400 WATT POWER INVERTER
CPI 400
Nothing Comes Close To A Cobra
Operating Instructions
Printed in China
Part No. 480-057-P
™
English
Our Thanks To You
Introduction
Thank you for purchasing the Cobra
inverter. Properly used, this Cobra
give you many years of reliable service.
How Your Cobra
®
Power Inverter Works
The Cobra
®
Power Inverter is an electronic product
that has been designed and built to take low voltage
DC (Direct Current) power from your automobile by
simply connecting the power inverter to the cigarette
lighter socket (or connecting directly to other low voltage
power supplies) and CONVERT it to standard 115 volt AC
(Alternating Current) power like the current you have in
your home. This conversion process thereby allows you to
use many of your household appliances and electronic
products in automobiles, RVs, boats, tractors, trucks and
virtually anywhere else.
Customer Assistance
Customer Assistance
Should you encounter any problems with this product,
or not understand its many features, please refer to this
owner's manual. If you require further assistance after
reading this manual, Cobra
following customer assistance services:
For Assistance In the U.S.A.
Automated Help Desk English only.
24 hours a day, 7 days a week 773-889-3087 (phone).
Customer Assistance Operators English and Spanish.
8:00 a.m. to 6:00 p.m. CT, Monday through Friday
(except holidays) 773-889-3087 (phone).
Questions English and Spanish.
Faxes can be received at 773-622-2269 (fax).
Technical Assistance English only.
www.cobra.com (on-line: Frequently Asked Questions).
English and Spanish. productinfo
For Assistance Outside the U.S.A.
Contact Your Local Dealer
A1 English
®
CPI 400
®
product will
®
Electronics offers the
cobra.com (e-mail).
@
© 2003 Cobra
®
Electronics Corporation
6500 West Cortland Street
Chicago, Illinois 60707 USA
www.cobra.com
Advertisement
Table of Contents
Related Manuals for Cobra CPI 400
Summary of Contents for Cobra CPI 400
- Page 1 400 WATT POWER INVERTER CPI 400 Nothing Comes Close To A Cobra ™ Introduction Thank you for purchasing the Cobra inverter. Properly used, this Cobra give you many years of reliable service. How Your Cobra Operating Instructions The Cobra that has been designed and built to take low voltage...
-
Page 2: Table Of Contents
Controls /Indicators and Product Features Introduction Features • Reverse Polarity Protection • Two AC Receptacles • Low Battery Alarm • Automatic Thermal Protection/Shutdown • Low Battery Shutdown Protection & Power Indicators AC Outlets Positive Battery Cable Terminal Cooling Fan A2 English Introduction On/Off Power Switch... -
Page 3: Important Safety Information
Important Safety Information Introduction Important Safety Information Before installing and using your Cobra please read these general precautions and warnings. Caution and Warning Statements To make the most of this inverter, it must be installed and used properly. Please read the installation and operating instructions carefully before installing and using it. -
Page 4: Important Safety
Important Safety Information Introduction WARNING Power inverters contain components that tend to produce arcs or sparks. To prevent fire or explosion, do not install the inverter in areas or compartments containing batteries or flammable materials or in locations that require ignition- protected equipment. -
Page 5: Quick Evaluation Before Installation
Connect Test Load or Power and Protection Indicators section on page 12. for details). If the power source is a DC power supply, switch it Off as well. Terminals (see page 8 for details). (see page 8 for details). connections are secure. -
Page 6: Installation Installation Requirements
Installation Requirements Installation Installation Requirements The inverter must be installed in an area that meets all of the following requirements: A. Dry Do not place in an area where water can drip or splash on the inverter. B. Cool Ambient air temperature should be between 30°F and 105°F (0°C and 40°C). -
Page 7: Connecting Cables
To Connect the Cables Between the Inverter and the Battery: 1. Turn the On/Off Switch on the inverter to the Off position. If the power source is a DC power supply, switch it Off as well. On/Off Switch to Off 2. -
Page 8: Power Consumption
On (see “Installation” page 6). To Turn the Power Inverter On: 1. If a DC power supply is being used as the power source, switch it On. 2. On the left side panel, switch the On/Off Switch to On. -
Page 9: Power And Protection Indicators
Power & Protection Indicators Operation NOTE The On/Off Switch turns the control circuit in the inverter On and Off. It does not disconnect power from the inverter. When the switch is in the Off position, the inverter draws no current from the battery. When it’s in the On position, but no power is being supplied to the load, the inverter draws less than 500 milliamperes from the battery. -
Page 10: Troubleshooting Guide
Troubleshooting Guide Operation Troubleshooting Guide Problem/Symptom Possible Causes Low output voltage Overload No output voltage Low input voltage No output voltage Thermal after prolonged use shutdown No output voltage, High input “Protect” indicator voltage lighted No output voltage Short circuit No power to Blown fuse inverter... -
Page 11: Warranty
United Parcel Service (UPS) or First Class Mail to avoid loss in transit to: Cobra Factory Service, Cobra Electronics Corporation, 6500 West Cortland Street, Chicago, Illinois 60707 USA. 6. If the power inverter is in warranty, upon receipt of your power inverter, it will either be repaired or exchanged depending on the model. -
Page 12: Accessories And Order Form
Or call 773-889-3087 (Press 1 from the main menu) 8:00 a.m. to 6:00 p.m. CT, Monday through Friday. Make check or money order payable to: Cobra Electronics, Attn: Accessories Dept. 6500 West Cortland Street, Chicago, IL 60707 USA To order online, please visit our website: www.cobra.com...
