MicRadar R24BBD1 Instructions Manual
Bio-sensing radar
Hide thumbs
Also See for R24BBD1:
- Applications manual (11 pages) ,
- Instructions for use manual (8 pages) ,
- Manual (20 pages)
Related Manuals for MicRadar R24BBD1
Summary of Contents for MicRadar R24BBD1
- Page 1 24GMilimeterwave Bio-sensing radar R24BBD1-Respiratory sleep module using guide Please read the product instructions carefully before use and keep them properlyV1.0 MicRadar Technology (Shenzhen) Co. ,LTD...
-
Page 2: Product Description
R24BBD1- Respiratory sleep module using guide 1. Product description Based on the millimeter-wave radar system, the breathing and sleep radar realizes the perception of human biological existence and human motion, continuously records the sleep state of the human body, and judges... - Page 3 R24BBD1- Respiratory sleep module using guide DP4: Body Motion Amplitude Parameter Output data once every 5 seconds [Reference: 0 – 100 Description of Body Motion Amplitude Parameter Output] DP5: Getting in/Out of bed From bed to bed, report within 0.5s...
- Page 4 R24BBD1- Respiratory sleep module using guide 2%-30% micro-motion Only slight head or limb movement Ambulation/rapid body 31%-60% slower body movement movements 61%-100% running/close range rapid body movement TEL:0755-88602663 sales@micradar.cn www.micradar.cn 501, West Block, Phase II, Tian 'an Innovation Technology Plaza, Futian District, Shenzhen...
-
Page 5: Tool Preparation
R24BBD1- Respiratory sleep module using guide 4. Module package size and pin description Radar module structure diagram Pin description Note: 1) S1 output: high level - someone, low level - no one; 2) S2 output: high level - active, low level - still 3) GP1~GP4 are parameter selection control terminals, which can be redefined according to user needs. - Page 6 7. Radar Installation Instructions 7.1. Working range of radar module The beam coverage of the R24BBD1 radar module is shown in the figure below. The radar coverage is a three-dimensional sector area of 40° in the horizontal and 40° in the elevation.
- Page 7 R24BBD1- Respiratory sleep module using guide 7.2.1 Inclined installation If the related detection function of breathing and sleep radar is used in sleep health applications, the radar needs to be installed obliquely above the head of the bed for detection.
- Page 8 R24BBD1- Respiratory sleep module using guide Bed state judgment test: When no one enters the radar detection range, it will respond immediately and report the state of entering bed When the radar state changes from getting Install the radar according to the out of bed - "into bed, it stops at the...
- Page 9 R24BBD1- Respiratory sleep module using guide your breath for 30s~40s after 1 minute breathing value can be reported as 0 Watch the radar status change times/min after holding the breath for about 30s~40s, and the abnormal breath holding alarm is reported, it means "passed"...
- Page 10 R24BBD1- Respiratory sleep module using guide Example: Space size: 10 ㎡ - 20 ㎡ Interference source: air conditioner outdoor unit/blackout curtain/partition wall Recommended installation sensitivity: 4 (adjust 6 or 8 according to the size of the space) Scene mode recommendation: area detection...
- Page 11 R24BBD1- Respiratory sleep module using guide to the radar, and the shaking of metal curtains can cause false positives. Radar needs to be planned in terms of installation angle. Non-interfering factors: radar electromagnetic waves will penetrate human clothing, curtains, thin wood, and glass. The installation angle and performance of the radar need to be determined according to the application.
