This operating manual refers exclusively to the following models, of our own manufacture:
9
10
11
12
13
14
15
MODBAR, Espresso System
Espresso Module
Fig. 2 - Espresso System
Legend
9 Tap Fluid Connection
10 Water Inlet
11 Drain
12 ModLink Connections
13 Tap Electrical Connection
14 Power Switch
15 Power Inlet
For additional information on electronics,
keypads, and software
please see the section entitled Software
Programming your Espresso Machine.
programming,
