Summary of Contents for Baudcom BD-ONT-114G-BE
- Page 1 Shanghai Baudcom Communication Device Co.,Ltd Model: BD-ONT-114G-BE 4GE+POE XPON SFU ONU USER MANUAL Version V2.0 Website: http://www.baudcom.com.cn Email: info@baudcom.com.cn Tel: +86 21 37709251 Page I...
-
Page 2: Table Of Contents
Shanghai Baudcom Communication Device Co.,Ltd directory Chapter 1 Products ................错误!未定义书签。 XPON ONUProduct introduction ..................1 Product overview ................错误!未定义书签。 Hardware specifications ..............错误!未定义书签。 The software features..............错误!未定义书签。 1.4 Application of figure ....................3 1.5 Panel described ......................3 Chapter 2 Quick Installation ..................5 2.1 Standard package contents .................. -
Page 3: Hardware Specifications
Shanghai Baudcom Communication Device Co.,Ltd Chapter 1 Product Introduction XPON ONU introduction 1. Product Description BD-ONU-114G-BE provides industrial-grade high-reliability ONU. By optimizing software and hardware processing, it supports lightning protection of up to 6 kV and high temperature resistance of up to 70 degrees, and supports docking compatibility with OLT of various manufacturers. - Page 4 Shanghai Baudcom Communication Device Co.,Ltd Output optical power 0~+4dbm Sensitivity of reception -28dbm Saturation of reception -10dbm PON interface 1*SC/PC Interface features 4*10/100/1000Base-T 口 Data interface size 125(L)×120(W)×30(H) weight 0.42KG power The external power supply 48v 2A Power consumption <72 -40℃...
-
Page 5: Application Of Figure
Shanghai Baudcom Communication Device Co.,Ltd 1.4 Application of figure 1-2: Application of figure 1.5 Panel described The name of the function Connect GPON or EPON ports to the Internet via SC single-mode fiber optic cable. LAN1-LAN4 Connect the PC to the Ethernet port of the SFU using the RJ-45 CAT5 Press the reset button to restart the device and restore it from factory default Settings. - Page 6 Shanghai Baudcom Communication Device Co.,Ltd Indicator name state function destroy No power supply POWER bright Has the power supply destroy The device is not registered with the OLT. Procedure bright The device has been registered with the OLT. Procedure flashing...
-
Page 7: Chapter 2 Quick Installation
Shanghai Baudcom Communication Device Co.,Ltd Chapter 2 Quick Installation 2.1 Standard package contents When you receive our products, please check carefully to make sure there are no defects in our products. If there is a problem with the transportation, please contact the transportation company;... -
Page 8: Establish A Connection
Shanghai Baudcom Communication Device Co.,Ltd 4. Check all signal levels and services on all SFU communication ports. Equipment Installation and Adjustment： Install the SFU on a horizontal surface (bench top) Place the SFU on a clean, flat, sturdy work surface. You must keep the clearance of each side of the device at least 10 cm to dissipate heat。... -
Page 9: Chapter 3 Configuration
Shanghai Baudcom Communication Device Co.,Ltd Chapter 3 Configuration After the basic connection configuration is complete, you can use its basic functions. To meet personalized service requirements, this chapter describes how to modify parameters and configure personalized services。 3.1 The login The device is configured through the Web interface. -
Page 10: Equipment Information
Shanghai Baudcom Communication Device Co.,Ltd 3.2.1 Equipment information This page displays basic device information, such as device model, device ID, hardware version, and software version。 3-2: Equipment information 3.2.2 PON information This page displays GPON or EPON information, including connection information, FEC... -
Page 11: Network
Shanghai Baudcom Communication Device Co.,Ltd PON information 3-5: 3.3 network 3.3.1 Management IP Address Configuration 3.3.2 Configuring Management vlans 3.3.3 Port configuration The ZTE C300 device is used as an example to configure Internet access data for the SFU device。... -
Page 12: Multicast Configuration
Shanghai Baudcom Communication Device Co.,Ltd (This command registers the device with the OLT) （This command configures the bandwidth template, line template, and VLAN for the ONU） （In the second step, configure VLAN70 as the Internet access VLAN, VLAN2000 as the PPPOE dial-up VLAN, and VLAN3056 as the multicast VLAN）... -
Page 13: Application
Shanghai Baudcom Communication Device Co.,Ltd device in slot 2, port 6） （This command displays the configuration information about all ports of the 12th ONU in slot 2, port 6） 3.5 application 3.5.2 Equipment management 3.5.2.1 Equipment to restart This page allows you to restart the device. The restart process will take a few minutes。... - Page 14 Shanghai Baudcom Communication Device Co.,Ltd 3-51: upgrade 3.5.2.3 Restoring Default Settings This page allows you to restore the device to default Settings. You can click Restore Factory Defaults restore configurations. After recovery, will restart automatically. 3-52: Restoring Default Settings 3.5.2.4 Configuration file management This page allows you to back up and restore the SFU configuration。...
-
Page 15: Chapter 4 Frequently Asked Questions
Shanghai Baudcom Communication Device Co.,Ltd Chapter 4 Frequently Asked Questions Q: Are all the indicators off? Answer: (1) The power supply is turned off or the power adapter is damaged. (2) The indicator LED switch is off. 2. Q: Why do Los lights flash? Answer: (1) No optical signal.
