Package Contents
Motion Sensor
Overview
AM41TK Series
Quick Start Guide
lorex.com
PIR Sensor
Bracket
(optional)
Battery slot
PIR sensor
LED indicator
Pin insert
Mounting Adhesive
Pin*
*May include one or more, depending on the package purchased.
To purchase additional sensors, visit
lorex.com
and/or authorized resellers.
Specifications
•
Environment: Indoor
•
Maximum detection distance: 26 feet
•
Maximum detection angle: 110°
•
Operating temperature: 14°F~113°F
•
Operating humidity: 0-95%RH
•
Battery: CR2450
•
Protocol: Bluetooth 5.0
LED Behavior
See the table below for definitions of the
sensor's LED behaviors:
Behavior
Meaning
(solid for 2 seconds)
Powered on.
(flashing rapidly)
Ready to pair.
Pairing successful.
(solid for 2 seconds)
Pairing failed. Try
(flashing 3 times)
repeating the setup.
Alarm has been
(flashing rapidly)
triggered.
Firmware upgrade in
(flashing)
progress.
WARNING:
CHOKING HAZARD
KEEP OUT OF REACH OF CHILDREN
Lorex products come with a standard 1-year
warranty. For more information about Lorex's
warranty policy, visit lorex.com/warranty.
AM41TK_QSG_EN_R1
