LD DAVE G4X Series User Manual page 11

POWER INPUT
1
IEC mains socket with integrated fuse holder. A suitable power cord is included in the scope of delivery.
IMPORTANT NOTE: Replace the fuse only with one of the same type and rating. Pay attention to the
imprint on the housing. If the fuse blows repeatedly, please contact an authorised service centre.
POWER
2
On/off switch. Always switch on the speaker system as the last unit in the signal chain and switch it off
again as the first unit.
INPUT 1 / INPUT 2
3
Audio inputs with combo sockets (XLR / 6.3 mm jack), which are suitable for both unbalanced and bal-
anced cabling. The inputs are adjusted to the signal source using the SELECT button in the subwoofer's
mixer section (LINE, HI-Z and MIC).
INPUT 3 L / INPUT 4 R
4
Stereo line input with combo jacks (XLR / 6.3 mm jack), suitable for both unbalanced and balanced
cabling. Connection for a keyboard or external mixer, etc.. Only use connections no. 4 and no. 5 alterna-
tively.
RCA INPUT 3 L / INPUT 4 R
5
Stereo line input with cinch sockets for connecting an audio player (CD player, MP3 player, tablet, etc.).
Only use connections no. 4 and no. 5 as alternatives.
INPUT 5/6 SPDIF
6
Digital stereo input in optical SPDIF format with TosLink socket. Connection for a playback device with
optical SPDIF output.
SAT LEFT / SAT RIGHT
7
Speakon compatible connectors for the corresponding DAVE G4X satellites.
