Tecnosystemi smart clima GIOTTO SG User Manual page 3

CODICE
DESCRIZIONE / DESCRIPTION
/ CODE
STAFFA "GIOTTO SG" - 120 EVO
111000801
/ "GIOTTO SG" - 120 EVO BRACKET
STAFFA "GIOTTO SG" - 120 EVO
CON BULLONERIA INOX
11100080VI
/ "GIOTTO SG" - 120 EVO BRACKET
WITH STAINLESS STEEL BOLT
STAFFA "GIOTTO SG" - 160 EVO
111000811
/ "GIOTTO SG" - 160 EVO BRACKET
STAFFA "GIOTTO SG" - 160 EVO
CON BULLONERIA INOX
11100081VI
/ "GIOTTO SG" - 160 EVO BRACKET
WITH STAINLESS STEEL BOLTS
STAFFA "GIOTTO SG" - 160 EVO
GRIGIO ANTRACITE
SCD500120
"GIOTTO SG" - 160 EVO BRACKET
ANTHRACITE GRAY
800
A
DIMENSIONI
/ DIMENSIONS
A [mm] B [mm]
350/750 150/310
350/750 150/310
350/750 180/380
350/750 180/380
350/750 180/380
D
PORTATA
/ LOAD
CAPACITY
C [mm] D [mm] [kg]
420 400 120
420 400 120
420 465 160
420 465 160
420 465 160
COLLAUDO
/ TESTING
[kg]
180
180
240
240
240
3
