- Page 1 60GMilimeterwave Bio-sensing radar R60APS1-People counting module using guide Please read the product instructions carefully before use and keep them properly V1.0 MicRadar Technology (Shenzhen) Co. ,LTD...
- Page 2 R60APS1- People counting module using guide 1. Product description People counting radar, based on information such as the amplitude of personnel movement, distance change, angle resolution, etc., to detect the basic position of personnel.Count the number of stationary people based on their breathing and subtle posture changes.
- Page 3 R60APS1- People counting module using guide 4. Module package size and pin description Radar module structure diagram Pin description Note: 1) GP1~GP6 are parameter selection control terminals, which can be redefined according to user needs. 2) The output signals of this interface are all 3.3V level.
- Page 4 6. Power-up and data rules 7. Radar Installation Instructions 7.1. Working range of radar module The beam coverage of the R60APS1 radar module is shown in the figure below. Radar coverage is 100 ° horizontal. Schematic diagram of R60APS1 radar coverage area 7.2.
- Page 5 R60APS1- People counting module using guide human detection is L3 ≈ 10 meters; the maximum distance of human static position detection is L2 ≈ 6 meters. (Note: The minimum angle of multi-target moving position detection for multi-person distinction: ≥ 20 ° , the minimum distance for multi-target stationary position detection: ≥0.5 meters)
- Page 6 R60APS1- People counting module using guide the first move freely pass time 8.2. Static position detection test: Static distance information accuracy test: The mobile test is carried out within the radar detection range, and when it stops at a random position, the distance reported by the radar at the...
- Page 7 R60APS1- People counting module using guide Whether it is within the accuracy requirements the first 50° pass time 9. Guide to the actual installation steps of the radar Step 1: Confirm the main activity and stay area of the person, which is...
- Page 8 R60APS1- People counting module using guide Radar needs to be planned in terms of installation angle. Non-interference factors: radar electromagnetic waves will penetrate human clothing,curtains,thin wood, glass. The installation angle and performance of the radar need to be determined according to the application.
