TYPICAL PERFORMANCE CHARACTERISTICS
DC2257A CISPR 22 Radiated
Results Without Spread Spectrum
40
30
20
10
0
0
Output Disconnect Response
(Short Circuit)
V
OUT
10V/DIV
V
LED
10V/DIV
I
LED
10A/DIV
6
SPREAD SPECTRUM DISABLED
250 500 750 1000
FREQUENCY (MHz)
8005 G08
8005 G10
500ns/DIV
For more information
T = 25°C, unless otherwise noted.
A
DC2257A CISPR 22 Radiated
Results With Spread Spectrum
40
30
20
10
SPREAD SPECTRUM ENABLED
0
0 250 500
FREQUENCY (MHz)
Output Disconnect Response
(Input > Output)
V
IN
10V/DIV
V
OUT
10V/DIV
V
LED
10V/DIV
1ms/DIV
