- Page 1 100205196 HOSE REEL CART ASSEMBLY INSTRUCTION...
- Page 2 Warranty This product is covered by the manufacturer’s one-year limited warranty. This guarantees that as of the date of purchase, the product is free of defects in material and workmanship. Under normal use and proper care, this product will remain free of defects for one year from the date of purchase.
- Page 3 PARTS LIST Frame Axles Wheels Hose Reel Handle Pull Handle Leader Hose Accessories Basket...
- Page 4 HARDWARE LIST PART# DESCRIPTION Q UANTITY Coach Bolt, 6 x 33mm Coach Bolt, 6 x 39mm Bolt, 6 x 30 mm Bolt, 8 x 45mm Hex Nut, 8mm Flat Washer, 8mm Lock Nut, 12mm Flat Washer, 12mm Lock Nut, 6mm Flat washer, 6mm Dome Nut, 6mm Rubber Washer (Includes 1-Spare Rubber Washer...
- Page 5 ASSEMBLY INSTRUCTIONS PLEASE READ ALL INSTRUCTIONS AND IDENTIFY ALL PARTS BEFORE STARTING ASSEMBLY Figure 1 (See Figure 1) Remove the Lock Nuts (O) and Flat Washers (P) from each of the two Axles (B). Slide the Axles .. . (B) through the holes at the bottom ' fj.
- Page 6 Hose Figure 4 (See Figure 4) Place the Hose Reel (D) Coupling onto the Frame (A) and align the handle stem with the handle hub (*bearing house). Insert the handle stem into the Handle (E) hole. Crank Stem ' (See Figure 5) Align the Handle (E) Figure 5 mounting holes with the handle stem mounting holes, insert a Bolt (K) into...
- Page 7 (See Figure 7) Slot the Pull Handle (F) Figure 7 onto the Frame (A) and align the F---- mounting holes. Secure with Coach a..Bolts (J), Flat Washers (R) and Lock Nuts (Q). (See Figure 8) Place Flat Washers (R) Figure 8 onto the end of two Bolts (L) and insert into the mounting holes of the...
