Linksys PCM100H1 Specifications

H H o o m m e e L L i i n n k k P P h h o o n n e e l l i i n n e e + + 1 1 0 0 / / 1 1 0 0 0 0 N N e e t t w w o o r r k k P P C C C C a a r r d d
( ( P P C C M M 1 1 0 0 0 0 H H 1 1 ) )
Also Connect Your Desktop PCs!
H H o o m m e e L L i i n n k k P P h h o o n n e e l l i i n n e e N N e e t t w w o o r r k k C C a a r r d d ( ( H H P P N N 1 1 0 0 0 0 ) )
H H o o m m e e L L i i n n k k P P h h o o n n e e l l i i n n e e 1 1 0 0 M M b b p p s s N N e e t t w w o o r r k k C C a a r r d d ( ( H H P P N N 2 2 0 0 0 0 ) )
H H o o m m e e L L i i n n k k P P h h o o n n e e l l i i n n e e + + 1 1 0 0 / / 1 1 0 0 0 0 U U S S B B N N e e t t w w o o r r k k A A d d a a p p t t e e r r ( ( U U S S B B 1 1 0 0 0 0 H H 1 1 ) )
H H o o m m e e L L i i n n k k P P h h o o n n e e l l i i n n e e N N e e t t w w o o r r k k i i n n a a B B o o x x ( ( H H P P N N 1 1 0 0 0 0 S S K K ) )
Benefits
Benefits
• Connect to Any HomeLink or Ethernet
with Just One PC Card
• Share Files, High-Speed Internet Access
and More Without Interrupting Normal
Phone Service
• No Additional Hubs or Cables Needed
• Standard 16-Bit PC Card with 2 RJ-11
Telephone Ports and 1 10/100 Port
• 1Mbps Transfer Rate Over Standard
Telephone Lines
• Bonus Internet Sharing Software Included
• Free Technical Support and 1-Year Warranty
HomeLink
10/100 Network PC Card
Build a Network on Your Home's Existing Telephone Line
or Connect to a 10/100 Network
Using Just One PC Card!
o you need a PC Card that offers instant
D
connectivity to multiple PCs over a
home's existing telephone lines or using
a regular 10/100 Ethernet connection? The
answer is here! The HomeLink Phoneline +
10/100 Network PC Card is the ultimate in versa-
tile connectivity for mobile users. This 16-Bit PC
Card's coupler is equipped with two standard
RJ-11 telephone ports and a 10/100 dual-speed
Ethernet port. You can connect to any 1Mbps
HomeLink network or any 10BaseT/100BaseTX
network without using two network cards. The
card fits into any standard Type II PCMCIA slot,
leaving room for a 56K modem or other PC Card
in dual-slot notebook PCs. You can share Internet
access via a dial-up, cable modem or DSL con-
nection, as well as files, printers, and CD-ROM
drives at 1Mbps without interrupting regular tele-
phone service. Since your HomeLink network
runs on regular telephone cables, there's no extra
hardware to buy. Just plug it into any standard
wall jack and you're networked!
Features
Features
• Build A Network Using Your Existing
Telephone Line -- No Additional Hubs or
Cabling Needed
• Share Your High-Speed Internet Access with
Your HomeLink PCs
• 1Mbps Transfer Rate Over Telephone Lines --
Perfect for File and Printer Sharing, Email,
Internet Access, Network Gaming and More
• Autosensing RJ-45 Port Automatically Detects
Cabling Speed
• HomePNA-Compatible
• Type II PCMCIA Network Card with 2 RJ-11
Modular Telephone Ports and 1 RJ-45
10BaseT/100BaseTX Ethernet Port
• Compatible with Virtually All PCMCIA and
CardBus-Equipped Notebook PCs
• Free Technical Support
• Limited 1-Year Warranty
Phoneline +
™
