Elsist SlimLine MPS056B110 Hardware Manual

Porta Ethernet
1 2
Ethernet port
P2
8 1
Ethernet (P2)
Pin Signal Pin Signal
1 ETH1 5 N.C.
2 ETH2 6 ETH6
3 ETH3 7 N.C.
4 N.C. 8 N.C.
LED Yellow Link activity
LED Green Speed 100Mb/s
DHCP enabled
Stato CPU – I/O
5
CPU – I/O Status
CPU Status
LED Function
ON=Power OK
PWR
(Green)
OFF= Power fault
RUN Regular Blink =
(Yellow) System OK
ON=System Ready
RDY
(Green)
OFF=System Stopped
DIxx ON=Input activated
(Red) OFF= Input activated
DOxx ON=Output activated
(Red) OFF= Output activated
USB
USB activity
(Yellow)
Uscite digitali e porta RS232+USB
7
Digital Outputs and RS232+USB Port
1 8
1
6
P5 P4 P10
1 2 3 4 5 6
~ _ ~ _
Ingressi Digitali/Analogici
Digital/Analog Inputs P2
8
1
+/- +/-
-/+ -/+
8 7 6 5 4 3 2
8
USB (P10)
Pin Signal
Vcc (5V 1A max.)
1
Short circuit protected
2 D-
3 D+
4 GND
RS232 (COM0 P4)
Pin
Pin Signal Pin Signal
1
1 Not connected 5 RX
2
2 Not connected 6 TX
3
3 DTR 7 CTS
4
4 GND 8 RTS
5
Alimentazione
3
P1 P3 Power Supply
1 3 1
P8
1
Voltage 0-10V
1,5mmq
16AWG
+ + !
Fuse 1AT
1
3 2 1
Messa a terra pulita
Clean GND
Identificazione prodotto
6
Product identification
LBL052E 000
MPS056B110
Code:
Serial Nr: 00183
Collegamento moduli di estensione
9
Extension modules connection
Bus di estensione
Extension bus
9 1
10 2
P10 P7
BUS I 2 C (P7)
Signal Pin Signal
+5Vdc 6 GND
+5Vdc 7 SCL
+5V (Aux) 8 GND
+5V (Aux) 9 SDA
RDYO-N 10 GND
Dimensioni
4
Dimensions
Tenere corto e distante
da fonti di disturbo
Keep it short and away
from noise sources
Vmax = 30Vdc
=
+ ~
~
- ~
MPS056***0
Livello modulo
Module release
Relay = 1
Static = 3
SSR = 4
Base = 1
Extended = 2
119mm 22,5mm
SlimLine
SlimLine
Compact Eth
Compact Eth
CPU Module
CPU Module
Hardware
Hardware
Manual
Manual
MNL197B100
