Summary of Contents for Tescom AVR 11
- Page 1 AVR 11 User Manual Automatic Voltage Regulator 1 phase In / 1 phase Out 1-15 kVA SERVO MOTOR Βόλου 7, 183 46 Μοσχάτο +30 210 9590080 www.tescom-ups.gr Volou 7, 18 346, Moschato, Greece info@tescom-ups.gr...
- Page 2 AVR 11 • 1/1 • 1-500 kVA • Automatic Voltage Regulator USER MANUAL IMPORTANT NOTICES! Dear user; This manual contains information about features of Voltage Regulator (AVR), installation, operation and the loads connected to the AVR, safety information, use of the AVR, operation principles, settings and measurements (calibrations), detection and troubleshooting.
-
Page 3: Meanings Of Symbols Used In The Manual
AVR 11 • 1/1 • 1-500 kVA • Automatic Voltage Regulator USER MANUAL MEANINGS OF SYMBOLS USED IN THE MANUAL This symbol points out where to pay attention mostly. This symbol shows instructions that may pose a life threatening hazard, such as an electric shock if not followed. -
Page 4: Meanings Of Symbols On Avr
AVR 11 • 1/1 • 1-500 kVA • Automatic Voltage Regulator USER MANUAL MEANINGS OF SYMBOLS ON AVR PE: Protective Earth Electroshock Hazard (Black/Yellow) Includes warning instructions Recycle Heavy load www.tescom-ups.gr... -
Page 5: Table Of Contents
AVR 11 • 1/1 • 1-500 kVA • Automatic Voltage Regulator USER MANUAL CONTENTS MEANINGS OF SYMBOLS USED IN THE MANUAL ....................... 4 MEANINGS OF SYMBOLS ON AVR ..........................5 1.SAFETY INSTRUCTIONS ............................7 2.GENERAL INSTRUCTIONS ............................8 2.1.Safe Handling ..............................8 2.2.Location ................................ -
Page 6: Safety Instructions
AVR 11 • 1/1 • 1-500 kVA • Automatic Voltage Regulator USER MANUAL 1.SAFETY INSTRUCTIONS Use the AVR where thereis restricted access. When AVR Line (Manual Bypass) is selected, device is deactivated and Human Safety the load is sourced from the mains and the output is energized. -
Page 7: General Instructions
AVR 11 • 1/1 • 1-500 kVA • Automatic Voltage Regulator USER MANUAL 2.GENERAL INSTRUCTIONS 2.1.Safe Handling Be careful when handling loads. Do not carry heavy loads without help. • Move wheeled devices on smooth and unobstructed surfaces. • Do not use ramps that are more inclined at 10 ° angle. -
Page 8: Location
AVR 11 • 1/1 • 1-500 kVA • Automatic Voltage Regulator USER MANUAL 2.2.Location This product complies with the restricted access and safety requirements specified in TS EN 60335-1 and TS EN 60335-1 / A11 safety standards. Users must meet the following requirements. -
Page 9: Unpacking And Assembly
AVR 11 • 1/1 • 1-500 kVA • Automatic Voltage Regulator USER MANUAL 3.UNPACKING AND ASSEMBLY The equipment damaged during transportation must be inspected by the Technical Service Personnel before the installation. As AVR is delivered to you, please check the packaging firstly. Even device is packed carefully, it may have been damaged during the transportation. -
Page 10: Unpacking
AVR 11 • 1/1 • 1-500 kVA • Automatic Voltage Regulator USER MANUAL 3.1.Unpacking The cardboard box is removed from the top as held by the handles. 3.2.Assembly Procedures The installation complies with national installation regulations. • TS HD 384.4.42 S1: Electrical installation at the premises Part 4: Protection for safety Group 42: Protection against thermal effects •... -
Page 11: Kva -50 Kva(1 Phase Input/1Phase Output)Front Panel View
AVR 11 • 1/1 • 1-500 kVA • Automatic Voltage Regulator USER MANUAL 3.3. 1 KVA -50 KVA(1 Phase Input/1Phase Output)Front Panel View İmage-1 Image-1 Cartridge Fuse Input Signal Light Circuit Breaker B Type Output Signal Light Input/Output Voltmeter Cam Switch(Line-Regulator) -
Page 12: Kva - 50 Kva(1 Phase Input/ 1 Phase Output) Rear Panel View
AVR 11 • 1/1 • 1-500 kVA • Automatic Voltage Regulator USER MANUAL 3.4. 1 KVA - 50 KVA(1 Phase Input/ 1 Phase Output) Rear Panel View Image-2 Image-2 Earth Connection Output Connection Neutral Connection Neutral Connection Input Connection Ventilation Holes Device Carriage Legs www.tescom-ups.gr... -
Page 13: Kva -50 Kva (1 Phase Input/1 Phase Output) Connection Of Terminals
AVR 11 • 1/1 • 1-500 kVA • Automatic Voltage Regulator USER MANUAL 3.5. 1 KVA -50 KVA (1 Phase Input/1 Phase Output) Connection of Terminals Feedback Risk Firstly, separate the AVR from the circuit. Measure all terminals including the earth connection (PE) and check if there is dangerous voltage. -
Page 14: Earth Connection
AVR 11 • 1/1 • 1-500 kVA • Automatic Voltage Regulator USER MANUAL 3.5.1. Earth Connection For safety, the ground connection of the device must be done. Perform PE ground connections before connecting any other cable. AVR’s PE (Earth) must be connected to high quality Earth line (low resistance)The connection of the load must be done through the output Earthing screw. -
Page 15: Avr (Automatic Voltage Regulator) Operations
AVR 11 • 1/1 • 1-500 kVA • Automatic Voltage Regulator USER MANUAL 4.AVR (AUTOMATIC VOLTAGE REGULATOR) OPERATIONS The AVR (Automatic Voltage Regulator) connected between the mains and the device protects the device / devices from line breakdowns, especially line outages. -
Page 16: Device Specifications And Basic Information
AVR 11 • 1/1 • 1-500 kVA • Automatic Voltage Regulator USER MANUAL 4.1. Device Specifications and Basic Information 4.1.1. Power Range 1 – 15 kVA single phase production. 4.1.2. Working Voltage Range Standard: %-25,%+15 -220/230/240 V Single Phase Optional: %±20 -220V/230/240 V Single Phase... -
Page 17: Advantages Of Avr
AVR 11 • 1/1 • 1-500 kVA • Automatic Voltage Regulator USER MANUAL 4.2. Advantages of AVR • High quality and Long Life Solution • Safe and tested system • Silent Operation and High Efficiency • No Distortion at output •... -
Page 18: Input/Output Display
AVR 11 • 1/1 • 1-500 kVA • Automatic Voltage Regulator USER MANUAL 5. .INPUT/OUTPUT DISPLAY The input / output display on the front panel shows the voltage value at the input and the voltage at the output of the device.(Image-5) Image-5 Input-Output connection scheme shown in Image-6. -
Page 19: Avr Internal Structure And Troubleshootings
AVR 11 • 1/1 • 1-500 kVA • Automatic Voltage Regulator USER MANUAL 6. AVR INTERNAL STRUCTURE AND TROUBLESHOOTINGS 6 6 . . 1 1 . . A A V V R R I I n n t t e e r r n n a a l l S S t t r r u u c c t t u u r r e e... -
Page 20: Control Board And Assembly
AVR 11 • 1/1 • 1-500 kVA • Automatic Voltage Regulator USER MANUAL 6.2. Control Board and Assembly Image-8 Resim-8 Motor Limit Switch(Common Pin) Limit Switch-1 Limit Switch-2 Output Voltage Accuracy Setting Output Voltage Setting Circuit Transformer Connection Pins www.tescom-ups.gr... - Page 21 AVR 11 • 1/1 • 1-500 kVA • Automatic Voltage Regulator USER MANUAL Image-9 Image-10...
-
Page 22: Possible Malfunctions And Troubleshootings
AVR 11 • 1/1 • 1-500 kVA • Automatic Voltage Regulator USER MANUAL 6.3. Possible Malfunctions and Troubleshootings Malfunction Possible Causes Troubleshooting If voltmeter Voltmeter If voltmeter is digital, please check the socket. retrieves Malfunctioned İf it is analogue, please replace with new one... -
Page 23: Technical Specifications
AVR 11 • 1/1 • 1-500 kVA • Automatic Voltage Regulator USER MANUAL 7. TECHNICAL SPECIFICATIONS MODEL 1101 1102 1103 1105 1107 1110 1115 Power(KVA) INPUT of REGULATOR Input Voltage -25/+15 % Standard (other input bandwidth are optional) Correction Range Working Frequency 47…65 Hz... -
Page 24: Warranty
AVR 11 • 1/1 • 1-500 kVA • Automatic Voltage Regulator USER MANUAL 8. WARRANTY 8.1. Warranty Conditions 1.AVR’s warranty period is 2 years from the date of delivery of product against defects in components, workmanship and production, if the product is used in the compliance with shown in the user manual. -
Page 25: Device And Manufacturer's Information
AVR 11 • 1/1 • 1-500 kVA • Automatic Voltage Regulator USER MANUAL 8.3. Device and Manufacturer’s Information Manufacturer Name: Address: Tel / Fax e-mail Contact Sign&Stamp Device Type Regulator Brand Model Label and Serial No Delivery Time/Place Warranty Min. Repair Period... - Page 26 Βόλου 7, 183 46 Μοσχάτο +30 210 9590080 www.tescom-ups.gr Volou 7, 18 346, Moschato, Greece info@tescom-ups.gr...
