- Page 1 ENGLISH ENGLISH ENGLISH ENGLISH Installation and maintenance instructions version 1.00 CASTLM8I3A CASTLM8I...
- Page 2 - tampering, deletion, removal of the identification label and/or serial number of the product - misuse, transformation, alteration, repair of products not carried out by Laumas personnel Laumas provides a 1-year warranty from the date of the delivery note on defects in material or manufacture of the battery. GUIDELINES FOR PROPER DISPOSAL...
-
Page 3: Table Of Contents
TABLE OF CONTENTS USER WARNINGS ......................... 1 PARTS IDENTIFICATION ...................... 2 TECHNICAL SPECIFICATIONS .................... 3 INSTALLATION ........................3 OPTIONS ..........................5 STAFFETLM8I / STAFFETLM8IEX ..................5 SANITIZATION AND MAINTENANCE (CASTLM8I3A) ............6 SANITIZATION ......................... 6 MAINTENANCE ........................6... -
Page 4: User Warnings
USER WARNINGS RECOMMENDATIONS FOR THE PROPER USE OF WEIGHING INSTRUMENT Keep away from heat sources and direct sunlight Do not dip in water Do not install in areas subject to explosion hazard The following table shows the material of the instrument components exposed to external agents: COMPONENT MATERIAL DETAILS... -
Page 5: Parts Identification
PARTS IDENTIFICATION 1. Back shell. 2. Front shell. 3. Nuts M5. 4. Cable glands. 5. Hygienic seal. 6. Plugs M12. 7. Keyboard. 8. Fixing plates. Installation supports. - 2 -... -
Page 6: Technical Specifications
TECHNICAL SPECIFICATIONS HUMIDITY (non condensing) CASTLM8I: IP68/IP69K (optional) PROTECTION RATING CASTLM8I3A: IP68/IP69K STORAGE TEMPERATURE (INTERNAL TLM8) -30°C +80°C WORKING TEMPERATURE (INTERNAL TLM8) -20°C +60°C INSTALLATION - PRELIMINARY OPERATION: make an opening on the panel as shown in the figure; - insert the instrument into the opening;... - Page 7 - tighten the screws of the supports until they are flush; - when the stop is reached, tighten the screws of the supports until the seal is firmly pressed on the panel; - check that all screws are properly tensioned. - 4 -...
-
Page 8: Options
OPTIONS STAFFETLM8I / STAFFETLM8IEX Instrument CASTLM8I Optional: kit for front panel mounting. - remove the first row of cable glands; - screw the M12 plugs on; - proceed as described in the INSTALLATION section. - 5 -... -
Page 9: Sanitization And Maintenance (Castlm8I3A)
SANITIZATION AND MAINTENANCE (CASTLM8I3A) SANITIZATION 1) Perform a first rinse with water at a maximum temperature of 40 °C. 2) Distribute an alkaline detergent at a maximum temperature of 100 °C and leave it to act for about 10 minutes, respecting the supplier's concentration specifications. - Page 12 On our website www.laumas.com there are videos on the guidelines for correct installation of weighing systems and video tutorials on configuring our transmitters and weight indicators. All Laumas product manuals are available online. You can download the manuals in PDF format from www.laumas.com by consulting the Products section or the Download Area.
