AT-AT-AT
Page 1
Eurorack DIY Kit Instructions
AT-AT-AT Triple Passive Attenuator

OVERVIEW

For the most recent version of this
document please visit
https://www.thonk.co.uk/shop/at-at-at/
All Thonk kits are sold under our
standard
Terms
and
Conditions
-
http://www.thonk.co.uk/faq/

DIY INSTRUCTIONS

This document gives detailed instructions that assume you have purchased a
complete kit from www.thonk.co.uk. It also assumes no previous knowledge of
electronics. To learn to solder try
https://youtu.be/IpkkfK937mU
and the Adafruit
guide to excellent soldering –
bit.ly/1l77tF4
Watch and understand that whole YouTube video! If you're not achieving the results
You will not
shown in the video then you need to buy new tools or seek advice.
end up with a working module otherwise.

TOOLS REQUIRED

Soldering iron, snipe nose pliers, wire strippers, small flat head screwdriver and
diagonal cutters AKA snips AKA side-cutters. A Digital Multimeter is always helpful
for checking for bad solder joints and continuity. Thonk sell a range of inexpensive
tools here -
http://bit.ly/1jxqF3n
April 2022
Version 2.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AT-AT-AT and is the answer not in the manual?

Questions and answers

Related Manuals for Thonk AT-AT-AT

Summary of Contents for Thonk AT-AT-AT

  • Page 1 Soldering iron, snipe nose pliers, wire strippers, small flat head screwdriver and diagonal cutters AKA snips AKA side-cutters. A Digital Multimeter is always helpful for checking for bad solder joints and continuity. Thonk sell a range of inexpensive tools here - http://bit.ly/1jxqF3n...
  • Page 2 AT-AT-AT Page 2 Eurorack DIY Kit Instructions SOLDER JOINTS Your solder joints should look like those shown as ‘OK’ below, they should have that neat conical shape on BOTH sides of the PCB. If they don’t look the same on both sides then stop! Work out why from the soldering guides linked and don’t continue...
  • Page 3 AT-AT-AT Page 3 Eurorack DIY Kit Instructions AT-AT-AT BUILD INSTRUCTIONS Start by finding the single 10-pin header and break this into three separate 3-pin headers. Place and solder each header so they sit on the back of the PCB in the LIN/LOG positions as shown.
  • Page 4 AT-AT-AT Page 4 Eurorack DIY Kit Instructions For the next step place the three B100K pots and six jack sockets into position shown DON’T SOLDER ANYTHING YET. Place the panel on the front of the module and then add the nuts and washers to all pots and jacks to hold everything in place.
  • Page 5 AT-AT-AT Page 5 Eurorack DIY Kit Instructions Check the components are sitting flush between the panel and PCB, and then flip the module over and solder all the pins for the pots and jacks on the back of the PCB.
