SOR 1710 General Instructions Manual

®
The SOR Type 1710 Electric Level Detector is a horizontally mounted, float-operated level
detector. The Type 1710 is suitable for plant and OEM applications where open or closed
contacts are required to signal the presence or absence of liquid at a discrete level.
When the liquid rises, the float extension arm moves a magnet that repels an internal
magnet de-actuating a microdetector. When the liquid level falls, the float extension arm
moves in the opposite direction, actuating the microdetector (See
recommended for use in clean liquids only.
NOTE: If you suspect that a product
is defective, contact the factory or
the SOR Representative in your
area for a return authorization
number (RMA). This product should
only be installed by trained and competent personnel.
Microdetector
Design and
specifications are
subject to change
without notice.
For latest revision, go to
www.sorinc.net
Form 916 (08.12) ©2012 SOR Inc.
Electric Level Detector
petent personnel
Liquid presence
NO = closed
NC = open
Microdetector
Magnets
Electrical Connection ...........................2
SIL Installation ..................................2
Dimensions ......................................3
Maintenance .....................................4
Troubleshooting .................................4
Replacement Detector Assemblfies .........5
ATEX Marking Details ..........................5
Declaration of Conformity .....................6
Registered Quality System to ISO 9001:2008
Side-Mount
Type 1710
General Instructions
). The 1710 is
Magnets

Table of Contents

Liquid absence
NO = open
NC = closed
1/8
