Summary of Contents for Netafim GYRONET TURBO
- Page 1 GYRONET TURBO MIDI-SPRINKLER USER MANUAL V 002.01 - JULY 2017...
- Page 2 ANY FORM OR BY ANY MEANS, WHETHER ELECTRONIC, MECHANICAL, BY PHOTOCOPYING, RECORDING OR IN ANY OTHER MANNER WITHOUT PRIOR WRITTEN PERMISSION OF THE PUBLISHER. ALTHOUGH NETAFIM™ TAKES THE GREATEST POSSIBLE CARE IN DESIGNING AND PRODUCING BOTH ITS PRODUCTS AND THE ASSOCIATED DOCUMENTATION, THEY MAY STILL INCLUDE FAULTS.
-
Page 3: Table Of Contents
CONTENTS Introduction Use of symbols Aim of this manual Safety instructions GyroNet™ Turbo midi-sprinkler Description Applications Features and benefits Specifications Technical data Performance Max. lateral length - 10% flow variation Sprinkler water trajectory Head loss in riser tube Installation Introduction Various installation configurations Maintenance Checking the swivel (rotor) pin for wear... -
Page 4: Use Of Symbols
INTRODUCTION Use of symbols The symbols used in this manual refer to the following: WARNING The following text contains instructions aimed at preventing bodily injury or direct damage to the crops, the product and/or the infrastructure. CAUTION The following text contains instructions aimed at preventing unwanted system operation, installation or conditions that, if not followed, might void the warranty. -
Page 5: Gyronet Turbo Midi-Sprinkler
For water containing over 2 ppm of sand, a hydrocyclone sand separator must be installed upstream from the main filter. • For water containing over 100 ppm of sand/silt/clay solids, pretreatment must be performed according to the instructions of the Netafim™ expert team. Turbo USER MANUAL 5 GyroNet... -
Page 6: Technical Data
TECHNICAL DATA Performance Sprinkler Lateral Rectangular spacing Spacing - rectangular (m x m) Nozzle Working Wetted 4 x 6 5 x 6 6 x 6 7 x 6 7 x 7 size Color pressure Flow diameter* (mm) code (bar) rate (l/h) Precipitation rate (mm/h) 1.89 Yellow... - Page 7 TECHNICAL DATA Performance (cont'd) Sprinkler Lateral Triangular spacing - isosceles** Spacing - triangular (m x m) Nozzle Working Wetted 4 x 6 5 x 6 6 x 6 7 x 6 7 x 7 size Color pressure Flow diameter* (mm) code (bar) rate (l/h)
-
Page 8: Max. Lateral Length - 10% Flow Variation
TECHNICAL DATA Max. lateral length - 10% flow variation Inlet pressure: 2.5 bar Lateral: 32 mm Lateral: 40 mm ID: 27.2 mm ID: 36.8 mm Nominal Nominal Distance between sprinklers (m) Distance between sprinklers (m) flow rate: flow rate: 200 l/h* 200 l/h* Max. - Page 9 TECHNICAL DATA Max. lateral length - 10% flow variation (cont'd) Inlet pressure: 2.5 bar Lateral: 50 mm Lateral: FlexNet 2" ™ ID: 45.4 mm ID: 51.5 mm Nominal Nominal Distance between sprinklers (m) Distance between sprinklers (m) flow rate: flow rate: 200 l/h* 200 l/h* Max.
-
Page 10: Sprinkler Water Trajectory
TECHNICAL DATA Sprinkler water trajectory A. Distance - Distance of max. trajectory height from sprinkler nozzle. B. height - Elevation of max. trajectory height above ground. Trajectory height above sprinkler nozzle The maximum trajectory height above the sprinkler nozzle is relevant in the following cases: •... -
Page 11: Installation
Assembly must be done gently. Do not overtighten or use excessive force. Various installation configurations Netafim™ sprinklers can be installed at a convenient height in different configurations, to suit the needs of various crops and field conditions. Among the various installation options: •... -
Page 12: Maintenance
MAINTENANCE To assure proper operation of the sprinkler, a simple inspection and maintenance procedure should be carried out regularly. Checking the swivel (rotor) pin for wear Frequency: Before the beginning of each growing season Action: 1. Gently pull the swivel (rotor) up with your fingernail or with a small screwdriver and hold it. 2. -
Page 13: Parts
PARTS GyroNet™ Turbo - head only Model 1 unit 25 units/bag 100 units/bag 64100-002040 64100-002010 64100-002070 64100-003050 64100-003080 64100-004040 64100-004050 64100-004070 64100-004940 64100-006000 Packaging data Units Box size Box weight Boxes Total units Pallet weight GyroNet™ Turbo p/box (cm) (Kg) p/pallet p/pallet (Kg) -
Page 14: Warranty
1 (one) year from the date of purchase. If a defect is discovered during the applicable warranty period, Netafim™ will repair or replace, at its discretion, the product or the defective part. - Page 16 GROW MORE WITH LESS WWW.NETAFIM.COM...
