Ercol Ancona 5152 Quick Start Manual

Console table

5152 Ancona Console Table

Thank you for purchasing this Ancona console table, Please read the instructions carefully before use to ensure

safe and satisfactory operation of this product.

This item is HEAVY

Pre-assembly preparation

Please ensure instructions are read in full before attempting to assemble this product

Please check the pack contents before attempting to assemble this product. A full checklist of components is

given in this leaﬂet. If any components are missing, please contact the retailer from whom you bought this

product.

This product is HEAVY, it should be assembled as near as possible to the point of use. TAKE CARE WHEN

LIFTING to avoid personal injury and (or) damage to the product.

This product takes approximately 30 MINUTES to assemble with 2 PEOPLE.

The fittings pack contains SMALL ITEMS which should be KEPT AWAY FROM YOUNG

CHILDREN.

Necessary Tools

Ref: 00237/5152

Table of Contents

Do you have a question about the Ancona 5152 and is the answer not in the manual?

Page 1 5152 Ancona Console Table Thank you for purchasing this Ancona console table, Please read the instructions carefully before use to ensure safe and satisfactory operation of this product. This item is HEAVY Necessary Tools Pre-assembly preparation Please ensure instructions are read in full before attempting to assemble this product Please check the pack contents before attempting to assemble this product.
Page 2 Fittings and parts checklist M5 Allen key x 1 Top panel x 1 8*50mm Bolt x 8 Shelf panel x 1 6*45mm Bolt x 8 Side legs x 2 Front&Back legs x 2 Half moon washer x 8 8*25mm Bolt x 8 Cross rail x 2 M4 Allen key x 1...
Page 3 Step by step assembly instructions Insert the legs (C) onto the edges of connection cross rails E(Length direction) and insert the legs (D) onto the edges of connection cross rails E(Width direction)as shown below. Using the M4 Allen key (F) to fix the 8pcs 6*45mm bolts (I) and 8pcs half moon washer (J) on the legs and cross rails so that they are completely immobilized as shown below.
Page 4 (E). Assembly completed and put the console table up. Fittings K * 8 H * 8 Using 8*25 bolt（K ） PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE Ercol Furniture Ltd, Summerleys Road, Princes Risborough, Buckinghamshire. HP27 9PX www.ercol.com...
