MEGANET
TM
ROTATING IMPACT
SPRINKLER
USER MANUAL
V 002.01 - JULY 2017

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MegaNet 15D and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Netafim MegaNet 15D

  • Page 1 MEGANET ROTATING IMPACT SPRINKLER USER MANUAL V 002.01 - JULY 2017...
  • Page 2 ANY FORM OR BY ANY MEANS, WHETHER ELECTRONIC, MECHANICAL, BY PHOTOCOPYING, RECORDING OR IN ANY OTHER MANNER WITHOUT PRIOR WRITTEN PERMISSION OF THE PUBLISHER. ALTHOUGH NETAFIM™ TAKES THE GREATEST POSSIBLE CARE IN DESIGNING AND PRODUCING BOTH ITS PRODUCTS AND THE ASSOCIATED DOCUMENTATION, THEY MAY STILL INCLUDE FAULTS.
  • Page 3: Table Of Contents

    CONTENTS Introduction Use of symbols Aim of this manual Safety instructions MegaNet™ rotating impact sprinkler Description Applications Features and benefits Specifications Technical data Performance Max. lateral length - 10% flow variation Sprinkler water trajectory Head loss in riser tube Installation Introduction Various installation configurations Maintenance...
  • Page 4: Use Of Symbols

    INTRODUCTION Use of symbols The symbols used in this manual refer to the following: WARNING The following text contains instructions aimed at preventing bodily injury or direct damage to the crops, the product and/or the infrastructure. CAUTION The following text contains instructions aimed at preventing unwanted system operation, installation or conditions that, if not followed, might void the warranty.
  • Page 5: Meganet™ Rotating Impact Sprinkler

    MEGANET™ ROTATING IMPACT SPRINKLER Description Thread connector model Cement connector model Thread connector model ISO C 20 mm / ASTM C ½" with non-leakage valve Cover Upper body Base ½" male thread Cement connector Non-leakage valve Applications High water trajectory angle - 24D - for vegetables and open field crops, open field nurseries, crops germination, frost mitigation, cooling fruit orchards and roof dust cleaning.
  • Page 6: Specifications

    MEGANET™ ROTATING IMPACT SPRINKLER Specifications • 7 different nominal flow rates: 200, 250, 350, 450, 550, 650, 750 l/h. Nominal flow rates at 2.3 bar pressure. • Recommended working pressure: 2.0 to 3.0 bar (at the sprinkler head). • Can be installed on solid sets or in removable field stands. •...
  • Page 7: Technical Data

    TECHNICAL DATA Performance Sprinkler Rectangular spacing Lateral MegaNet™ 15D Water trajectory angle: 15 degrees. Pin color code: Gray Spacing - rectangular (m x m) Nozzle Working Flow Wetted Color size pressure rate diameter* 7 x 8 8 x 8 9 x 8 10 x 8 9 x 9 9 x 10 10 x 10...
  • Page 8 TECHNICAL DATA Performance (cont'd) Sprinkler Triangular spacing - isosceles** Lateral MegaNet™ 15D Water trajectory angle: 15 degrees. Pin color code: Gray Spacing - triangular (m x m) Nozzle Working Flow Wetted Color size pressure rate diameter* 7 x 8 8 x 8 9 x 8 10 x 8 9 x 9...
  • Page 9: Max. Lateral Length - 10% Flow Variation

    TECHNICAL DATA Max. lateral length - 10% flow variation Inlet pressure: 3.0 bar Lateral: PE 32 mm Lateral: PE 40 mm ID: 27.2 mm ID: 36.8 mm Nominal Nominal Distance between sprinklers (m) Distance between sprinklers (m) flow rate: flow rate: 200 l/h* 200 l/h* Max.
  • Page 10 TECHNICAL DATA Max. lateral length - 10% flow variation (cont'd) Inlet pressure: 3.0 bar Lateral: PE 50 mm Lateral: FlexNet 2" ™ ID: 45.4 mm ID: 50.4 mm Nominal Nominal Distance between sprinklers (m) Distance between sprinklers (m) flow rate: flow rate: 200 l/h* 200 l/h*...
  • Page 11: Sprinkler Water Trajectory

    TECHNICAL DATA Sprinkler water trajectory A. Distance - Distance of max. trajectory height from sprinkler nozzle. B. height - Elevation of max. trajectory height above ground. Trajectory height above sprinkler nozzle The maximum trajectory height above the sprinkler nozzle is relevant in the following cases: •...
  • Page 12: Installation

    INSTALLATION Introduction CAUTION Assembly must be done gently. Do not overtighten or use excessive force. Tools required • 20 mm spanner • 30 mm spanner Various installation configurations Netafim™ sprinklers can be installed at a convenient height in different configurations, to suit the needs of various crops and field conditions.
  • Page 13: Maintenance

    MAINTENANCE To assure proper operation of the sprinkler, a simple inspection and maintenance procedure should be carried out regularly. Rinsing the filter Frequency: Before the beginning of each growing season or in case one the following symptoms occurs: • The sprinkler doesn't emit water. •...
  • Page 14: Checking The Turbine And The Cover

    MAINTENANCE Checking the turbine and the cover Frequency: Before the beginning of each growing season Action: 1. Open the sprinkler by unscrewing the upper body of the sprinkler from its base. 2. Detach the filter by pulling it down. 3. Remove the pin by pulling it up with your fingernail or with a small screwdriver.
  • Page 15: Cleaning The Nozzle

    MAINTENANCE Cleaning the nozzle CAUTION Never operate the sprinkler without the filter. Failure to comply with this instruction will clog the sprinkler, and may damage it and void the warranty. If the above instruction is followed, the sprinkler nozzle should never get clogged. In the event that the sprinkler has been operated without the filter in place, it is possible to clean the nozzle.
  • Page 16 MAINTENANCE 5. Release the diverter using the other end of the Hold the first service key in place and turn the second service key. second service key counterclockwise to release the diverter. Diverter 6. Clean the nozzle from the top with a water jet or 7.
  • Page 17: Parts And Complementary Products

    PARTS AND COMPLEMENTARY PRODUCTS Parts MegaNet™ - ½" threaded inlet connector, head only Flow Nozzle Catalog number rate* Color size (l/h) code (mm) 1.85 Yellow 63600-001700 63600-004900 2.06 Purple 63600-001750 63600-004950 2.44 Green 63600-001000 63600-005000 2.79 Blue 63600-002000 63600-006000 3.08 Brown 63600-003000 63600-007000 3.37 Orange 63600-004000 63600-008000...
  • Page 18: Complementary Products

    PARTS AND COMPLEMENTARY PRODUCTS MegaNet™ accessories Product Service key Product Road protector description description Catalog Catalog 63620-004500 63620-007000 number number Complementary products Pressure regulator Product In-line pressure regulator, description ¾" female - ½" female. 2.5 bar nominal outlet pressure. Catalog 31000-002200 number 18 MegaNet...
  • Page 19: Models For Specific Uses

    PARTS AND COMPLEMENTARY PRODUCTS Models for specific uses, head only Special model for cement connection (blue base) Product description 20 mm ISO inlet connector ½" ASTM inlet connector Flow Nozzle Catalog number Catalog number rate* Color size (l/h) code (mm) 1.85 Yellow 2.06...
  • Page 20: Appendix 1: Special Applications

    APPENDIX 1: SPECIAL APPLICATIONS Special model for cement connection (blue base) Can be cemented to the end of a PVC riser tube in solid set installations. Effective for theft prevention. 2 types are available: • ISO C 20 mm • ASTM C ½"...
  • Page 21: Special Model With Anti-Drain Valve

    APPENDIX 1: SPECIAL APPLICATIONS Special model with anti-drain valve For use in slopped fields in order to prevent drainage of the distribution pipe and possible over-saturation of the soil, unwanted puddles or landslide. Features and benefits • Automatic end-of-irrigation shut-off valve. •...
  • Page 22: Road Protector

    APPENDIX 1: SPECIAL APPLICATIONS Road protector To avoid wetting the roads around the field, Netafim™ offers a road protector to be used on the sprinklers at the boundaries of the field. Installing the road protector 1. Place the road protector on top of the sprinkler with its back side facing the road you want to protect from water.
  • Page 23: Warranty

    WARRANTY Netafim™ warrants all the components of the MegaNet™ sprinkler to be free of substantial defects in material and workmanship for a period of 1 (one) year from the date of purchase. If a defect is discovered during the applicable warranty period, Netafim™ will repair or replace, at its discretion, the product or the defective part.
  • Page 24 GROW MORE WITH LESS WWW.NETAFIM.COM...
