- Page 1 Item No. : 8588 Solar + LED Floodlight ™ Solar + Reflector LED ™ Solaire + Projecteur DEL User’s Manual We are constantly improving our products so specifications are subject to change without notice. RoHS compliant...
- Page 2 Solar + LED Floodlight 800 by Wagan Tech ™ ® Thank you for purchasing the Solar + LED Floodlight 800 by Wagan Tech ™ ® With normal care and proper treatment, it will provide years of reliable service. Please read all operating instructions carefully before use.
-
Page 3: Specifications
User’s Manual—Read before using this equipment SPECIFICATIONS Solar panel 7.0W, mono-crystalline silicon Battery 3.7V, 6.0 Ah, Li-ion LED count Brightness (Lumens) 800 lm max Recharge time 6 hours full sunlight Lighting time nights Waterproof IP65 Install height 8–11 ft (2.5~3.5 m) Materials PCB, poly-carbonate plastic, ABS plastic, glass... -
Page 4: Initial Activation
Solar + LED Floodlight 800 by Wagan Tech ™ ® APPLICATIONS Suitable for outdoor wall or pole installation in plazas, parks, gardens, courtyards, streets, walkways, pathways, campuses, airfields, farms, and perimeter security. INITIAL ACTIVATION Activate the light by pressing the button on the underside of the light (as shown below). -
Page 5: Wall Installation
User’s Manual—Read before using this equipment Wall installation First, remove the U-bolts. Make 2 holes in the wall and take out the expansion bolt and washer. Attach the light onto the wall. M6 flat washer Expansion bolts M6 spring washer M6 nut Please install the solar panel in a place without any shade and facing direct sunlight for better charging. -
Page 6: Operation
Solar + LED Floodlight 800 by Wagan Tech ™ ® OPERATION First 5 hours: 800 lumens when motion is detected; dims to 100 lumens 20 seconds after no motion. 20 sec After 5 hours (or when battery is below 30%): 800 lumens when motion is detected;... -
Page 7: Special Note
User’s Manual—Read before using this equipment SPECIAL NOTE • Please allow solar panel to charge in bright sunlight for over 5 hours before first time use. • If the sunlight is not strong enough, it may take longer to fully charge the light.
