Prime TNODP23 Quick Start Manual

MODEL #TNODP23
EZ-SET OUTDOOR
DIGITAL TIMER
STEP 1 - Set the time
• Plug in the timer and let it
charge for 30 minutes.
CTD
• Use the up ( ) and
down ( ) arrow to set the
current time.
Custom
STOP
PLUG IN THE TIMER AND MOVE TO STEP 2
ADDITIONAL FEATURES
CUSTOM COUNTDOWN:
• Press "CTD".
• Press up ( ) and down ( ) arrow to set the
countdown from 1 minute to 24 hours.
(Note: "CTD" will flash on LCD to indicate the
countdown feature is active)
PROGRAMMING INSTRUCTIONS
Congratulations! You have purchased the easiest to
use timer on the market today. In three steps or less,
your timer will be ready to use.
1. Set the time.
2. Choose a preset option.
3. Set a custom on/off time.
STEP 2 - Pick a preset option
• Press one or more of the
preset options that meet your
On
needs.
Off
• When the button lights up
the timer is set (timer must
Custom
ON OFF be plugged in for buttons to
illuminate).
• If you would like a custom
on/off time, move to Step 3.
5pm-12am 5pm-8am
5am-8am
If not, the setup of your new
EZ-SET timer is FINISHED!
MANUAL ON/OFF OVERRIDE:
• Press "On/Off" to bypass the current setting and turn
your device On or Off.
(Note: Timer settings will resume based on the next
programmed cycle)
CTD
Custom Custom
ON OFF
5pm-12am 5pm-8am
5am-8am
On to step 3
CTD
Custom
ON
5am-8am
On
Off
STEP 3 - Set a Custom
On/Off Time
• Hold down "Custom ON"
and press the up ( ) and
down ( ) arrow to set the
ON time.
• Hold down "Custom OFF"
and press the up ( CTD ) and
down ( ) arrow to set the
Custom
OFF time.
ON
• Ensure the timer is still
plugged in. Press,
BUT DO NOT HOLD DOWN, the "Custom On" and
"Custom Off" buttons. Buttons will turn blue
when the program is activated.
IN CASE OF POWER FAILURE
Timer will continue to operate on battery backup if the
power goes out; however it will not turn attached devices
on or off. Once power is restored, programming will
resume. If power remains out longer than the battery
backup will operate, re-program the timer as explained in
Steps 1, 2 and 3 of the "Programming Instructions".
NOTE: Battery is permanently installed and not
replaceable. It automatically recharges when power is
provided to the timer.
On
Off
Custom
OFF
5pm-12am 5pm-8am
CTD
Custom Custo
ON OFF
5am-8am 5pm-12am 5pm-8am
On
Off
Custom
OFF
5am-8am 5pm-12am 5pm-8am
