Lapa Fan
- Installation instructions
Should you have any questions or difficulty installing your new fan,
please contact Modern Fan Co. customer service immediately.
Note: Power supply must be turned off prior to any contact with electrical wires. It is
recommended that a licensed electrician be hired to install your ceiling fan.
(1) Remove and identify contents of carton.
blades
down rods
(2) Using machine screws from hardware package or
existing screws in junction box, securely attach hanging
bracket to ceiling junction box.
(3) Remove the stopper screw and loosen the
set screw on the fan collar. Set the stopper
screw aside for step (5).
set screw
stopper screw
fan body
half-ball
hardware
package
L a p a
THE MODERN FAN COMPANY
Customer Service
M-F 8am - 4pm (PST)
(ph) 888.588.3267
www.modernfan.com
optional
control
canopy
bottom cap
hanging
bracket
balancing kit
Advertisement
Related Manuals for The Modern Fan Company Lapa
Summary of Contents for The Modern Fan Company Lapa
- Page 1 L a p a THE MODERN FAN COMPANY Customer Service M-F 8am - 4pm (PST) (ph) 888.588.3267 www.modernfan.com Lapa Fan - Installation instructions Should you have any questions or difficulty installing your new fan, please contact Modern Fan Co. customer service immediately.
- Page 2 (4) Remove stopper pin and half ball from small down rod by loosening set screw on half ball. Set parts aside for step (7). set screw stopper pin (5) Run fan wires through selected down rod. Reinstall stopper screw from step (3) and firmly tighten set screw on fan collar against down rod.
- Page 3 (11) Attach bottom cap to fan body by aligning slots on cap with fittings inside fan body, and rotating clockwise, or proceed to step (12) if you are using the optional light kit. (12) To install optional light kit, begin by identifying all parts, then follow steps (a) through (f) below: socket screws LED lamp/bulb...
