LD DAVE G4X Series User Manual page 13

REVERB
12
Level control for mixing the signal from channel 1 or channel 2 to the internal digital effects unit.
PRESET PLATE / LARGE / SMALL / OFF
13
If necessary, press the PRESET button repeatedly to select the desired effect preset or to switch off the
reverb effect. The corresponding indicator field of the three effects lights up white; when the reverb
effect is switched off, none of the indicator fields light up.
INPUT 3/4
14
Volume control for stereo channel 3/4. Turning to the right increases the volume, turning to the left
decreases it.
INPUT 5/6
15
Volume control for stereo channel 5/6. Turning to the right increases the volume, turning to the left
decreases it.
SOURCE
16
Button for selecting the signal source SPDIF or Bluetooth for channel 5/6. The corresponding display
field lights up white.
HOLD TO LINK
17
Press the HOLD TO LINK button for about 3 seconds to put the internal Bluetooth module into pairing
standby, the connection to a previously paired device is disconnected. The Bluetooth symbol flashes for
the duration of the pairing readiness. Activate Bluetooth on your playback device (smartphone, tablet,
etc.) and select LD DAVEG4 in the Bluetooth menu. Pairing is now automatic; as soon as the devices are
paired, the Bluetooth symbol lights up permanently. Audio playback via Bluetooth can now be started.
MODE SELECT
18
Select the symbol corresponding to the set-up variant of the DAVE G4X speaker system using the SELECT
button. This optimises the radiation pattern of the satellite speakers accordingly. The symbol for the
selected set-up variant lights up white.
SUB
19
Volume control for the subwoofer. Turning to the right increases the volume, turning to the left
decreases it.
HIGH
20
High shelf filter for adjusting the treble reproduction to the room acoustics
(turn to the left = lowering, turn to the right = raising, centre position = no influence).
13
