1 Device Overview

1.1

Features

• Small Size

– QLP 4-mm × 4-mm Package, 16 Pins

• True Single Chip UHF RF Transmitter

• Frequency Bands

– 300 to 348 MHz

– 400 to 464 MHz

– 800 to 928 MHz

• Programmable Data Rate Up to 500 kBaud

• Low Current Consumption

• Programmable Output Power Up to +10 dBm for

All Supported Frequencies

• Programmable Baseband Modulator

• Ideal For Multi-channel Operation

• Very Few External Components

– Completely On-chip Frequency Synthesizer

– No External Filters Needed

• Configurable Packet Handling Hardware

• Suitable for Frequency Hopping Systems Due to a

Fast Settling Frequency Synthesizer

• Optional Forward Error Correction with Interleaving

1.2

Applications

•

Ultra-low Power UHF Wireless Transmitters

•

Operating in the 315-, 433-, 868-, and 915-MHz

ISM/SRD bands

•

AMR – Automatic Meter Reading

•

Consumer Electronics

•

RKE – Remote Keyless Entry

1.3

Description

The CC1150 is a true single-chip UHF transmitter designed for very low power wireless applications. The

circuit is mainly intended for the ISM (Industrial, Scientific and Medical) and SRD (Short Range Device)

frequency bands at 315-, 433-, 868-, and 915-MHz, but can easily be programmed for operation at other

frequencies in the 300 to 348 MHz, 400 to 464 MHz and 800 to 928 MHz bands.

The RF transmitter is integrated with a highly configurable baseband modulator. The modulator supports

various modulation formats and has a configurable data rate up to 500 kBaud. The CC1150 device

provides extensive hardware support for packet handling, data buffering and burst transmissions.

The main operating parameters and the 64-byte transmit FIFO of CC1150 can be controlled via an SPI

interface. In a typical system, the CC1150 device will be used together with a microcontroller and a few

additional passive components.

CC1150 is part of the SmartRF™ technology platform based on 0.18-μm CMOS technology from Texas

Instruments.

An IMPORTANT NOTICE at the end of this data sheet addresses availability, warranty, changes, use in safety-critical applications,

intellectual property matters and other important disclaimers. PRODUCTION DATA.

Sample &

Product

Buy

Folder

CC1150 Low Power Sub-1 GHz RF Transmitter

Tools &

Technical

Software

Documents

SWRS037B – JANUARY 2006 – REVISED MARCH 2015

• 64-byte TX Data FIFO

• Suited for Systems Compliant with EN 300 220

and FCC CFR Part 15

• Many Powerful Digital Features Allow a High-

performance RF system to be made Using an

Inexpensive Microcontroller

• Efficient SPI interface: All Registers Can be

Programmed With One "Burst" Transfer

• Integrated Analog Temperature Sensor

• Lead-free "Green" Package

• Flexible Support for Packet Oriented Systems

– On-chip Support for Sync-Word Insertion,

Flexible Packet Length and Automatic CRC

Handling

• OOK and Flexible ASK Shaping Supported

• 2-FSK, GFSK and MSK Supported

• Optional Automatic Whitening of Data

• Support for Asynchronous Transparent Transmit

Mode for Backwards Compatibility with Existing

Radio Communication Protocols

•

Low Power Telemetry

•

Home and Building Automation

•

Wireless Alarm and Security Systems

•

Industrial Monitoring and Control

•

Wireless Sensor Networks

Support &

Community

CC1150
