage

    Part 2 - Configuration Storage A disk that has never Formatted been used before. Indicates each disk's status. ● Disk performing normally. ● If the HDD is partially Good damaged, indicates the bad sector Disk Bad percentage. ● If the HDD's bad sector ratio is higher than as designated Error...

  • Page 77: Network

    Part 2 - Configuration Network indicates the camera is connected. indicates the This page provides a complete overview of the network camera is not connected. Clicking Camera status in real-time. the image displays the camera's Connection channel number. Clicking the image displays status information of the device connected to the NVR.
  • Page 78 Part 2 - Configuration Indicates whether there are clients connected to the NVR via an external network and how many Number of Connected clients are connected. Clients indicates at least one client is connected. indicates no client is connected. Indicates network connection statuses (connected, connecting, disconnected, and connection error) using following lines:...

  • Page 79: Part 3 - Search

    Part 3 - Search Time-Lapse Search Search by changing Time-Lapse Search and Event Log Search. While in Live mode, select the Search Mode icon and select Time-Lapse Search, or Event Log Search. Search Menu 1 Layout Used to change the screen layout to single screen, 1x2, corridor format or 2x2.

  • Page 80: Context Menu

    Part 3 - Search to adjust the playback speed. Releasing the mouse • Farther back the data is on the record table, the button returns the vertical indicator to the center and more recent it is. stops video playback. • If the system's clock is changed to a previous date ●...

  • Page 81: Clip Copy

    Part 3 - Search ● Use Site Info: Adds Site info to the Clip Copy file’s Clip Copy name. Special characters contained in the location info (such as \, /, :, ;, *, ?, !, “, <, >, and |) will be replaced Clip Copy with _ when the information is added to the file name.

  • Page 82: Event Log Search

    Part 3 - Search Event Log Search ● Use event filters to include/exclude specific system events such as Panic Record, Check Recording, Disk Almost Full, Disk Bad, Disk Temperature, Disk Select Search Mode > Event Log Search to bring up S.M.A.R.T., and Disk Config Change from the search.

  • Page 83: Overlapped Recording Search

    Part 3 - Search Overlapped Recording Search If the system’s clock is changed to a point in the past, overlapping recordings may be produced. Overlapped recordings have to be searched in segments. For example, making a recording from 1 o’clock to 5 o’clock, changing the system’s clock at 5 o’clock to 3 o’clock, and then continuing to record until 6 o’clock produces two recordings that overlap between 3 o’clock...

  • Page 84: Memo

    Part 3 - Search Memo V8.2...
  • Page 85 IDIS Co., Ltd. For more information, please visit at www.idisglobal.com...
