VGA Converter
To Monitor
INSTALLATION / PLACEMENT
1. Turn off the DVR BEFORE connecting the VGA Converter.
2. Connect the VGA Connector
Cable from the PC Monitor to the
VGA Port on the VGA Converter
Accessory.
3. Connect the VGA
Converter Accessory to the
L224 Series DVR using the
D/V Port.
MODEL ACCL224VGA
VGA CONVERTER ACCESSORY
(For L224 Series DVR Only)
To DVR
THIS PACKAGE CONTAINS:
1 – VGA Converter for L224
Series DVR
FEATURES
• Allows the L224 Series DVR
to be connected to a PC
Monitor
• Converts the signal to VGA
Advertisement
Table of Contents
Related Manuals for Lorex ACCL224
Summary of Contents for Lorex ACCL224
- Page 1 VGA Converter To Monitor INSTALLATION / PLACEMENT 1. Turn off the DVR BEFORE connecting the VGA Converter. 2. Connect the VGA Connector Cable from the PC Monitor to the VGA Port on the VGA Converter Accessory. 3. Connect the VGA...
- Page 2 4. Turn on the DVR. Press MENU (on the front panel of the DVR), and enter the DVR PASSWORD (0000 by default). Navigate to the Monitor Setup on the DVR: • Use the keys to navigate. ▲▼◄► • Press ENTER to select a menu, and MENU to exit.
