- Page 1 MODVAR Low voltage reactive power compensation modules Installation manual...
-
Page 2: Inspection On Receipt
− MODVAR module is not damaged. − Minimum: -40°C / -40°F − Any loss or damage should be notified immediately to your − Maximum: 75°C / 167°F nearest ABB agent. 3 ABB Instruction manual | MODVAR Low voltage reactive power... - Page 3 2. Fuse and fuse base 5. Cables (not shown) 6. Discharge resistors 3. Contactor 7. Capacitors Figure 3.2: MODVAR segregated (reactor and capacitors are mounted on separate trays to reduce thermal stress on capacitors) MODVAR Low voltage reactive power | ABB Instruction manual 4...
- Page 4 MODVAR Low voltage reactive power compensation modules 3.1 MODVAR dimensions 300mm 575mm 455mm 472mm Figure 3.3: MODVAR dimensions 575mm R W B 8mm fixing holes 455mm Figure 3.4: MODVAR dimensions 5 ABB Instruction manual | MODVAR Low voltage reactive power...
-
Page 5: Mechanical Installation
MODVAR modules must be fixed horizontally so as to allow airflow circulation (see blue arrows in the figure below). MODVAR modules must be fixed on a rigid frame with two M6 screws (not provided). Make sure that the rigidity of the support and the screws are sufficient to bear the weight (about 50 kg) of the MODVAR module(s). - Page 6 Air should flow from the bottom to the top of the cubicle as illustrated on the opposite picture. One fan per 6 MODVAR columns blowing a minimum air flow of 525 m³/h is necessary. Design guideline The difference between ambient temperature outside the cubicle and measured temperature must be lower than 10°C.
-
Page 7: Electrical Installation
− Qn - reactive power output in kvar − Vn - line voltage, phase-to-phase The temperature around the cables must also be considered according to cable manufacturer. Figure 4.3: MODVAR electrical connection diagram MODVAR Low voltage reactive power | ABB Instruction manual 8... - Page 8 (provided). Suitable for use with up to 30 x 10mm bus dimensions as well as the additional inductance in case bar. of inrush current peak. 9 ABB Instruction manual | MODVAR Low voltage reactive power...
-
Page 9: Maintenance
Please ensure that your installation is as per the over current rating according IEC 60831 standards. Contact ABB for technical support. MODVAR Low voltage reactive power | ABB Instruction manual 10... -
Page 10: Technical Specifications
Overvoltage tolerance: 10% for maximum 8h in every 24h and 30% for maximum 1min (according to IEC 60831) Maximum permissible current: 1.3x In. Altitude Up to 1000m Compliance IEC 60831 part 1 & 2 CE marked Cooling Forced air cooling:120cm 11 ABB Instruction manual | MODVAR Low voltage reactive power... - Page 11 S/N: After disconnecting from supply, wait 2 min and check for absence of residual voltage before handling the parts Made in Australia Figure 8.1: Typical label of a MODVAR module MODVAR Low voltage reactive power | ABB Instruction manual 12...
- Page 12 © Copyright 2013 ABB. Power Products Division All rights reserved. 88 Beresford Road Lilydale VIC 3140 ABB is working continuously to improve Phone: +61 3 9735 7333 our products. We therefore reserve the Fax: +61 3 9735 3863 right to change designs, dimensions E-mail: lv.powerquality@au.abb.com...
