INSTRUCCIONES DE MONTAJE - MOUNTING INSTRUCTIONS - MONTAGEANLEITUNG
CÚPULA ADAPTABLE A - SCREEN FOR - WINDSCHUTZSCHEIBE FÜR
ID. PIEZA / PART
1
2
3
4
5
6
7
8
info@puigusa.com
www.puigusa.com
YAMAHA MT125
DESCRIPCIÓN
Cúpula
Tornillo especial M5x13 + rosca interior M5x11
Tornillo especial M5x15 + rosca interior M5x12
Arandela de nylon M5x1
Arandela de goma Ø ext. 15 x Ø int. 5x4
Tornillo Allen M5x14 ISO 7380 (negro)
Arandela de nylon M5x0,5
Tapón tornillo M5 ISO 7380
Ref.: 7654
DESCRIPTION
Screen
Special screw M5x13 + interior thread M5x11
Special screw M5x15 + interior thread M5x12
M5x1 nylon washer
Ø outer 15 x Ø inner 5x4 rubber washer
M5x14 ISO 7380 (black) Allen screw
M5x0,5 nylon washer
M5 ISO 7380 screw cap
QTY.
1
2
2
4
4
4
4
4
