Omax PROTOMAX Manual page 3

LAYOUT SOFTWARE
Importing a file
Click on [Import from other CAD]
●
to load your file.
You will need a .dxf file.
After selecting the path to your
●
design, a preview is shown.
If needed use the checkboxes on
the left to modify it.
When you are done click [Ok].
●
Your design will be shown on the
●
main screen.
Select now your design by clicking
●
on [Select] and then [All].
All lines should be selected
(marked in yellow).
PAGE 3
