Note:
Extra stream 2's actual frame depends on device max capacity set
which can be adjusted within its range.
H.264H: 40Kbps-8192Kbps adjustable
Video Bit Rate
MJPEG: 40Kbps-16384Kbps adjustable and bit rate is adjustable.
Support customized setup.
Support mirror.
Video Flip
Support flip function.
Snapshot Max 1f/s snapshot. File extension name is JPEG.
Privacy Mask Supports max 4 privacy mask zones
Video Setup Support parameter setup such as bright, contrast.
Video
Channel title, time title, motion detect, tampering, overlay
Information
Lens 2.8mm, 3.6mm, 6mm. Fixed focus.
Lens Interface M12. Lens is the default accessories
396 (18*22) detection zones; sensitivity level ranges from 0 to 100;
area threshold ranges from 0 to 100.
Motion Detect
Activation event: video storage, image snapshot, log, email function
and etc.
Activation event: video storage, image snapshot, log, email function
Video Loss
and etc.
Record Priority
Manual >Video detect>Schedule
Storage
NAS storage
Management
Wire Network
1-ch 10/100 Base-T Ethernet
Standard HTTP, TCP/IP, ARP,IGMP, ICMP, RTSP, RTP,UDP, RTCP,
Network Protocol
SMTP, FTP, DHCP, DNS, DDNS, PPPOE, UPNP, NTP, Bonjour,
SNMP, QoS, 802.1x
( 704*576@20fps)
extra stream 2
(1280*720@1fps)
Main stream
(1920*1080@25fps),
extra stream 1
( 704*576@25fps)
extra stream 2
(1280*720@11fps)
NTSC:
Main stream
(2048*1536@20fps),
extra stream 1
( 704*480@20fps)
extra stream 2
(1280*720@1fps)
Main stream
(1920*1080@30fps),
extra stream 1
( 704*480@30fps)
extra stream 2
(1280*720@1fps)
