Linksys WPC54A Quick Installation

This Quick Installation is meant to help you install the product quickly and easily. For detailed instructions on installation
and configuration and further setup options, please consult the User Guide.
Instant Wireless™ Series
WPC54A
W W i i r r e e l l e e s s s s
System Requirements
• Pentium-Class 200MHz or Faster Processor
P P C C C C a a r r d d
• 64MB RAM Recommended
• One Available Type II or Type III PCMCIA
CardBus Slot
• One CD-ROM Drive
• Windows 98SE, Me, 2000
• 5 Mb of free disk space for utility and
driver installation
Package Contents
• One Wireless PC Card (IEEE 802.11a) (1)
• One Setup CD-ROM with User Guide (2)
• One Quick Installation Guide
• One Registration Card
2
Installing the Wireless PC Card
Software
Note: Make sure to install the software before you install the Wireless
PC Card.
A. Insert the Setup Wizard CD into your CD-ROM Drive. The Setup
Wizard should run
automatically, and
the following screen
should appear. If it
does not, click Start
and choose Run. In
the box that appears,
enter D:\setup.exe
(where "D" is the
letter of your CD-
ROM drive.)
A
B. Click on the Setup
button.
C. When the screen at
the right appears,
click Next to contin-
ue.
C
1
D. The Warranty Policy will appear. Click Yes if you agree, or No to end the
installation.
D
E. The InstallShield Wizard will automatically choose a folder where the
Setup Wizard will install the files. Click Next.
E
F. The InstallShield Wizard will ask you to choose a wireless mode. Choose
the mode that applies to your network. Ad-Hoc Mode is used for simple
peer-to-peer networking or sharing of local resources between wireless
networked PCs. Infrastructure Mode allows a wireless network to be
integrated into an existing, wired network through an access point, per-
mitting roaming between access points while maintaining a connection to
all network resources. Select the radio button next to your choice, and
click Next.
F
Continued on back
