Synargy Madrid Assembly Instructions

Step 1
Connecting power to the left
hand backs to operate power.
Connect the cords shown as 'A'
and 'B' (below) on both of the
end seats.
One cord will come from the seat
back and the other will be found
at the base of the seat.
Assembly Instructions for Madrid
- 3 Seat - 2 Seat - Recliner
Step 2
Powering the recliners.
At the base of the suite there is
a cord which needs to be
plugged into the rectangle
power box (transformer) which
has a cord ending in a plug.
This will then be ready to plug
into a wall socket.
Repeat for each power recline
seat.
2
Step 3
Attaching the backs to the base
of the suite.
Slide the metal receivers over
the metal posts.
Metal receivers are located on
the inside of the back.
Press both sides of back firmly
into place. The back should
automatically lock into place.
3
