V6-60HS-1 SERIES OF HIGH-SPEED
Copyright © 2000 Vicon Industries Inc. All rights reserved.
Product specifications subject to change without notice.
Vicon and its logo are registered trademarks of Vicon Industries Inc.
VICON INDUSTRIES INC., 89 ARKAY DRIVE, HAUPPAUGE, NEW YORK 11788
TEL: 631-952-CCTV (2288) FAX: 631-951-CCTV (2288) TOLL FREE: 800-645-9116
24-Hour Technical Support: 800-34-VICON (800-348-4266)
UK: 44/(0) 1489-566300 INFOFAX: 800-287-1207 WEB: www.vicon-cctv.com
Vicon part number 8006-8683-02-00
MOTORIZED ZOOM LENSES
X683
Section 15 Rev 100
Advertisement
Table of Contents
Related Manuals for Vicon V6-60HS-1 Series
Summary of Contents for Vicon V6-60HS-1 Series
- Page 1 Copyright © 2000 Vicon Industries Inc. All rights reserved. Product specifications subject to change without notice. Vicon and its logo are registered trademarks of Vicon Industries Inc. VICON INDUSTRIES INC., 89 ARKAY DRIVE, HAUPPAUGE, NEW YORK 11788 TEL: 631-952-CCTV (2288) FAX: 631-951-CCTV (2288) TOLL FREE: 800-645-9116 24-Hour Technical Support: 800-34-VICON (800-348-4266) UK: 44/(0) 1489-566300 INFOFAX: 800-287-1207 WEB: www.vicon-cctv.com...
- Page 5 Introduction The information in this manual covers the installation, operation and maintenance of the V6-60HS-1 Series of High-Speed Motorized Zoom Lenses. These units should be installed by a qualified technician using approved materials in conformance with national, state and local electrical codes. Read these instructions through completely before attempting installation.
- Page 6 Notes 2 • • Introduction X683 Rev 100 V6-60HS-1 Zoom Lenses...
-
Page 7: Installation
Installation Unpacking and Inspection All Vicon equipment is tested and inspected before leaving the factory. It is the carrier’s responsibility to deliver the equipment in the same condition as it left the factory. Inspect the cartons upon delivery and, if damage is present, make detailed notes on the carrier’s bill. Then obtain the carrier’s agent signature and file a damage claim as soon as possible. - Page 8 Table 2 Table 3 Wiring for M and MS Lenses Wiring for M and MS Lenses with Presets Pin Number Wire Color Function Pin Number Wire Color Function White Iris drive White Iris drive Zoom drive Zoom drive Green Focus drive Green Focus drive Black...
- Page 9 Wiring the Autoiris (AC) Lens AC lenses have two cables. One cable has a AMP MR (Miniature Rectangle) connector. This provides connection for the zoom, focus and preset controls. Lenses without the preset function are supplied with a 6-pin connector, while lenses with presets have a 9-pin connector. The wiring of both connectors is shown in Figure 2. Table 4 shows the color-coding of the control cables and Table 5 shows the color coding for the control and preset cables.
-
Page 10: Autoiris Adjustment
Zoom and Focus Adjustment Procedure The following procedure should be used to obtain the best results in setting optical and mechanical focus. 1. Adjust the zoom function to the maximum telephoto setting, then focus on a convenient distant object. Readjust the zoom to the maximum wide angle setting and check the focus. The focus should remain reasonably sharp. - Page 11 Video Level (LEVEL) The level control is preset at the factory for optimum performance, so normally no adjustment is required. Adjusting this control when it is not necessary may spoil the picture quality. If all other adjustments fail to produce a satisfactory picture, adjust the LEVEL potentiometer. The adjustment limits are low (L) and high (H). Note: When making an adjustment, turn the potentiometer a little at a time.
-
Page 12: Shipping Instructions
Shipping Instructions Use the following procedure when returning a unit to the factory: 1. Call or write Vicon for a Return Authorization (R.A.) at one of the locations listed below. Record the name of the Vicon employee who issued the R.A. -
Page 13: Technical Information
Zoom and focus: 40 mA max. per motor. Connectors: Iris: 3-conductor shielded pendant cable supplied for iris. Zoom and focus: Standard lens; Vicon part number 8000-9800-00 on pendant cable. (Mating connector 8000-9736-00 supplied.) Preset lens; Vicon part number 8000-9801-00 on pendant cable. - Page 14 Cable Requirements: Without presets: 3 conductor, shielded. With presets: 7 conductor, shielded. Video: Requires video from 0.5 V to 1.0 V peak-to-peak for proper iris operation. OPERATIONAL Duty Cycle: Intermittent. Iris Speed: M, MS Lens: 1.5 – 8 sec at 8 VDC, adjustable. AC Lens: 2.0 sec, not adjustable.
