- Page 1 ENGLISH ENGLISH ENGLISH ENGLISH Installation and User Manual version 1.00 ADPEW200 In ADPE explosion proof box...
- Page 2 No guarantee is applicable on returned products without the original label and/or serial number. No guarantee against misuse. Batteries: Laumas provides 1 year guarantee from the date of delivery note, against material defects or battery manufacturing faults. DISPOSAL...
-
Page 3: User Warnings
USER WARNINGS RECOMMENDATIONS FOR THE PROPER USE OF WEIGHING INSTRUMENT Keep away from heat sources and direct sunlight Repair the instrument from rain (except special IP versions) Do not wash with water jets (except special IP versions) Do not dip in water Do not spill liquid on the instrument Do not use solvents to clean the instrument Do not install in areas subject to explosion hazard (except special Atex versions) -
Page 4: Recommendations For Correct Installation Of The Load Cells
RECOMMENDATIONS FOR CORRECT INSTALLATION OF THE LOAD CELLS INSTALLING LOAD CELLS The load cells must be placed on rigid, stable in-line structures; it is important to use the mounting modules for load cells to compensate for misalignment of the support surfaces. CONNECTING SEVERAL CELLS IN PARALLEL Connect several cells in parallel by using - if necessary - a watertight junction box with terminal box. - Page 5 EARTHING THE WEIGHED STRUCTURE By means of a copper wire with suitable cross-section, connect the cell upper support plate with the lower support plate, then connect all the lower plates to a single earthing system. Electrostatic charges accumulated because of the product rubbing against the pipes and the weighed container walls are discharged to the ground without going through or damaging the load cells.
- Page 6 W200 weight indicator, provided in one of the following models: W200 BASE, W200 LOAD, W200 UNLOAD, W200 MULTI, W200 3-6-14 PRODUCTS (see enclosed manual). WARNING: ADPEW200 is not compatible with NTEP approved instruments. ATEX [EEx ia] certified barriers (dimensions: 105x12,6x82 mm, mounting on standard...
-
Page 7: Electrical Connections
ELECTRICAL CONNECTIONS Warning! For electrical connections and power supply of the instrument refer to the wiring diagram of the specific instrument manual. SAFE HAZARDOUS AREA AREA REF - REF- EX - REF + 7766Pac Load SIG - SIG - SIG + cells 7761ac SIG +... - Page 8 ELECTRICAL CONNECTIONS BETWEEN LOAD CELLS AND JUNCTION BOX Connect the load cells by means of a terminal board housed inside an ATEX certified junction box, connecting together wires of the same colour; the same procedure applies to the shields, keeping them separate from the earthing system and connected metal parts.
-
Page 9: Declaration Of Conformity - Eu
Niniejszym oświadczamy, że produkt, którego niniejsze oświadczenie dotyczy, jest zgodny z Deklaracja zgodności poniższymi normami. Заявление о Мы заявляем, что продукт, к которому относится данная декларация, соответствует соответствии перечисленным ниже нормам. Models: ADPEW200 Mark Applied EU Directive Standards Not Applicable (N/A) for VDC type 2014/35/EU EN 61010-1:2010+A1:2019... - Page 10 Niniejszym oświadczamy, że produkt, którego niniejsze oświadczenie dotyczy, jest zgodny z Deklaracja zgodności poniższymi normami. Заявление о Мы заявляем, что продукт, к которому относится данная декларация, соответствует соответствии перечисленным ниже нормам. Models: ADPEW200 Mark Applied UK legislation Standards Not Applicable (N/A) for VDC type Electrical Equipment BS EN 61010-1:2010+A1:2019...
- Page 12 On our website www.laumas.com you can find videos on the correct installation of weighing systems and tutorials on the configuration of our weight transmitters and indicators. Comprehensive user manuals for all LAUMAS products can be found online. They can be downloaded in PDF format from either the Products section or the Download Area of the website www.laumas.com.
