Weather resistant color camera with night vision

Advertisement

4. View the Camera Picture

a. Turn on your TV
b. To view the picture from the camera, switch to
the Video mode (i.e. AV, or AUX mode).
Refer to your VCR's (or camera's) owner's manual
for instructions for connecting the VCR
This camera can also be connected to a video
cassette recorder (VCR) or Digital Video Recorder
(DVR) that provides RCA camera cable input jacks.

Specifications

Image Device
Color CMOS (510H x 492V)
Resolution
330 TV Lines
Shutter Control
Auto 1/60 – 1/15,000 SEC
Lens
6mm F1.8
Minimum Illumination
3.0 LUX, 0 LUX with IR LED
Power Requirement
9V DC Adapter (included)
º
Operating Temperature
14
F to 113
Housings
ABS Plastic
It's all on the web
Product Information
User Manuals
Quick Start Guides
V I S I T
www.lorexcctv.com
Strategic Vista International Inc.
Copyright © 2005 Strategic Vista International Inc
As our products are subject to continuous improvement, SVII
and its subsidiaries reserve the right to modify product design,
specifications and prices, without notice and without incurring
any obligation. E&OE
º
º
º
F (-10
C to 45
C)
W E A T H E R R E S I S T A N T C O L O R
Specification Sheets
Software Upgrades
Firmware Upgrades
B U S I N E S S & H O M E
C A M E R A w i t h N I G H T V I S I O N
Model SG6157
Quick Set-up Guide
