Summary of Contents for Invixium TITAN
- Page 1 Feature Description Document Configuring Door Strike Power Supply INVIXIUM XAD-FDD-524-02G...
- Page 2 All Devices Description TITAN, TFACE, TOUCH 2 & SENSE 2 are equipped with the ability to redirect all their extra power and use it to supply to the Electric Door Strike, removing the need to have 2 separate power sources - 1 for the device and 1 for the door strike. Activating the Door Strike Power Supply feature will trigger a specified power supply to the connected strike.
- Page 3 From Home >> Click the Device tab on the top >> Select the required Device >> Navigate to the Access Control tab for the device >> Click on Door Strike Power Supply 2. Toggle the “Door Strike Power Supply” switch on the right to enable the Door Strike Power Supply feature. INVIXIUM XAD-FDD-524-02G...
- Page 4 4. Click Apply to save the settings to the IXM device. 5. To reset the Door Strike Power Supply settings back to default, click Reset. A “Door strike power supply settings restored” message will be displayed. Click OK. INVIXIUM XAD-FDD-524-02G...
- Page 5 Configuring Door Strike Power Supply on the LCD Menu 1. Swipe to the Door Access app from the Menu screen. Tap on the Door Access icon. The device will prompt for device security authentication before opening the app (The default PIN is 0000). INVIXIUM XAD-FDD-524-02G...
- Page 6 2. Tap on Door Strike Power Supply. INVIXIUM XAD-FDD-524-02G...
- Page 7 3. Toggle Status to ON to enable settings. 4. Select supply mode as 12V or 24V (TOUCH 2 and SENSE 2 only support a 12V door strike) and tap the Save icon on the top right to store the settings. INVIXIUM XAD-FDD-524-02G...
- Page 8 This document and the information described throughout are provided in their present condition and are delivered without written, expressed, or implied commitments by Invixium Inc. and are subject to change without notice. The information and technical data herein are strictly prohibited for the intention of reverse engineering and shall not be disclosed to parties for procurement or manufacturing.
