TECO Platinum 3D Inverter Series User Manual

Hide thumbs Also See for Platinum 3D Inverter Series:

Quick start manual (6 pages)

Operation & installation manual (40 pages)

Table Of Contents

Quick Links

SPLIT-TYPE ROOM AIR CONDITIONER

User Manual

Platinum 3D Inverter Series

Models:

TWS-TSO26H3DVGA

TWS-TSO35H3DVGA

TWS-TSO50H3DVGA

TWS-TSO70H3DVGA

TWS-TSO80H3DVGA

IMPORTANT NOTE:

Thank you for selecting a TECO quality Air Conditioner.

Read this manual carefully before installing or operating

your new air conditioning unit. Make sure to save this

manual for future reference.

The design and specifications are subject to change

without prior notice for product improvement. Consult

with the sales agency or manufacturer for details.

Table of Contents

Need help?

Do you have a question about the Platinum 3D Inverter Series and is the answer not in the manual?

Questions and answers

Summary of Contents for TECO Platinum 3D Inverter Series

Page 1 TWS-TSO50H3DVGA TWS-TSO70H3DVGA TWS-TSO80H3DVGA IMPORTANT NOTE: Thank you for selecting a TECO quality Air Conditioner. Read this manual carefully before installing or operating your new air conditioning unit. Make sure to save this manual for future reference. The design and specifications are subject to change without prior notice for product improvement.
Page 3: Table Of Contents
Maintenance and repair requiring the assistance of other skilled personnel shall be carried out under the supervision of the person competent in the use of flammable refrigerants. For more details, please contact TECO Australia’s Service on 1300 660 037.
Page 4: Safety Precautions
SAFETY PRECAUTIONS Read Safety Precautions Before Operation WARNING CAUTION This symbol indicates the possibility This symbol indicates the possibility of of personnel injury or loss of life. property damage or serious consequences. WARNING • This appliance is not intended for use by persons(including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
Page 5 CAUTION Turn off the air conditioner and disconnect the power if you are not going to use it for a long time. • Turn off and unplug the unit during storms. • Make sure that water condensation can drain unhindered from the unit. •...
Page 6: Names Of Parts
NAMES OF PARTS Display window Emergency button NOTE ON ILLUSTRATIONS Illustrations in this manual are for explanatory purposes. The actual shape of your indoor unit may be slightly different. The actual shape shall prevail.
Page 7: Emergency Function
EMERGENCY FUNCTION & AUTO-RESTART FUNCTION If the remote controller fails to work or maintenance necessary, proceed as following: front panel Open and lift the front panel up to an angle to reach the emergency button. If the button is pushed when the unit is OFF, the air conditioner will operate in AUTO mode.
Page 8: Remote Controller
REMOTE CONTROLLER 1. ON/OFF Button * Press this button to turn on/ off the unit. * T his will clear the existing timer and SLEEP settings. 2. MODE Button * Press this button, you can select the running mode as follows: r AUTO COOL HEAT...
Page 9 REMOTE CONTROLLER 4. COOL Button * Press this button to enter COOL mode. 5. HEAT Button * Press this button to enter HEAT mode. 6. TIMER Button * With the unit ON, press this button to set OFF timer or with it OFF to set ON timer.
Page 10 REMOTE CONTROLLER Note: * When the unit is on, press the "U/D S WING" button and hold for 3 seconds, the button will shift to be the functional button of "Rated swinging", and then press the "U/D SWING" button to select the positions of Rated swinging.
Page 11 REMOTE CONTROLLER • SILENCE When the unit is on, press the "MENU" button, then press 1:,. , 'v , <l and t> to choose the "SILENCE" character, when the "SILENCE" character will blink, and press the "OK" button to highlight (not highlight ) the "SILENCE" character , which will activate (deactivate) the function of silent wind.
Page 12 • Anti-F Anti-F function: When the unit is closed under the modes of cooling, dry or auto (cooling), it will continue to operate for about 3 minutes to dry the moisture on the evaporator, so as to prevent the accumulation of bacteria on the evaporator, which causes fungus and strange smell and is harmful to the health .
Page 13: Operating Instructions
OPERATING INSTRUCTIONS Fix batteries 1.Slide to open the cover according to the direction indicated by the arrowhead. 2.lnsert two brand new batteries (7#), and position the batteries to the right electric poles(+&-). 3.Put back the cover. Auto operation mode 1. Press the "MODE" button, select the auto operation mode. 2.
Page 14 OPERATING INSTRUCTIONS OPERATING INSTRUCTIONS Fan operation mode 1. Press the "MODE" button, select the fan operation mode. 2. By pressing the "SPEED" button, you can select the fan speed from LOW, MID, HIGH. 3. Press the "ON/OFF" button, the air-conditioner starts to operate.
Page 15 OPERATING INSTRUCTIONS Operation range The table below indicates the temperature ranges the air conditioner can be operated within. 18°C~32°C 18°C~32°C 0°C~24°C -7°C~43°C -7°C~24°C -7°C~43°C If air conditioner is used outside of the above conditions, certain safety protection features might come into operation and cause the unit to function abnormally. The unit does not operate immediately if it is turned on after being turned off or after changing the mode during operation.
Page 16: Maintenance
MAINTENANCE The Owner is responsible for regular maintenance of the equipment to ensure the air conditioner operates efficiently. It is recommended that a qualified & licenced technician is contracted to service the air conditioner at least once a year. INDOOR UNIT - ANTI-DUST FILTERS CLEAN 1.
Page 17: Troubleshooting
TROUBLESHOOTING MALFUNCTION POSSIBLE CAUSES Power failure/ Circuit Breaker tripped Faulty indoor/outdoor unit fan motor Faulty compressor The appliance does not Faulty protective device or fuses. operate Loose connections or Isolator switched off It sometimes stops operating to protect the appliance. Voltage higher or lower than the normal operating voltage range Active TIMER-ON function Faulty electronic control board...
Page 18: Repairs, Services & Warranty
If you have a problem, and the problem persists after you have made the checks mentioned in this manual, contact: TECO Australia’s Service on 1300 660 037 (8:30am - 4pm Mon~Fri AEST) For warranty details please visit www.teco.com.au Service Email: had.service@teco.com.au...
Page 19 Did you know? TECO Australia’s product range also includes: Top Load Clothes Washers Front Load Clothes Washers Auto Sensing Vented Clothes Dryers Refrigerators Chest and Vertical Freezers Bar Fridges Televisions Air Curtains Air Conditioners Visit www.teco.com.au for our full range.
Page 20 HCA-V2 E&OE...

This manual is also suitable for:

Tws-tso26h3dvga Tws-tso35h3dvga Tws-tso50h3dvga Tws-tso70h3dvga Tws-tso80h3dvga
