(D "COM" jack
Plug in connector for black (negative) test lead.
@ "VOmA" jack
Plug in connector for red (positive) test lead for voltage,
resistance and current (except 1 OA) measurements.
® "10A" jack
Plug in connector for red test lead for1 OA measurement.
@ red LED
Non-contact voltage detection indicator.

3.2 GENERAL

Maximum voltage
between input and the
ground
Fuse protection
Power
LCD 2000 counts ,updates 2-3/sec
Display
Dual-slope integration AID converter
Measuring method
Only figure "OL" on the display
Over range Indication
Polarity indication "-"displayed for negative polarity
Operating Environment
Storage temperature
Low battery indication
Size
Weight
CATlll 600V
F1: FF 400mA H 600V
F2: FF 1 0A H 600V
9V battery, NEDA 1604 or 6F22
° °
0 c to 40 C
° °
-10 c to 50 C
"E!l"appears on the display
1 40mmx67mmx30mm
Approx.112g.
09
4.0PERATING INSTRUCTIONS

4.1 DC/AC voltage measurement

1.Connect the red test lead to the "V.O.mA" jack and the
black lead to the "COM" jack.
2.Set rotary switch at desired DCV/ACV position. If the
voltage to be measured is not known beforehand, set
range switch at the highest range position and then
reduce it until satisfactory resolution is obtained.
3.Connect test leads across the source or load being
measured.
4.Read voltage value on the LCD display along with the
polarity of the red lead connection
&warning
To avoid harms to you or damage to the meter from
electric shock.Please do not attempt to measure
voltage higher than DC/AC 600V although readings
may be obtained.AC Frequency range:40Hz to
400Hz.Response:Average responding,calibrated in
rms of a sine wave.

4.2 DC/AC current measurement

Overload Protection:400mA/600V fuse.10A/600V fuse.
1.Connect the red test lead to the "V.0.mA" jack and the
black test lead to "COM" jack. (For measurements
between 200mA and 1 OA,remove red lead to"10A" jack.)
2.Set the rotary switch at desired DCA/ACA position.
3.0pen the circuit in which the current is to be measured,
and connect test leads in series with the circuit.
4.Read current value on LCD display along with the
polarity of red lead connection.
