- Page 1 USER MANUAL Home VS ASIN AQUA ® 2021 CUTTING EDGE TECHNOLOGY FOR CRYSTAL CLEAR AND HEALTHY POOL WATER INTEGRATED VS PUMP CONTROL www.asekopool.com...
-
Page 2: General Safety Information
General safety information This user manual contain basic information that should be observed during assembly, start-up, operation, and maintenance. Therefore, this user manual must be read by installers and operators prior to assembly and start/up, and must be accessible to every user of this unit. Additionally, all further safety information in this document absolutely must be observed. - Page 3 The chemicals used with the ASIN Aqua must be handled in a safe manner to prevent damage or personal harm. Aseko recommends you always use personal protective safety equipment when handling the pH and chlorine agents. Refer to the Materials Safety Data Sheet (MSDS).
- Page 4 What do you receive in your box Water thermometer with housing #13192 Device ASIN AQUA Home Probe housing 2 pcs #13013 Peristaltic pumps #12093 Flowmeter with filter #12106 CLF probe Redox probe Long Life pH probe Long Life #12052 # 12016 # 12012 Water valves 2 pcs #12006 Injection valve 4 pcs #12005...
-
Page 5: Available Optional Accessories
Photometer pH 7.00 Buffer #12065 Redox Air thermometer 1/4” threaded #12134 # 13076 Buffer #12063 #13192 ASEKO original chemical solution 20 l volume for pools CHLORPURE #12075 pH MINUS #12130 pH PLUS #12120 ALGICID #12156 FLOC+C #12139 5 l volume for whirlpools... - Page 6 Highly effective disinfection treatment of pool water for public and private pools. Extraordinary precise measuring of chlorine content in the pool water by ASEKO CLF - free chlorine probe combined with the system digital intelligence is able to control the preset disinfection level by usage of minimum necessary chemical aids.
-
Page 7: Freeze Protection
Pool management functions Filtration Time Control Daily, automatic start of the filtering for individually preset periods. Water Level - Refilling Water level can be monitored by optional level sensor. System can be individually programmed to control up to four different water levels at your pool and switch the water refilling or waste water draining on/off (this requires an optional Besgo valve for automatic backwashing). - Page 8 ASIN AQUA Home Installation ASIN AQUA Home is to be wall-mounted in a dry and dust-free environment with temperatures ranging from +5 °C to +40 °C. Install the mounting rail to attach ASIN AQUA Home to the wall. Choose the 40 °C location so that there is a free space of at least 40 cm in all directions and CHLORINE...
-
Page 9: Installing The Probes
Installing the Probes Carefully insert the pH, CLF or REDOX probe into the housing. Hand tighten or use the attached plastic wrench socket for probes. Connect the connector and lock it by tightening a connector ring. After probes have been inserted, slightly tightened and connectors have been connected, ASIN AQUA Home is ready for connection to the water system of your pool. - Page 10 OUTPUT CHLORINE ALGICID FLOCC INLET MEASURED WATER SUPPLY MEASURED WATER DRAINAGE...
- Page 11 Pool Water Connection Water valve fitting The pool water to be measured must be brought to the ASIN AQUA probes. We place the shut-off valve in the plug D = 50 with thread G1 / 4 “# 12134, glued to the T-piece. Tighten by hand only. Do not use pliers or other Plug with tools.
- Page 12 CHLORINE ALGICID FLOCC Max 8 m FLOC+C...
- Page 13 Pool Chemicals Connection Plug with Screw the injection valves into the plug D = 50 with thread G1 / 4 “# 12134, D = 50 with glued to the T-piece. Tighten by hand only. Do not use pliers or other thread 1/4“...
-
Page 14: Accessories Connection
Accessories Connection POWER SUPPLY ZDROJ NAPÁJENÍ 230 V ~ 50 Hz 230 V ~ 50 Hz RELAY 230 V, MAX 1 A 230 V relé Solenoid Solenoid valve dopuštění filling max 1A Besgo valve 5W Besgo 5 W Filter backwash Praní... - Page 15 VS pump connection WARNING Always check the connection according to the current user manual of your pump manufacturer. Speed TYP A TYP B TYP C STOP STOP Relay status HAYWARD (older type) TYP C TYP A Speed 3 Speed 2 SPECK TYP A UWE EO PM...
-
Page 16: Power Supply
Power Supply Connection to the mains: Leave the mains switch in the off position. Connect the filtering device to the ASIN AQUA Home switched socket Installation must be outlet (filtration power supply - max. 1.4 kW / 230 VAC). protected by a residual Connect the 230 V / 50 Hz mains cable to ASIN AQUA Home (on the right current device (RCD). -
Page 17: Installation Test
Installation Test WARNING: Any obstacles, bubbles or leaks in the connecting tube will prevent ASIN AQUA Home from correct operating. The clear plastic tube allows you to monitor flow of liquid to the injecting valves. Before commencing the operation, test ASIN AQUA Home installation. Most problems result from incorrectly performed installation. -
Page 18: Touch Screen Description
Touch screen description Main Screen The basic screen display measured, required values and status information. E.g. click on the Chlorine tab to enter the setting of the required chlorine value in pool water. Required Value. Measured Value. The chlorine pump status – ON. ON indicates the ON - filtering follows Enter settings. - Page 19 Settings Back to the main screen. Displays help/manual for Back to the previous the particular screen. screen. Movement through Menu Movement in menu to the previous page. ON - function is switched on Indicator of the current page and the total number of pages.
- Page 20 Configuration Date and Time To ensure the correct function of timers, set the current date and time. Pool Volume To ensure the correct function of ASIN AQUA Home, enter the correct volume of your. Calculate your pool volume in m Length (L) times width (W) times depth (D) is volume (V) - (L × W × D = V).
- Page 21 Smart Heating Water Temperature Measurement and Heating Control The high-accuracy electronic thermometer is used to measure water temperature. This should be installed to the inlet pipe coming from the pool. Never mount it downstream of the heat exchanger. Significant distortion of temperature occurs.
- Page 22 Wintering To enable the function, it is necessary to install outdoor air thermometer. • After the freeze protection has been enabled, ASIN AQUA Home checks outdoor temperature. If outdoor temperature is lower than 0 °C, filtration is switched on to circulate the pool water. After 15 minutes will ASIN AQUA Home measure temperature of the pool water.
- Page 23 VS variable pump control In the settings, select the type of your variable speed variable pump. ASIN Aqua Home VS allows you to use 3 speeds of your VS pump. Speed 1 (LOW) for economical filtration outside the TIMER. Speed 2 (MEDIUM) for filtering during set times.
-
Page 24: Commissioning Procedure
Choosing the disinfection probe CLF free hlorine probe Free chlorine measurement, CHLOR PURE dosing Redox probe of the RX potential Measurement of redox potential, CHLOR PURE dosing Commissioning procedure and required value setting Commissioning procedure The water in the pool must be clean without any additives. Ideally fill the pool with fresh water from the water main. - Page 25 Wait at least 1 hour. Optimally up to 24 hours Before opening the water supply to the probes, the water must be clean and the chlorine concentration measured by the colorimeter or Pool Tester must be within the range 0.3 to 1.2 mg/l. If the concentration is lower, repeat superchlorination.
- Page 26 If you use the CLF probe For the correct functionality of the CLF probe you must observe the following conditions: pH of the pool water The ideal pH value should be between 6.8 and 7.5. The pH of the pool water must be stabilized. If the pH value fluctuates, the value of the chlorine in pool water changes accordingly.
-
Page 27: Fine Tuning
If you use the Redox probe For the correct functionality of the REDOX probe, you must observe the following conditions: pH of the pool water The ideal pH value should be between 6.8 and 7.5. The pH of the pool water must be stabilized. If the pH value fluctuates, the value of the Redox changes accordingly. -
Page 28: Safety Functions
Safety Functions Maximum Number of pH Doses - without Probe Response If the measured pH value does not change even after preset quantity of doses (according to the settings), ASIN AQUA Home stops pH dosing and an error message appears on the display. The other ASIN AQUA Home functions are not limited. -
Page 29: Ph Probe Calibration
In Operation Measurement and Calibration pH Probe Calibration Do not calibrate the pH When pH is being measured in operation, there may be a difference between probe at a pH difference the ASIN AQUA Home value and the current pH value measured directly in lesser than 1. - Page 30 CLF Probe calibration Do not calibrate the probe until the water in the pool is thoroughly mixed and the value on the ASIN AQUA Net display is stable. This may take several hours. Calibration is performed by entering the manually measured value of chlo- rine concentration (using a photometer) in the CALIBRATION menu.
- Page 31 Water Thermometer Calibration If water temperature is different from temperature shown by ASIN AQUA Home, calibrate the thermometer in the water thermometer calibration menu. Air Thermometer Calibration If air temperature is different from temperature shown by ASIN AQUA Home, calibrate the thermometer in the air thermometer calibration menu.
-
Page 32: Maintenance
Maintenance #12073 Replacement hose for the pump PP 60 To ensure the optimum efficiency, perform visual checks and maintenance of ASIN AQUA Home on a regular basis. Pump Hose Replacement To prevent the pump from failing, it is recommended to replace the hose #12073 every 24 months. - Page 33 There is no manufacturer of pH and REDOX probes that cover its products with warranty. ASEKO has decided to cover supplied probes to its clients by two year warranty period that cover free repair of supplied probe that will have higher tolerance than above described.
-
Page 34: Error Messages
Error messages This error message This error message appears after appears after 15/30 15/30/60 doses doses of pH without of chlorine without probe reaction. probe response. This error message appears when the set maximum chlorine dose is exceeded. Those error messages appear when: Agent Run Out No Water Flow to Probe •... - Page 35 Too Rapid pH Change Too rapid change of pH is usually caused by refilling water directly to the skimmer. If such rapid change of pH occur, ASIN AQUA Home stops controlling pH for two hours. This limitation can be manually disabled. After pH has been stabilized or two hours have elapsed, ASIN AQUA Home changes over to the normal mode.
-
Page 36: Internet Connection
The LAN connector is to be connected to the domestic router. Data are sent in the intervals of 10 seconds to the address pool.aseko.com, the route must not be blocked by the firewall. Connection of ASIN AQUA Home to your LAN is not complicated. You just need some basic IT skills. - Page 37 INTERNET Home network INTERNET 3G / LTE WIFI EXTENDER Wifi extender INTERNET Powerline via 230 V 230 V socket outlet INTERNET...
-
Page 38: For Android
Live application to your smartphone. Application is available for iOS and Android operation systems. Main screen after opening will ask for typing your ASIN AQUA Home serial number. If you have more pools equipped by the ASEKO NET adapter you can load all of them to one application. Pool LIVE... - Page 39 The web application for detailed monitoring of the pool water quality by means of well-arranged graphs. It shows all the measured parameters as well as ASIN AQUA Home actions up to 30 days back. This application is giving you the detailed information of the pool status and detailed review of all events, taken actions and act levels of monitored items up to 30 days back.
- Page 40 Besgo 3 W Besgo 3 W Besgo 3 W Dnová výpust Dnová výpust Dnová výpust Externes Touchscreen Display Topení Topení Topení Bezpotencionální Bezpotencionální Bezpotencionální relé relé relé The external display shows Bez funkce Bez funkce Bez funkce 1. Pool water parameters: Speed 3 Speed 3 Speed 3...
- Page 41 (turbidity) to larger particles that can be removed by filtering. ASEKO Pool & Spa Floc + c A unique mixture of coagulant and flocculant for increasing the efficiency of the filter. The coagulant neutralizes the zeta potential, which keeps impurities dispersed into a fine turbidity.
- Page 44 USER MANUAL ASIN AQUA Home VS www.asekopool.com...
