eXplorist 600 GPS Receiver

Button Descriptions:

On/Off
Backlight
ENTER
ESCAPE
ZOOM IN
ZOOM OUT
MENU
NAV
MARK
GOTO
Arrow joystick
Turns the eXplorist on or off.
Turns the display backlight on. Sequences from off to low to high
intensity.
Used to access highlighted menu items or accept highlighted
buttons.
Cancels data inputs.
Closes the accessed function and goes back to the last viewed
screen.
Steps backward through the navigation screens.
Used on the Map screen to zoom in on the map displayed. The
map display can be zoomed in to 100 ft. (35.0 m).
Also used to quickly step through the list of POIs when doing an
alphabetical search.
Used on the Map screen to zoom out on the map displayed. The
map display can be zoomed out to 1700 mi (2700 km).
Also used to quickly step through the list of POIs when doing an
alphabetical search.
Brings up a menu with available options. Options can be selected
by using the arrow joystick to highlight the option and pressing
ENTER to access it.
Steps through the navigation screens. (Map screen > Compass
screen > Position screen > Satellite Status screen)
Used to save your present position as a point of interest. Points of
interest that you save are stored in the My Points of Interest portion
of the database.
Creates a one-leg route from your present position to a destination
selected from the Points of Interest database or by using the cursor
on the background map.
Pans the cursor on the Map screen.
Moves the highlight bar to select menu options and data-entry
fields.
