KEY LABEL COLOR

To identify the status of a key during template editing, the key label is displayed in three
different colors.
•
Black - The key is blank with no definition.
•
Blue - When a template is loaded from file or read from keyboard, all keys that
are not blank will be displayed in blue.
•
Green - When a key is modified after a template load or keyboard read, it will be
changed to green to identify that this key has been changed from the original
template.
KB5000 User Manual Rev. 2
18
In this example
of the KB5000
template, the
L51 key is a
blank key and is
indicated by the
color black.
In this example
of the KB5000
template, the
R11 key is a
defined key and
is indicated by
the color blue.
