- Page 1 OPERATING INSTRUCTIONS Translation of the Original OME 40S Oil Mist Eliminator...
- Page 2 These operating instructions describe all models and variants of your product. Note that your product may not be equipped with all features described in this document. Pfeiffer Vacuum constantly adapts its products to the latest state of the art without prior notice. Please take into account that online operating instructions can deviate from the printed operating instructions supplied with your product.
-
Page 3: Table Of Contents
Fitting direction Installation on the pump Operation Filter element saturation Maintenance Maintenance safety instructions Disassembly Cleaning Reassembly Disposal Service solutions by Pfeiffer Vacuum Spare parts Technical data and dimensions Technical data Dimensions Declaration of incorporation of partly completed machinery 3/22... - Page 4 List of figures List of figures Fig. 1: Fitting direction on the pump Fig. 2: Installation of OME40S on pump Fig. 3: Filtration element replacement Fig. 4: Filtration element replacement Fig. 5: Dimensions OME 40S 4/22...
-
Page 5: About This Manual
Keep the manual for future consultation. 1.1 Validity This operating instructions is a customer document of Pfeiffer Vacuum. The operating instructions de- scribe the functions of the named product and provide the most important information for the safe use of the device. The description is written in accordance with the valid directives. The information in this op- erating instructions refers to the product's current development status. -
Page 6: Abbreviations
About this manual Note 1.3.3 Abbreviations Exh. Exhaust Inlet flange Oil Mist Eliminator 1.3.4 Trademark proof ● Axarel ® is a trademark of DuPont de Nemours and Company, Wilmington, Delaware, USA.. ● CareClean ® is a trademark of Castrol Ltd. ● PremaClean ®... -
Page 7: Safety
Safety 2 Safety 2.1 General safety information The following 4 risk levels and 1 information level are taken into account in this document. DANGER Immediately pending danger Indicates an immediately pending danger that will result in death or serious injury if not observed. ►... - Page 8 Safety ─ Impregnation with polymesirable resins ─ Debubbling monomers 8/22...
-
Page 9: Product Description
To correctly identify the product when communicating with our service center, always have the informa- tion from the product rating plate available. 3.1.1 Scope of delivery ● 1 OME 40S Oil Mist Eliminator ● 1 centering ring equipped with O-Ring DN40 ISO-KF ● 1 quick connect clamp DN40 ISO-KF ●... -
Page 10: Installation
Installation 4 Installation WARNING Poisonous substances exit from the exhaust There is a poisoning hazard from discharged gases or vapors that can be hazardous and/or polluting during use. ► Install and run the exhaust line so that overpressure cannot build up inside it. ►... -
Page 11: Installation On The Pump
1. Remove the vent valve assembled in the pump’s exhaust port 2. Assemble as shown in (see « Product description »chapter) using the connection accessories pro- vided with the OME or ordered separately (see Pfeiffer Vacuum products catalogue). 3. Insure the assembly tightness. -
Page 12: Operation
Operation 5 Operation WARNING Risk of overpressure At the pump exhaust, the discharge circuit must be such that the resulting overpressure in the oil case is as low as possible. The maximum overpressure recommended for correct pump operation is 500 hPa. A slight negative pressure in the oil case (100–200 hPa), at the exhaust, will prevent gases from accumulating and reduce pump corrosion and pollution. -
Page 13: Maintenance
Maintenance 6 Maintenance 6.1 Maintenance safety instructions DANGER Risk to the health in the event of contact with toxic substances During pump disconnection, operator could be in contact with process residues on the exhaust that could cause severe injury or death. ► Take the appropriate safety measures to prevent injury. Consult the department manager for in- structions and safety information. -
Page 14: Cleaning
Maintenance be changed. In this case, drain and rinse the pump, replace the oil before installing an OME equipped with a new filter element (see Rotary Vane Pump Maintenance Manual). 6.3 Cleaning Never clean a filtration element! Always replace the filtration element with a new one. ►... -
Page 15: Disposal
Maintenance 6.5 Disposal Environmental protection The product and its components must be disposed of in accordance with the applica- ble regulations relating to environmental protection and human health, with a view to reducing natural resource wastage and preventing pollution. Our products contain various materials which must be recycled. Take special care for: ●... -
Page 16: Service Solutions By Pfeiffer Vacuum
We are always focused on perfecting our core competence – servicing of vacuum components. Once you have purchased a product from Pfeiffer Vacuum, our service is far from over. This is often exactly where service begins. Obviously, in proven Pfeiffer Vacuum quality. - Page 17 Service solutions by Pfeiffer Vacuum 5. Prepare the product for transport in accordance with the provisions in the contamination declaration. a) Neutralize the product with nitrogen or dry air. b) Seal all openings with blind flanges, so that they are airtight.
-
Page 18: Spare Parts
Spare parts 8 Spare parts Item Description Material Quantity Part number Spring Stainless steel Valve Aluminium O-ring Elastomer NBR 079248 Screw CHC M4 x 10 Steel Washer Steel Steel Filter element (glass microfibers + epoxy resine) Filter element 068443 Flat ring Elastomer NBR 068446 Grey body... -
Page 19: Technical Data And Dimensions
99.99% of vapor droplets greater than 0.6 µm in diameter Maximum working pressure 1500 hPa Maximum flow through the OME 17500 hPa l/s (with pump 63 m 9.2 Dimensions DN40 ISO-KF Ø 140 DN40 ISO-KF Fig. 5: Dimensions OME 40S 19/22... -
Page 20: Declaration Of Incorporation Of Partly Completed Machinery
Declaration of incorporation of partly completed machinery Declaration for product(s) of the type: Oil Mist Eliminator OME 40S We hereby declare that the listed product satisfies all relevant provisions of the following European Directives. Machinery 2006/42/EC (Annex II, no. 1 B) - Page 21 21/22...
