Hover-1 ALPHA PRO Operation Manual

Hide thumbs Also See for ALPHA PRO:
Table of Contents

Advertisement

Quick Links

ELECTRIC FOLDING SCOOTER
O P E RATI O N M A N U A L
H 1- A LP R O

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ALPHA PRO and is the answer not in the manual?

Questions and answers

Related Manuals for Hover-1 ALPHA PRO

Summary of Contents for Hover-1 ALPHA PRO

  • Page 1 ELECTRIC FOLDING SCOOTER O P E RATI O N M A N U A L H 1- A LP R O...
  • Page 2 HELMETS SAVE LIVES! Always wear a properly tted helmet that complies with CPSC or CE safety standards when you ride your E-Scooter. Correct Fit: Make sure your helmet covers your forehead. Incorrect Fit: Forehead is exposed and vulnerable to serious injury.
  • Page 3 WARNING As with all mechanical devices, the Hover-1 Alpha Pro is subject to wear and high stresses. Di erent materials and components may react to wear or fatigue in di erent ways. If the design life of a component has been exceeded, it may suddenly fail, possibly causing injuries to the rider.
  • Page 4 • To avoid collisions, falls, and loss of control, please learn how to ride the Alpha Pro safely. • You can learn how to ride the Alpha Pro by reading the operation manual and watching videos. • All users are responsible for any consequences caused by violating warning contents or proper operations.
  • Page 5 Use caution when riding the Alpha Pro in cold temperatures (below 40°F/4°C). Doing so may increase the risk of mechanical failures of the E-Scooter, which may lead to damage to your device, property damage, serious bodily injury, and even death.
  • Page 6 • Do not operate or allow others to operate the Alpha Pro until the user understands all instructions, warnings, and safety features described in this manual. • Check with your doctor if you have a medical condition that could affect your ability to use the Alpha Pro.

  • Page 7: Safety Precautions

    • Hover-1 is not liable for tickets or violations given to riders who do not follow local laws and regulations. • For your safety, always wear a helmet that meets CPSC or CE safety standards.
  • Page 8 • Do not ride with pets. • Before stepping on your Alpha Pro, make sure it is placed flat on level ground.
  • Page 9 • If you are riding near other riders, be sure to maintain a safe distance between each other to prevent collisions. • Be sure to keep your feet on the Alpha Pro at all times. Moving your feet off your Alpha Pro while driving is dangerous and may cause the Alpha Pro to stop suddenly or veer sideways.
  • Page 10 • Do not ride your Alpha Pro where it is not permitted. • Do not ride your Alpha Pro near motor vehicles or on public roads. • Do not travel up or down steep hills. • The Alpha Pro is intended for use by a single individual, DO NOT attempt to operate the Alpha Pro with two or more people.
  • Page 11 • Do not ride the Alpha Pro in dark or poorly lit areas. • Do not ride the Alpha Pro near or over potholes, cracks, or uneven pavement or surfaces. • Do not operate your Alpha Pro off-road. • Do not turn sharply, especially at high speeds.

  • Page 12: Care And Maintenance

    • Do not dispose of the Alpha Pro in fire as it may explode or combust. • Do not let the Alpha Pro come into contact with sharp objects, as this will cause scratches and damage.

  • Page 13: Battery Care / Maintenance

    E-Scooter. • When charging the E-Scooter, only use the enclosed 1-pin charging cable provided by Hover-1. Use of any other charger or cable may lead to damage to the E-Scooter, overheating, and risk of fire. Use of any other charger or cable voids the manufacturer warranty.
  • Page 14 • Do not attempt to modify, change, or replace your battery. • Do not use your device if the battery begins to emit odor, overheats, or begins to leak. • Do not touch any leaking materials or breathe fumes emitted. •...

  • Page 15: Specifications

    Handle-activated rear disc brake BT ID: D042258 FCC ID: 2AANZALPHA20G UL Certification: UL2272 certified PARTS LIST A. Alpha Pro E-Scooter B. Handlebar Assembly C. Charger + Charging Cable D. Hex Key & Bolts E. Air Pump F. 6 Spare Bolts...
  • Page 16 HOVER-1 ALPHA PRO DIAGRAM FEATURES/PARTS 1. LED Display 9. Steering Column 2. Bell 10. Folding Hinge 3. Brake Handle 11. Kickstand 4. Handlebar (L) 12. Foot deck 5. Handlebar (R) 13. Charging Port 6. Throttle 14. Folding Hook 7. Power Button 15.

  • Page 17: Led Display

    HOVER-1 ALPHA PRO DIAGRAM BRAKE HANDLE THROTTLE FOLDING CLIP LED DISPLAY POWER BUTTON LED DISPLAY HIGH SPEED MODE The ‘S’ icon indicates high speed mode is activated. When the E-Scooter is powered on, press the power button once to switch between high and low speed mode.

  • Page 18: Bluetooth ® Speaker

    BLUETOOTH SPEAKER ® The Alpha Pro has a powerful built-in wireless speaker, so you can play your music while riding. PAIRING THE SPEAKER 1) Turn on your E-Scooter. The speaker will “ping” to announce that it’s waiting for a Bluetooth connection.
  • Page 19 • Connect the cable with the power supply (100V-240V; 50 Hz/60 Hz). • Align and connect the 1-pin charging cable into the charging port of the Alpha Pro (DO NOT FORCE OR BEND THE CHARGING CABLE AS IT MAY CAUSE THE PRONGS TO BEND OR BREAK).

  • Page 20: Pinch Points

    PINCH POINTS Some parts of your Alpha Pro can injure you if mishandled. Moving and folding parts can cut skin. Clamps and pivoting parts such as brake levers can pinch. When folding and unfolding your Alpha Pro, please watch for pinch points where injury may be sustained. Do not leave your hand in these areas during the folding or unfolding process.

  • Page 21: Folding And Unfolding

    For safety reasons, the Alpha Pro will not accelerate unless it is already moving at least 1.8 mph (3 km/h). You must push off the ground with your foot to get the Alpha Pro moving, then press the throttle to ride it.

  • Page 22: Before Riding

    Replace the damaged part before riding. It is important that you fully understand all elements of your Alpha Pro E-Scooter. If these elements are not used correctly, you will not have full control of your Alpha Pro. Before you ride, learn the functions of the various mechanisms on your Alpha Pro.
  • Page 23 OPERATING YOUR DEVICE Make sure the device is fully charged before the first use. Before turning on your Alpha Pro E-Scooter, ride it like a normal kick scooter to get comfortable with the device before using it with the motor.
  • Page 24 OPERATING RANGE The Alpha Pro can travel up to 12 miles on a fully charged battery under ideal riding conditions. The following are some of the major factors that will affect the operating range of your device: •...

  • Page 25: Safety Alerts

    SAFETY ALERTS If a system error occurs or an improper operation is performed while riding your Alpha Pro, the device will alert the user in a variety of ways. The following are common occurrences that will produce safety alerts. These notices should not be ignored and appropriate action should be taken to correct any improper operation, failure, or errors.

  • Page 26: Fcc Statement

    FCC STATEMENT NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

  • Page 27: Warranty

    WARRANTY For warranty information, please visit us at www.hover-1.com Error E1- motor hall failure, the motor needs to be replaced Error E2 - accelerator failure, the accelerator needs to be replaced Error code E3 - motor blocking fault, release the...
  • Page 28 @Hover1Rideables @RideHover1 @RideHover1 www.Hover-1.com...
