Lorex SG6185W Specifications

WEathErproof mini color camEra
fE atU r ES
• Durable weatherproof metal camera suitable for
indoor/outdoor installations
• 6 high intensity IR LEDs provide illumination in no/low
light conditions up to 20ft/6m
• Color video during the day, automatically changes to
black & white video in low light
• Built-in microphone provides audio from the camera to
the monitor/television
• Easily connects to any TV or VCR with RCA A/V inputs
• Mounts easily to walls or ceilings
S pE ci fi cation S
Image Sensor Type: Color CMOS (640x480)
Resolution: 400 TV lines
Shutter Control: auto 1/30 - 1/625,000
Lens: 3.9mm F 2.8
IR LED's: 6 LEDs
Minimum Illumination: 1.0 Lux, 0 Lux with LEDs
Field of View (FOV): 60 degrees diagonal
Night Vision Range: 20ft/6m
Power Requirement: 7.5 V DC Adapter (included)
Operating Temp Range: 14 °F ~122°F ( -10°C ~ 50°C)
operating humidity range 30-90%
Unit Weight: 0.11kg / 0.25lbs
Housing: Weatherproof metal case
pac k aGE inform ation
SG6185W: UPC: 7-78597-06185-7
English package
SG6185Wf: UPC: 7-78597-16185-4
tri-lingual
package
Weight: 1.13kg / 2.5lbs
Dimensions: 6.9" x 6.1" x 3.7"
175 mm x 155 mm x 95 mm
cube:
0.00149m / 0.526ft
contents:
Camera, stand, sunshield, 100ft
(30m) extension cable, 7.5V DC power
adaptor
SG6185 Series
lorex technology inc.
300 Alden Road, Markham,
3700 Koppers Street, Suite 504
Ontario L3R 4C1 Canada.
Baltimore, Maryland 21227, USA.
p l U G a n D p l a Y S E c U r i t Y
With niGht ViSion
one of the world's smallest weatherproof
miniature cameras, the SG6185 also offers
IR (low light) illumination, a flexible camera
mounting bracket, true plug-and-play installation
simplicity and excellent image quality.
D i mE n Si o nS
2"in / 50mm
w w w . l o r e x c c t v . c o m
As our product is subject to continuous improvement, Lorex Technology &
subsidiaries reserve the right to modify product design, specifications & prices
without notice and without incurring any obligation. E&OE
3.7"in / 95mm
3.1"in / 80 mm
©2009 Lorex Technology Inc.
2-02032009
