Porta Ethernet
1
Ethernet port
1
8
Ethernet
Pin
Signal
Pin
Signal
1
ETH1
5
N.C.
2
ETH2
6
ETH6
3
ETH3
7
N.C.
4
N.C.
8
N.C.
LED Yellow
Speed 1Gbs
LED Green
Speed 10/100Mbs
Alimentazione/Stato CPU
8
8
Power supply/CPU Status
CPU Status
LED
Function
ON=Power OK
PWR
(LD1)
OFF= Power
(Green)
fault
A/V
RUN
Regular Blink =
(LD4)
System OK
(Yellow)
ON=System
HDMI
RDY
Ready
(LD3)
OFF=System Not
(Green)
Ready
USB
Solo per alimentazione aux. 5Vdc
Auxiliary power supply 5Vdc only
microSD
P8
1
1
LD1 LD3 LD4
Fuse 1AT
Tenere corto e distante
da fonti di disturbo
!
Vmax=30Vdc
Keep it short and away
from noise sources
Messa a terra pulita
Clean GND
USB Host
2
Host USB
USB Host
Pin
Signal
1
Vcc
(5V 100mA/port
max.)
2
D-
3
D+
4
ID
5
GND
Bus 1-Wire e Bus espansione
9
1-Wire and Extension bus
9
1
1
P11
10
2
P7
Bus 1-Wire
Bus I
2
C (P7)
(P11)
Pin
Signal
Pin
Signal
Pin
1
1-Wire
1
+5Vdc
6
2
GND
2
+5Vdc
7
3
+5V (Aux)
8
4
+5V (Aux)
9
5
RDYO-N
10
Bus di campo
4
Field bus
LK1
Field Bus (P2)
CAN
Pin
Signal
Pin
1
CAN H
1
2
CAN L
2
3
Field GND
3
LK1
ON= Line Terminated (120Ω)
Identificazione prodotto
7
Product identification
LBL052E000
MPS055**00
Code:
00348
Serial Nr:
Collegamento moduli di espansione
10
Extension modules connection
Signal
GND
SCL
GND
SDA
GND
Dimensioni
5
Dimensions
119mm
3
1
P1
RS485
Signal
D+
D-
Field GND
MPS055**00
Livello modulo
Module release
Lite version = 0
RS485 version = 1
CAN version = 2
SlimLine
SlimLine
Raspberry PI
Raspberry PI
CPU Module
CPU Module
Hardware
Hardware
Via G. Brodolini, 15 (Z.I.) 15033 CASALE M.TO (AL) ITALY
22,5mm
Manual
Manual
MNL195A100
Phone +39-0142-451987 Fax +39-0142-451988
Internet:
http://www.elsist.it
email:
elsist@elsist.it
