Installing The B602 System On The Helmet - Nolangroup N-Com R Series Manual

EN
Prior to installing the N-Com system, remove any filling foam material, if present, from the helmet
•
(refer to the user manual for your specific helmet).
Option 1
N.B.: Keep the filling material in case you wish to use the helmet without the N-Com system in the
future.
3.3.

Installing the B602 system on the helmet

Fig. 5
Fig. 6
10
Option 2
• Hook up the microphone connector (blue) to
the other end, following the directions of the
arrows (Fig. 5).
N.B.: You can adjust the position of the
microphone. For instructions on how to do this,
please see chapter. 3.4.
• Insert the left-hand cable (attached to the
keypad) into the port, as shown (Fig. 6).
