Control Button - HOMCOM 800-102V80 Assembly & Instruction Manual

• Before using this product for the first time, please clean and dry the stainless
steel stir sticks, pasta sticks, whisks, measuring cups, and cutting cup
containers.；
• When using this appliance for the first time, you may notice a strange smell from
the motor. This is normal and the smell will disappear as the motor runs.。
Warning：Do not plug the power cord into a power outlet until the stainless steel
stir bar, stir noodle stick, double egg fork, lantern stick, and vegetable cup
container are fully installed in the host; "OFF" position.

CONTROL BUTTON

• Release button – release dough hooks,double beater,whisk。
• Press button1-5,you can adjust the speed of dough hooks,double beater,whisk.
• "L","H"button is used for blender and chopper,press pulse can start working.
Assemble asseccories
• enssure the plug is off of power.
• Ensure the speed button is on 0 position.
• Insert the corresponding accessories into the correct mounting holes .
Each pair of whisks and noodle bars has a large-diameter meson, while the other
does not have a meson; make sure to insert the opposite hole when installing the
appliance (Figure 1).
When installing the stainless steel stirring rod, turn the baffle apart, insert
the accessor y counterclockwise into the hole, and check whether it is
installed in place (Figure 2)
You can then stir the stir bar with the food in a measuring cup. (Figure 3)
Double
surface
Hole is big
Fig.1
3
beater,hook with
