INSTRUCTIONS FOR
Installation AND OPERATION
MOTORIZED ZOOM LENSES (M, MS, AND AC SERIES)
The information in this instruction
manual covers the installation, opera-
tion, and maintenance of the following
Vicon lenses:
M Series Motorized Lenses
MS Series Motorized Lenses
with Spot Filter
AC Series Motorized Lenses
with Autoiris and Spot Filter
These units must be installed by qualified
personnel using approved materials in
conformance with national, state, and lo-
cal electrical codes.
The standard motorized zoom lenses
(model number suffix M) feature motor-
ized zoom, focus, and iris. Lenses with
the MS suffix are equipped with a neu-
tral-density spot filter to permit use in a
wide range of lighting conditions. With
Product specifications subject to change without notice.
TEL: 516-952-CCTV (2288) TOLL FREE: I-800-645-91 16 FAX: 516-951 -CCTV (2288)
VICON (U.K.) TEL: 44/(O) 1489/566300
1. INTRODUCTION
VICON INDUSTRIES INC.
89 ARKAY DRIVE, HAUPPAUGE, N.Y. 11788
this lens, a sensitive camera can operate
effectively in both partial darkness and
high-light-level conditions.
Lenses with the AC suffix have elec-
tronic circuitry for automatic iris control,
as well as the spot filter. This additional
feature provides optimum viewing con-
trast regardless of light conditions or
brightness variations within the scene.
Each of these models are also available
with a preset-position option. This con-
sists of potentiometers built into the lens
that provide position feedback informa-
tion for zoom and focus to an appropriate
control unit.
These lenses may be powered with
9 - 12 VDC power from either the
camera or from a model VPS- 12 DC
Power Supply.
Vicon part no. 8006-8749-02-00
INFOFAX: 1-800-287-I 207
Advertisement
Table of Contents
Related Manuals for Vicon M Series
Summary of Contents for Vicon M Series
- Page 1 Vicon lenses: Lenses with the AC suffix have elec- M Series Motorized Lenses tronic circuitry for automatic iris control, as well as the spot filter. This additional MS Series Motorized Lenses feature provides optimum viewing con-...
- Page 2 2. INSTALLATION Do not exceed the maximum recom- CAUTION: Control units having the mended distances between a lens and its three-position distance switch control unit or relay box. MUST NOT be set longer than recommended distances or the lens NOTE: The front element of a zoom may be seriously damaged.
- Page 3 2.2 Wiring M and MS Lenses the lens model. Refer to the Circuit Dia- A lens from the M or MS series has a gram for each lens model. single cable with multiple conductors. The number of conductors depends on 2.3 Wiring Autoiris (AC) Lenses mon) conductor.
- Page 4 in the bright areas and some in the other 1. Set the camera AGC switch to OFF areas, adjust the ALC potentiometer to a middle setting that provides the best 2. Set the monitor brightness and con- compromise. trast controls to their midpoints. Image Signal Level Adjustment: The 3.
- Page 5 Shipping Instructions Use the following procedure when returning a unit to the factory: listed below. Record the name of the Vicon employee who issued the R.A. VICON INDUSTRIES INC. 89 Arkay Drive Hauppauge, New York 11788 5 16-952-CCTV (2288) or toll free l-800-645-9 116...
- Page 6 MS Lens Standard View of Wiring Side View of Wiring Side NOT USED ZOOM Lens with Preset Option FOCUS Lens with Preset Option FOCUS LENS COMMON LENS COMMON ERROR RETURN < 5 ERROR Rt I ERROR SUP (+12 V) ZOOM WIPER FOCUS WIPER FOCUS WlPFR GROUND (SHIELD) <...
- Page 7 Close Open PRESET POTENTIOMETER Near I Far Wide 1 KQX4 Remarks: Connect together with Black (Focus), Red (Zoom) and Brown (Extender) for common system when necessary PRESET POTENTIOMETER Near 5KVR I F a r Wide 5KVR I Tele 1 KGX4 Remarks: Connect together with Black (Focus) and Red (Zoom) for common system when necessary.
