172-65711M-04 (SC-F71 Communication) 24 December 2021
Multi-purpose Controller
SC-F71
Communication
Copyright © 2021 by TLV CO., LTD.
All rights reserved

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SC-F71 and is the answer not in the manual?

Questions and answers

Related Manuals for TLV SC-F71

Summary of Contents for TLV SC-F71

  • Page 1 172-65711M-04 (SC-F71 Communication) 24 December 2021 Multi-purpose Controller SC-F71 Communication Copyright © 2021 by TLV CO., LTD. All rights reserved...

  • Page 2: Table Of Contents

    7.1 Original Communication ..............130 7.2 Modbus ..................... 131 8. Specifications .................. 132 8.1 Original Communication ..............132 8.2 Modbus ..................... 132 8.3 Loader Communication ..............133 TLV EXPRESS LIMITED WARRANTY ..........134 Service ....................136 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...

  • Page 3: Introduction

    If detailed instructions for special order specifications or options not contained in this manual are required, please contact TLV for full details. This instruction manual is intended for use with the model(s) listed on the front cover.

  • Page 4: Safety Considerations

     Do not touch high-voltage connections such as power supply terminals, etc. to avoid electric shock.  TLV is not responsible if this instrument is repaired, modified or disassembled by other than factory-approved personnel. Malfunction may occur and warranty is void under these conditions.
  • Page 5 Deformation or discoloration may occur. Use a soft, dry cloth to remove stains from the instrument.  To avoid damage to the instrument display, do not rub with an abrasive material or push the front panel with a hard object. 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...

  • Page 6: Notice

     The figures, diagrams and numeric values used in this manual are only for explanation purpose.  TLV is not responsible for any damage or injury that is caused as a result of using this instrument, instrument failure or indirect damage.

  • Page 7: Symbols

    11-segment character Minus Period B (b) D (d) O (o) ＊ Degree Prime → Asterisk Š ‹ 7-segment character Minus Period B (b) D (d) N (n) O (o) ＊ Degree Prime Asterisk Š 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...

  • Page 8: Abbreviation Symbols

    LBA deadband Screens used in this manual The SC-F71 has two inputs. The following input type is available by setting parameters: Dual PV (PV + PV) type or PV + Remote setting type. The input type is set to PV + Remote setting type when shipped from the factory.

  • Page 9: Document Configuration

    Document Configuration There are seven manuals pertaining to this product. Please be sure to read all manuals specific to your application requirements. The following manuals can be requested from TLV or your local TLV representative. Document Manual Remarks Number Multi-purpose Controller SC-F71 172-65706M This manual is enclosed with instrument.

  • Page 10: About This Manual

    □ I want to check the parameter names and their setting [Parameters/Functions] range. Parameter List (This manual is enclosed with instrument.) □ I want to know how to connect this instrument to a [PLC Communication] programmable logic controller (PLC). 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...

  • Page 11: Overview

    By saving the data that was set using our communication tool PROTEM-T to a computer, the data can be transferred to other SC-F71s, allowing setup to be accomplished much more quickly than when the data is set in each SC-F71 using the front panel keys.
  • Page 12 Communication] (172-65712M).  Configuration support tool: PROTEM-T PROTEM-T is an integrated configuration support software to manage parameter setting and measured values of the controller (SC-F71) and consists of the following tools: ・ Base Tool: Used to set/verify controller parameters. ・ Recipe Tool: Used to conduct overall management of parameter set values of our controllers (storing to a computer and transfer to other controllers.)

  • Page 13: Wiring

    When actually doing this, place one solderless terminal lug over the other as illustrated below. Two solderless terminals are used overlapped. Terminal Solderless screw terminal lug Top view Panel 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...

  • Page 14: Wiring For Host Communication

    R (A) R (B) RS-422A SG T (A) T (B) RS-422A SC-F71 terminal No. Symbol Signal name R (A) Receive data R (B) Receive data Signal ground Send data T (A) Send data T (B) 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 15 *R: Termination resistors (Example: 120  1/2 W) () If communication errors occur frequently due to the T (A) operation environment or the communication distance, T (B) () connect termination resistors. Maximum connections: Up to 31 units 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 16 Refer to the COM-KG or COM-K2 Instruction Manual. A previous version of COM-K (version 1) can be also used. However, if communication tool PROTEM-T is used using a COM-K, the PROTEM-T will not be supported by Windows 8 or later. 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 17 If communication errors occur frequently due to the (−) operation environment or the communication T (A) distance, connect termination resister. T (B) () Maximum connections: Up to 31 units The cable and termination resistor(s) must be provided by the customer. 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...

  • Page 18: Connections For Loader Communication

     The loader communication corresponds to the original communication protocol “Based on ANSI X3.28-1976 subcategories 2.5 and A4.”  Loader communication can be used on the SC-F71 even when the Communication function (optional) is not installed. Recommended USB communication converter: COM-KG or COM-K2 (RKC product).
  • Page 19 While the instrument is powered by COM-KG or COM-K2 (or COM-K version 1), if power is applied to the instrument, the instrument will be reset and starts for normal operation. When the instrument is powered on, the host communication can be used simultaneously. 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...

  • Page 20: Parameter Setting

    3.1 Setting of Communication Parameter 3.1.1 Description of each parameter To establish communication between host computer (master) and SC-F71 (slave), it is necessary to set the following parameters. The communication related parameters can be found in the Function block No. 60: communication (SCI) of Engineering mode. The communication status can be monitored at “Communication response monitor.”...
  • Page 21 Even : Not settable for Modbus Interval time: The interval time for the SC-F71 should be set to provide a time for host computer to finish sending all data including stop bit and to switch the line to receive status for the host. If the interval time between the two is too short, the SC-F71 may send data before the host computer is ready to receive it.
  • Page 22  Press MODE keys simultaneously to return to the Measured value (PV)/Set value (SV) Monitor. Setting End 0000  Select RUN on the RUN/STOP transfer.  Select lock on the Set data unlock/lock transfer. 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...

  • Page 23: Communication Requirements

    - Response wait time after SC-F71 sends BCC in polling procedure - Response wait time after SC-F71 sends ACK or NAK in selecting procedure Response send time is time when interval time is set at 0 ms. Original communication (Polling procedure) processing times...
  • Page 24 Sending status a: Response send time after the SC-F71 receives BCC + Interval time b: Response wait time after the SC-F71 sends ACK or Response wait time after the SC-F71 sends NAK To switch the host computer from transmission to reception, send data must be on line.

  • Page 25: Original Communication Protocol

    The basic procedure follows ANSI X3.28-1976 subcategories 2.5 and A4 basic mode data transmission control procedure (Fast selecting is the selecting method used in this controller). In this chapter the SC-F71 is referred to as the controller.  The Polling/Selecting procedures are a centralized control method where the host computer controls the entire process.
  • Page 26 Control area is specified. If any identifier not corresponding to the memory area is assigned with a Memory area number, this Memory area number is ignored. 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 27  When data range is 0 minute 00 second to 199 minutes 59 seconds: Data range is 0:00 to 199:59, punctuation of time unit is expressed in colon “: (3AH).” 4. ETX ETX is a transmission control character used to indicate the end of text transmission. 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 28 (8) No response from host computer When the host computer does not respond within approximately three seconds after the controller sends data, the controller sends EOT to terminate the data link. (Time out: 3 seconds) 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 29 [Example: Input 1_Set value (SV) S1]  Normal transmission Host computer send Host computer send Host computer send 0 1 S 1 Address Identifier Memory area number Identifier Data Identifier Data Controller send Controller send 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 30  Error transmission Host computer send Host computer send Host computer send Error data 0 1 S 1 Address Identifier Memory area number Identifier Data Identifier Data Controller send Controller re-send 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...

  • Page 31: Selecting

    1. Memory area number (3 digits) This is the identifier to specify the Memory area number. It is expressed by K1 to K16 to each Memory area number (from 1 to 16). If the Memory area number is 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 32 <Example> When setting range is 0 to 200, the controller will receive as follows: Send data 100.5 Receive data  The controller receives a value truncated to a specified number of decimal places. The digits smaller than that will be cut off. 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 33 STX, ETX or BCC. (7) EOT (Data link termination) The host computer sends EOT when there is no more data to be sent from the host computer or there is no response from the controller. 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 34 Controller send  Error transmission Error data Host computer Host computer send Host computer re-send send 1 S 1 Address Identifier Data Identifier Data Memory area Memory area number number Controller send Controller send 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...

  • Page 35: Modbus Protocol

    5. Modbus Protocol This chapter describes the Modbus protocol. In this chapter the host computer and SC-F71 are referred to as master and slave respectively. The master controls communication between master and slave. A typical message consists of a request (query message) sent from the master followed by an answer (response message) from the slave.

  • Page 36: Function Code

    24-bit time. If time intervals become time longer than the 24-bit time the relevant slave assumes that message sending from the master is terminated and there is no response. 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...

  • Page 37: Slave Responses

     The CRC code of the master does not coincide with that of the slave.  Transmission error such as overrun, framing, parity etc., is found in the query message.  Data time interval in the query message from the master exceeds 24-bit time. 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...

  • Page 38: Calculating Crc-16

    7. Repeat step 3 through 6 for all bytes of the message (except the CRC). 8. The CRC register contains the 2 byte CRC error code. When they are appended to the message, the low-order byte is appended first, followed by the high-order byte. 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 39 Is message complete? Reverse with high-order byte and low-order byte of CRC Register n: number of shift The  symbol indicates an exclusive OR operation. The symbol for the number of data bits is n. 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 40 = CRC & 1; CRC >>= 1; if (carry) { CRC ^= 0xA001; z_p++; crch = CRC / 256; crcl = CRC % 256 z_p [z_message_length++] = crcl; z_p [z_message_length] = crch; return CRC; 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...

  • Page 41: Register Read And Write

    Error code CRC-16 High  Diagnostics (Loopback test) [08H] The master’s query message will be returned as the response message from the slave. This function checks the communication system between the master and slave. 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 42 Quantity High following range: 1 to 61 (0001H to 003DH) Number of data Number of holding registers  2 Data to first register High Any pertinent data Data to next register High CRC-16 High 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...

  • Page 43: Caution For Handling Communication Data

    The data transfer sequence is selectable at “Communication protocol” in the Engineering mode. Refer to 3.1 Setting of Communication Parameter for the Communication protocol. 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...

  • Page 44: How To Use Modbus Data Mapping

    Data to be mapped: Input 1_Measured value (PV), Input 1_Manipulated output value monitor [heat-side], Event 1 state monitor, Event 2 state monitor 1. Write register addresses of mapping data to register address setting from 1 (1000H, 1001H) to 4 (1006H, 1007H). 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 45 Event 2 state monitor 2. Reads out the mapping data by following order message. Slave address Function code Starting number High First holding register address (1500H) Quantity High Number of data (4) CRC-16 High 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...

  • Page 46: How To Use Memory Area Data

    ･ ･ ･ ･ ･ ･ ･ 07C8 07C9 1992 1993 Memory area 7 0BA8 0BA9 2984 2985 ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ 0BB2 0BB3 2994 2995 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 47 Memory area 16 0C14 0C15 3092 3093 ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ 0C1E 0C1F 3102 3103 For the memory area data list, refer to the 6.3.2 Memory area data. 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 48 The memory area data is used in three groups for the Level PID. Refer to the SC-F71 Instruction Manual [Parameters/Functions] (172-65710M) for details of Level PID. 5.9.2 Control area transfer Any memory area used for control is specified by the Memory area transfer. The area now used for control is called Control area.
  • Page 49 0068H High-order word: 0069H). Data in Memory area 3 is called up to the register addresses from 0082H to 00E7H. 2. Control is performed by using data in the register addresses from 0082H to 00E7H. 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...

  • Page 50: Communication Data List

    Data mapping address [Modbus double word]. 153E 153F 5438 5439 Refer to the 5.8 How to Use Modbus Data Mapping for the Data mapping. Refer to the 5.9 How to Use Memory Area Data for the Memory area. 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...

  • Page 51: How To Read The Table

     16-bit data (Modbus) ………… significant digit significant digit …. Least Most significant digit significant digit …………….…………………… Bit 0 Bit 15 (8) Factory set value: Factory set value of communication data …………….…………………… Bit 15 Bit 0 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 52 If they are changed unnecessarily, it may result in malfunction or failure of the instrument. TLV will not bear any responsibility for malfunction or failure as a result of improper changes in the Engineering mode.

  • Page 53: Original Communication/Modbus Data

    [Varies with the setting of the Decimal point position.]  Input 1_Manipulated output -5.0 to +105.0% 000E 000F value monitor [heat-side]  -5.0 to +105.0% Input 1_Manipulated output 0010 0011 value monitor [cool-side] 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 54 +32: Input 1_Input error low +64: Input 2_Input error high +128: Input 2_Input error low When multiple items are applicable, they are summed up.  0: OFF Input 1_Burnout state monitor 0030 0031 1: ON 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 55 Original communication: 0 to 63 DI state monitor 0036 0037 The DI state is assigned as a bit image in binary numbers. Transmission data from the SC-F71 is replaced with ASCII code in decimal number. Bit 0: DI1 Bit 1: DI2 Bit 2: DI3...
  • Page 56 Transmission data from the SC-F71 is replaced with ASCII code in decimal number. Bit 0: DO1 Bit 1: DO2 Bit 2: DO3 Bit 3 DO4 Bit 4 to Bit 7: Unused Data 0: OFF 1: ON  Modbus: 0 to 15...
  • Page 57 1: AT running now 2: ST running now -1: Aborted. Setting changed. -2: Aborted. Abnormal input. -3: Aborted. Timeout. -4: Aborted. Abnormal calculated values.  Input 2_AT/ST status monitor 0050 0051 -4 to 2 0: AT/ST complete 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 58 When the type of retransmission output is as follows: decimal point position Varies with the setting of the Input 1_Decimal point position. No retransmission output Input 1_Measured value (PV) Input 1_Local SV Input 1_SV monitor value 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 59 Do not write “1.”  Input 1_Soft start remaining time 02E6 02E7 Depends on the Soft start time selection [hour:minute] 0:00 to 99:59 (0 to 5999 [minutes]) [minute:second] 0:00 to 199.59 (0 to 11999 [seconds]) 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 60 * When ST is finished, the control will automatically return to “0.” 0: ST unused Input 2_Startup tuning (ST) 0078 0079 1: Execute once * 2: Execute always * When ST is finished, the control will automatically return to “0.” 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 61 When Control with PV select is selected at Select function min. for input 2 -(PV select input span) to +(PV select input span) [Varies with the setting of the Decimal point position.] 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 62 When Control with PV select is selected at Select function for Input 2 PV select input range low to PV select input range high ★ [Varies with the setting of the Decimal point position.] 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 63 (When Control with PV select: 0.0 to 1000.0% of PV select input span) ★ 0 (0.0, 0.00): ON/OFF action NOTE: 0 (0.0, 0.00) cannot be set when temperature control operation [MC-(V)COS(R)] is selected for Input 1_Control action. 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 64 (When Control with PV select: 0 to PV select input span) [Varies with the setting of the Decimal point position.] Voltage (V)/Current (I) inputs (When Control with PV select: 0.0 to 1000.0% of PV 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 65 3, 10, 11, 14: No decimal place 2, 12: 1 digit 0, 1, 13: 2 digits ★ 4: 3 digits Table 1: Factory set value of the Dead zone Control Valve coefficient F (pressure unit) 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 66 ─ ─ ─ ─ 0.03 0.03 0.003 ─ ─ ─ ─ 0.04 0.04 0.004 ─ ─ ─ ─ 0.10 0.10 0.010 ─ ─ ─ ─ 0.10 0.10 0.010 ─ ─ ─ ─ ─ 0.14 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 67 -100.0 to +100.0% of Input 1_Input span (When Control with PV select: -100.0 to +100.0% of PV select input span) Minus (-) setting results in Overlap. However, the ★ overlapping range is within the proportional range. 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 68 104 Input 1_Soft start time (down) 02F0 02F1 Depends on the Soft start time selection 0:00 (0 minutes 00 ★ [hour:minute] 0:00 to 99:59 (0 to 5999 [minutes]) seconds) [minute:second] 199.59 (0 to 11999 [seconds]) 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 69 [Varies with the setting of the Decimal point position.] 112 Input 2_Setting change rate 00E0 00E1 0 to Input 2_Input span limiter (down) 0: No function ★ [Varies with the setting of the Decimal point position.] 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 70 4: 200 ms 9: 450 ms 5: 250 ms 10: 500 ms * When “Cascade control” or “2-loop control/Differential temperature control” is selected, Display update cycle is 100 ms even when “1” is selected. 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 71 (When Control with PV select: 0.0 to 25.00% of PV select input span) 125 OUT3 proportional cycle time 00FE 00FF 0.1 to 100.0 seconds 126 OUT3 minimum ON/OFF time 0104 0105 0 to 1000 ms of proportional cycle 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 72  Input 1_Output limiter low [cool-side] is  0.0 %: -(Input 1_Output limiter high [cool-side]) to -(Input 1_Output limiter low [cool-side]) (3) Fixed at 0.0% in the following cases: Input 1_Output limiter high [cool-side]  0.0%, and Input 1_Output limiter high [heat-side]  0.0% 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 73 (Input 1_Level PID setting 1)  (Input 1_Level PID setting 2)  (Input 1_Level PID setting 3)  (Input 1_Level PID setting 4)  (Input 1_Level PID setting 5)  (Input 1_Level PID setting 6)  (Input 1_Level PID setting 7) 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 74 Input 2_Output limiter low to whichever the smaller value of either "calculated value from Input 2_ Pressure (temperature) limiter" or "Input 2_Output limiter high”. When STOP is set, Input 2_Output limiter low to Input 2_Output limiter high. 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 75 (Input 2_Level PID setting 1)  (Input 2_Level PID setting 2)  (Input 2_Level PID setting 3)  (Input 2_Level PID setting 4)  (Input 2_Level PID setting 5)  (Input 2_Level PID setting 6)  (Input 2_Level PID setting 7) 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 76 [Varies with the setting of the Decimal point position.] 151 FF amount learning 0142 0143 0 to 3 0: No learning +1: Learn Input 1 +2: Learn Input 2 To select two or more functions, sum each value. 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 77 0 to 3600 seconds, 0.0 to 3600.0 seconds or 0.00 to 360.00 159 Cascade_Derivative time 0152 0153 seconds (slave-side) 0 (0.0, 0.00): PI action [Varies with the setting of the Integral/Derivative time decimal point position.] 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 78 [Varies with the setting of the Decimal point position.] 164 PV select transfer time 015C 015D 0.0 to 100.0 seconds 165 Input 1_Overshoot prevention 02F6 02F7 0: No feature 1: Yes 166 Input 2_Overshoot prevention 02F8 02F9 0: No feature 1: Yes 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 79 If they are changed unnecessarily, it may result in malfunction or failure of the instrument. TLV will not bear any responsibility for malfunction or failure as a result of improper changes in the Engineering mode.
  • Page 80 0: SET key method 179 Data registration 0170 0171 Used to register the Set value (SV) using the SET key. 1: Direct registration Used to register the Set value (SV) without pressing the SET key. 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 81 22: Voltage input -5 to +5 V DC 10: TC input U 23: Voltage input 0 to 100 mV DC 11: TC input L 24: Voltage input 0 to 10 mV DC 12: TC input PR40-20 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 82 - (Input determination point (low) [Varies with the setting of the Decimal point position.] 1_5% of input * When Input type of Input 1 is RTD, low limit value is about span) 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 83 195 Input 2_Decimal point position 0192 0193 1: One decimal place 4: Four decimal places Decimal point 2: Two decimal places position TC input: W5Re/W26Re, PR40-20: 0 (fixed) Thermocouples other than those shown above: 0 or 1 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 84 [Varies with the setting of the Decimal point position.] 2_5% of input * When Input type of Input 2 is RTD, low limit value is about span) 2 Ω. (Pt100: -245.5 C [-409.8 F] , JPt100: -237.6 C [- 395.7 F]) 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 85 19: Memory area transfer (16 points, With area set signal) 20: Area jump 205 DI2 function selection 01A6 01A7 0 to 14 Same as DI1 function selection (0 to 14) 0 to 14 206 DI3 function selection 01A8 01A9 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 86 0 to 14 208 DI5 function selection 01AC 01AD Same as DI1 function selection (0 to 14) 0 to 14 209 DI6 function selection 01AE 01AF Same as DI1 function selection (0 to 14) 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 87 13: Output while Set value of Input 2 is changing 14: Output of the communication monitoring result 15: FAIL output Same as OUT1 function selection 213 OUT2 function selection 01B6 01B7 Same as OUT1 function selection 214 OUT3 function selection 01B8 01B9 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 88 +4: Event 3 +8: Event 4 +256: Input 1_Input error high +512: Input 1_Input error low +1024: Input 2_Input error high +2048: Input 2_Input error low To select two or more functions, sum each value. 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 89 7: Input 2_Measured value (PV) 8: Input 2_Local SV 9: Input 2_SV monitor value 10: Input 2_Deviation 11: Input 2_Manipulated output value 12: Remote setting input value 13: Measured value (PV) of differential temperature input 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 90 Measured value (PV) of differential temperature input Manipulated output -(Input 1_Input span) to +(Input 1_Input span) value: 100.0 [Varies with the setting of the Decimal point position.] Measured value (PV) of differential temperature input: 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 91 Same as Retransmission output 1 type 229 Retransmission output 2 scale 01D0 01D1 Same as Retransmission output 1 scale high high 230 Retransmission output 2 scale 01D2 01D3 Same as Retransmission output 1 scale low 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 92 +4: Event 3 +8: Event 4 +16: Input 1_Input error high +32: Input 1_Input error low +64: Input 2_Input error high +128: Input 2_Input error low To select two or more functions, sum each value. 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 93 20: MV low [heat-side] 21: MV high [cool-side] 22: MV low [cool-side] 23: Process high/low [High/Low individual setting] 24: Process band [High/Low individual setting] Event hold and re-hold action is available. Event hold action is available. 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 94 259 Event 4 hold action 020C 020D Same as Event 1 hold action 260 Event 4 differential gap 020E 020F Same as Event 1 differential gap 261 Event 4 timer 0210 0211 Same as Event 1 timer 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 95 +2: SV tracking at transferring Auto/Manual To select two or more functions, sum each value. 270 Integral/Derivative time 0228 0229 0: No decimal place decimal point position 1: One decimal place 2: Two decimal places 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 96 The operation mode remains in the Auto mode and the Manipulated output at Input error of Input 1 is output. When the error is recovered, the operation mode is switched to the PID control. 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 97 5: Pressure control operation [MC-COS(R)-16, 65 to 150 mm] 6: Pressure control operation [MC-COS(R)-21] 7: Pressure control operation [MC-VCOS(R)] 8: Temperature control operation [MC-COS(R)-16] 9: Temperature control operation [MC-VCOS(R)] For cascade control, only 0 or 1 is selectable. 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 98 2: Switching by Measured value (PV) (Level PID action) 291 Input 2_Level PID differential 0252 0253 0 to Input 2_Input span TC/RTD inputs: 2 [Varies with the setting of the Decimal point position.] V/I inputs: 0.2 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 99 298 Input 1_Valve coefficient F 0316 0317 0: Atmospheric pressure standard Product pressure standard 1: Absolute pressure standard identification code specified at the time of order. 299 Input 1_Control valve selection 0318 0319 0: MC-VCOS(R) 1: PC-VCOS(R) 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 100 1: No 304 Input 1_Response speed 0322 0323 0 to 9999 seconds learning parameter t1 0 up 305 Input 1_Response speed 0324 0325 0 to 9999 seconds learning parameter t2 0 down 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 101 0347 -1999 to 9999 323 Input 2_Valve coefficient C 0348 0349 -1999 to 9999 -1999 to 9999 324 Input 2_Valve coefficient d 034A 034B -1999 to 9999 325 Input 2_Valve coefficient E 034C 034D 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 102 [Varies with the setting of the Decimal point position, when a setting is other than 8 for Input 2_Control action.] NOTE: Pressure (temperature) limiter function is OFF when 0 (0.0, 0.00, 0.000) is set 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 103 S3 set up 344 Input 2_Response speed 0372 0373 0 to 9999 seconds learning parameter S4 set down 345 Input 2_No. of corrective 0374 0375 0 to 99 times (99: unlimited times) actions 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 104 6: Input circuit error alarm Selectable range is limited depending on Input 1_ Control action. PID control: 0 to 6 When pressure control operation [MC-(V)COS(R)] is selected: 0 to 2, 6 Heating/Cooling control: 0 to 3, 6 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 105 0 PLC communication: 0 to 30 Modbus: 1 communication: 0 363 Communication speed 027A 027B 0: 2400 bps 1: 4800 bps 2: 9600 bps 3: 19200 bps 4: 38400 bps 5: 57600 bps 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 106 0 to 255 seconds 372 PLC response waiting time 028C 028D 0 to 3000 ms 373 PLC communication start time 028E 028F 1 to 255 seconds 374 Slave register bias 0290 0291 0 to 65535 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 107 (When Control with PV select: Input 1_Setting limiter low (When Control with to PV select input range high) PV select: PV select [Varies with the setting of the Decimal point position.] input range high) 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 108 401 Set lock level 02BE 02BF The Set lock level is assigned as a bit image in binary numbers. Transmission data from the SC-F71 is replaced with ASCII code in decimal number. Bit 0: SV setting mode + Parameter select mode...
  • Page 109 Same as the Parameter select setting 1 419 Parameter select setting 15 02E2 02E3 Same as the Parameter select setting 1 420 Parameter select setting 16 02E4 02E5 Same as the Parameter select setting 1 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 110 When Control with PV select is selected at Select function for Input 2 PV select input range low to PV select input range high [Varies with the setting of the Decimal point position.]  Manipulated output value: -5.0 to +105.0% 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 111 [Varies with the setting of the Decimal point position.] Voltage (V)/Current (I) inputs 0.0 to 1000.0% of Input 1_Input span (When Control with PV select: 0.0 to 1000.0% of PV select input span) 0 (0.0, 0.00): ON/OFF action 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 112 (When Control with PV select: 0.0 to 1000.0% of PV select input span) 0 (0.0, 0.00): ON/OFF action NOTE: 0 (0.0, 0.00) cannot be set when temperature control operation [MC-(V)COS(R)] is selected for Input 2_Control action. 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 113 0 to 3600 seconds, 0.0 to 3600.0 seconds or 0.00 to 360.00 Input 1_Integral time [cool-side] 0544 0545 1348 1349 seconds 0 (0.0, 0.00): PD action [Varies with the setting of the Integral/Derivative time decimal point position.] 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 114 0 hours 00 minutes 00 seconds to 9 hours 59 minutes 59 communication: seconds 0:00 (0 minutes 00 0 hours 00 minutes to 99 hours 59 minutes seconds) 0 minutes 00 seconds to 199 minutes 59 seconds Modbus: 0 (0 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 115 1374 1375 0: No function [Varies with the setting of the Decimal point position.] 0: No transfer Input 2_Auto/Manual transfer selection (Area) 0560 0561 1376 1377 1: Auto mode (bumpless) 2: Auto mode (bump) 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 116 [Decimal point position depends on the setting for Input 1_ Factory set value Valve coefficient F.] of the Dead zone 3, 10, 11, 14: no decimal point place 2, 12: one digit 0, 1, 13: two digits 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 117 ─ 0.03 0.03 0.003 ─ ─ ─ ─ ─ 0.04 0.04 0.004 ─ ─ ─ ─ ─ 0.10 0.10 0.010 ─ ─ ─ ─ ─ 0.10 0.10 0.010 ─ ─ ─ ─ ─ 0.14 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 118 0593 1426 1427 05F8 05F9 1528 1529 065E 065F 1630 1631 06C4 06C5 1732 1733 Input 2_Integral time 0594 0595 1428 1429 05FA 05FB 1530 1531 0660 0661 1632 1633 06C6 06C7 1734 1735 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 119 2933 0B80 0B81 2944 2945 0B8C 0B8D 2956 2957 0B98 0B99 2968 2969 Input 2_Soft start time (down) 0B76 0B77 2934 2935 0B82 0B83 2946 2947 0B8E 0B8F 2958 2959 0B9A 0B9B 2970 2971 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 120 0725 1828 1829 078A 078B 1930 1931 07F0 07F1 2032 2033 0856 0857 2134 2135 Input 2_Proportional band 072A 072B 1834 1835 0790 0791 1936 1937 07F6 07F7 2038 2039 085C 085D 2140 2141 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 121 2981 0BB0 0BB1 2992 2993 0BBC 0BBD 3004 3005 0BC8 0BC9 3016 3017 Input 2_Soft start time (down) 0BA6 0BA7 2982 2983 0BB2 0BB3 2994 2995 0BBE 0BBF 3006 3007 0BCA 0BCB 3018 3019 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 122 08C2 08C3 2242 2243 0928 0929 2344 2345 098E 098F 2446 2447 09F4 09F5 2548 2549 Input 2_Integral time 08C4 08C5 2244 2245 092A 092B 2346 2347 0990 0991 2448 2449 09F6 09F7 2550 2551 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 123 3029 0BE0 0BE1 3040 3041 0BEC 0BED 3052 3053 0BF8 0BF9 3064 3065 Input 2_Soft start time (down) 0BD6 0BD7 3030 3031 0BE2 0BE3 3042 3043 0BEE 0BEF 3054 3055 0BFA 0BFB 3066 3067 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 124 0B20 0B21 2848 2849 Input 2_Proportional band 0A5A 0A5B 2650 2651 0AC0 0AC1 2752 2753 0B26 0B27 2854 2855 Input 2_Integral time 0A5C 0A5D 2652 2653 0AC2 0AC3 2754 2755 0B28 0B29 2856 2857 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 125 Input 2_Soft start time (up) 0C04 0C05 3076 3077 0C10 0C11 3088 3089 0C1C 0C1D 3100 3101 Input 2_Soft start time (down) 0C06 0C07 3078 3079 0C12 0C13 3090 3091 0C1E 0C1F 3102 3103 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 126 Low-order word 1516H, high-order word 1517H] Register address setting 13 [Read/write address: 1018 1019 4120 4121 Low-order word 1518H, high-order word 1519H] Register address setting 14 [Read/write address: 101A 101B 4122 4123 Low-order word 151AH, high-order word 151BH] 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 127 Low-order word 153AH, high-order word 153BH] Register address setting 31 [Read/write address: 103C 103D 4156 4157 Low-order word 153CH, high-order word 153DH] Register address setting 32 [Read/write address: 103E 103F 4158 4159 Low-order word 153EH, high-order word 153FH] 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 128 (Low-order word 1018H, high-order word 1019H) Data specified Register address setting 14 151A 151B 5402 5403 (Low-order word 101AH, high-order word 101BH) Data specified Register address setting 15 151C 151D 5404 5405 (Low-order word 101CH, high-order word 101DH) 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...
  • Page 129 (Low-order word 103AH, high-order word 103BH) Data specified Register address setting 31 153C 153D 5436 5437 (Low-order word 103CH, high-order word 103DH) Data specified Register address setting 32 153E 153F 5438 5439 (Low-order word 103EH, high-order word 103FH) 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...

  • Page 130: Troubleshooting

    The power must be turned off before repairing work for input break and output failure including replacement of sensor, contactor or SSR, and all wiring must be completed before power is turned on again. 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...

  • Page 131: Original Communication

    This section lists some of the main causes and solutions for communication problems. If you cannot solve a problem, please contact TLV. 7.1 Original Communication Problem Possible cause Solution No response Wrong connection, no connection or Confirm the connection method or...

  • Page 132: Modbus

    Error code 4 Self-diagnostic error Turn off the power to the instrument. If the same error occurs when the power is turned back on, please contact TLV. 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...

  • Page 133: Specifications

     The setting of the number of data (the number of requested byte) is not set to a double of the requested number of data at the time of “Preset multiple registers (Write multiple registers)” 4: Self-diagnostic error response 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...

  • Page 134: Loader Communication

    While the instrument is powered by COM-KG or COM-K2 (or COM-K version 1), if power is applied to the instrument, the instrument will be reset and starts for normal operation. When the instrument is powered on, the host communication can be used simultaneously. 172-65711M-04 (SC-F71 Communication) 24 Dec 2021...

  • Page 135: Tlv Express Limited Warranty

    Subject to the limitations set forth below, TLV CO., LTD., a Japanese corporation (“TLV”), warrants that products which are sold by it, TLV International Inc. (“TII”) or one of its group companies excluding TLV Corporation (a corporation of the United States of America), (hereinafter the “Products”) are designed and manufactured by TLV, conform...
  • Page 136 WARRANTY NOT NEGATED HEREBY, AND ANY IMPLIED WARRANTY NOT NEGATED HEREBY, INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, DO NOT COVER, AND NEITHER TLV, TII NOR ITS TLV GROUP COMPANIES WILL IN ANY EVENT BE LIABLE FOR, INCIDENTAL OR...

  • Page 137: Service

    Service For Service or Technical Assistance: Contact your TLV representative or your regional TLV office. In Europe: Tel: [49]-(0)7263-9150-0 Daimler-Benz-Straße 16-18, 74915 Waibstadt, Germany Fax: [49]-(0)7263-9150-50 Tel: [44]-(0)1242-227223 Units 7 & 8, Furlong Business Park, Bishops Cleeve, Gloucestershire GL52 8TW, U.K.

Table of Contents
